JVC KD-A615J Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

SERVICE MANUAL
6 S ERVICE MANUAL
2010
MA467<Rev.002>
KD-A615J, KD-R610J, KD-R611E, KD-R611EU,
KD-R611EY, KD-R612E, KD-R616U, KD-R616UH,
COPYRIGHT © 2010 Victor Company of Japan, Limited
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)
1
PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
2
SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
3
DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
4
ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-18
5
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-23
CD RECEIVER
KD-R616UN, KD-R618J
KD-A615 / KD-R610
KD-R618
KD-A615
KD-R610

TABLE OF CONTENTS

COPYRIGHT © 2010 Victor Company of Japan, Limited
only KD-R611/KD-R612
No.MA467<Rev.002>
2010/6

Advertisement

Table of Contents
loading

Related Manuals for JVC KD-A615J

Summary of Contents for JVC KD-A615J

  • Page 1: Table Of Contents

    SERVICE MANUAL CD RECEIVER MA467<Rev.002> 2010 6 S ERVICE MANUAL KD-A615J, KD-R610J, KD-R611E, KD-R611EU, KD-R611EY, KD-R612E, KD-R616U, KD-R616UH, KD-R616UN, KD-R618J KD-A615 / KD-R610 KD-R618 only KD-R611/KD-R612 KD-A615 KD-R610 COPYRIGHT © 2010 Victor Company of Japan, Limited Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
  • Page 2 SPECIFICATION KD-R618/KD-A615/KD-R610 AUDIO AMPLIFIER SECTION 20 W RMS × 4 Channels at 4 Ω and < 1% THD+N Power Output 80 dBA (reference: 1 W into 4 Ω) Signal-to-Noise Ratio 4 Ω (4 Ω to 8 Ω allowance) Load Impedance Tone Control Range Bass ±12 dB (60 Hz, 80 Hz, 100 Hz, 200 Hz) Q1.0, Q1.25, Q1.5, Q2.0...
  • Page 3 KD-R616 AUDIO AMPLIFIER SECTION Maximum Power Output Front/Rear 50 W per channel 20 W RMS × 4 Channels at 4 Ω and < 1% THD+N Continuous Power Output Front/Rear (RMS) 4 Ω (4 Ω to 8 Ω allowance) Load Impedance Tone Control Range Bass ±12 dB (60 Hz, 80 Hz, 100 Hz, 200 Hz) Q1.0, Q1.25, Q1.5, Q2.0...
  • Page 4 KD-R611/KD-R612 AUDIO AMPLIFIER SECTION Maximum Power Output Front/Rear 50 W per channel 20 W per channel into 4 Ω, 40 Hz to 20 000 Hz at no more than 1% total har- Continuous Power Output Front/Rear (RMS) monic distortion. 4 Ω (4 Ω to 8 Ω allowance) Load Impedance Tone Control Range Bass...

  • Page 5: Precaution

    SECTION 1 PRECAUTION Safety Precautions (1) This design of this product contains special hardware and voltmeter. many circuits and components specially for safety purpos- Move the resistor connection to each exposed metal es. For continued protection, no changes should be made part, particularly any exposed metal part having a return to the original design unless authorized in writing by the path to the chassis, and measure the AC voltage across...
  • Page 6 Preventing static electricity Electrostatic discharge (ESD), which occurs when static electricity stored in the body, fabric, etc. is discharged, can destroy the laser diode in the traverse unit (optical pickup). Take care to prevent this when performing repairs. 1.5.1 Grounding to prevent damage by static electricity Static electricity in the work area can destroy the optical pickup (laser diode) in devices such as laser products.
  • Page 7 Attention when traverse unit is decomposed *Please refer to "Disassembly method" in the text for the pickup unit. • Apply solder to the short land sections before the card wire is disconnected from the connector on the servo board. (If the card wire is disconnected without applying solder, the pickup may be destroyed by static electricity.) •...
  • Page 8 Important for laser products 1.CLASS 1 LASER PRODUCT 5.CAUTION : If safety switches malfunction, the laser is able to function. 2.CAUTION : (For U.S.A.) Visible and/or invisible class II laser radiation 6.CAUTION : Use of controls, adjustments or performance of when open.

  • Page 9: Specific Service Instructions

    SECTION 2 SPECIFIC SERVICE INSTRUCTIONS This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS. SECTION 3 DISASSEMBLY Main body (Used figure were KD-R610U) 3.1.1 Removing the Bottom chassis (See Fig.1) (2) Remove the two screw F attaching the Top chassis. (See (1) Remove the three screws A attaching the Heat sink.
  • Page 10 3.1.4 Removing the CD mechanism (See Fig.6) (1) Remove the three screws H attaching the CD mechanism. Fig.6 3.1.5 Removing the Switch board (See Fig.7) (1) Remove the Volume knob.ZZ (2) Remove the four screws J attaching the Rear cover. (3) Disengage eleven hooks b engaged Rear cover.
  • Page 11 CD MECHANISM assembly section • Remove the CD MECHANISM assembly from the main body. 3.2.1 Removing the MECHANISM CONTROL BOARD Mechanism assembly (See Fig.1 and 2) control board (1) From the bottom side of CD MECHANISM assembly, CN102 remove the solders from the soldered sections (a, b and c) on the MECHANISM CONTROL BOARD assembly.
  • Page 12 3.2.2 Removing the top cover (See Fig.3 to 5) • Remove the MECHANISM CONTROL BOARD assembly. Top cover (1) From the front side of the CD MECHANISM assembly, change the hook position of the two roller springs. (See Fig.3.) (2) From the side of the CD MECHANISM assembly, remove the six screws B attaching the top cover.
  • Page 13 3.2.4 Removing the PHOTO BOARD assembly (See Fig.7 and 8) Mechanism section • Remove the MECHANISM CONTROL BOARD assembly and top cover. Mecha frame spring spring (1) From the bottom side of the top cover, release the projection e from the notch of the disc plate. (See Fig.7.) (2) Take out the disc plate in the direction of the arrow.
  • Page 14 3.2.6 Removing the slide cam (L) (See Fig.11 to 13) Slide cam(L) • Remove the MECHANISM CONTROL BOARD assembly, top cover and mechanism section. (1) From the top side of the mecha frame, remove the screw F attaching the cam cover. (See Fig.11.) (2) Take out the cam cover from mecha frame in an upward direction.
  • Page 15 3.2.7 Removing the F.lock lever and slide cam (R) (See 3.2.8 Removing the damper (See Fig.16) Fig.14 and 15) • Remove the MECHANISM CONTROL BOARD assembly, top • Remove the MECHANISM CONTROL BOARD assembly, top cover and mechanism section. cover and mechanism section. From the mechanism section, pull out the three dampers in the (1) From the top side of the mecha frame, take out the slide direction of the arrow.

  • Page 16: No.ma467)1

    3.2.10 Removing the feed motor (See Fig.18 and 19) • Remove the MECHANISM CONTROL BOARD assembly, top Feed motor cover, mechanism section and clamper assembly. (1) From the bottom side of the T.M chassis assembly, remove Comp. spring F.worm gear the two screws G attaching the feed motor assembly.

  • Page 17: No.ma467

    3.2.13 Removing the pickup assembly (See Fig.21 to 22) 3.2.14 Removing the spindle motor (See Fig.23 and 24) • Remove the MECHANISM CONTROL BOARD assembly, top • Remove the MECHANISM CONTROL BOARD assembly, cover, mechanism section, clamper assembly and feed motor top cover, mechanism section, clamper assembly, feed motor assembly.

  • Page 18: Adjustment

    SECTION 4 ADJUSTMENT Test instruments required for adjustment Standard volume position (1) Digital oscilloscope (100MHz) Balance and Bass &Treble volume : lndication"0" (2) Digital tester Loudness : OFF (3) Test Disc Dummy load (4) Extension cable : EXTCD004-28P Exclusive dummy load should be used for AM,and FM. Standard measuring conditions For FM dummy load, there is a loss of 6dB between SSG output Power supply voltage DC14.4V(10.5 to 16V)
  • Page 19 SERVICE MODE Operating key: [MENU] → [DOWN] (3 sec) Navigation key : Press [SEL] in any main display item to select that option. Volume Knob Turn: forward and backward selection INT ALL Initialize all data to factory shipment state. Note : A disc is inserted, and it is displayed only at the time of CD function. RUNNING MODE 1 CD6 module running mode 1 (Only factory use)
  • Page 20 DC OFFSET ERROR INFORMATION 4.7.1 Display indication DC OK DC 1 OK CLR DC1 VOL push to confirm push push DC ERROR DC 1 ERROR BACK BACK knob DC 2 X CLR DC2 VOL push to confirm push BACK 4.7.2 Error content confirmation. Whether it turns on power and the "PROTECT"...
  • Page 21 TUNER SERVICE MODE Key operation (FM and AM mode) Enter service mode: [SEL] → [MENU] (3 sec) Exit service mode: press [ENTER] (SEL) key. Go to next item: press [DISP] key Back to previous item: press [BACK] key VER=#*** MICON version display # indicates destination: J=USA, U=OTHERS (eg.
  • Page 22 ERROR CODE 4.9.1 Mechanical Error Detail Codes Condition Details Error code Detailed code LOADING Error Error without SW change in LOAD when time-out is done B1 time out When there is no change in the state of the switch from the state 0011 with DISC forward.

  • Page 23: Troubleshooting

    SECTION 5 TROUBLESHOOTING 16 PIN CORD DIAGRAM (For KD-A615/KD-R610/KD-R618) Black Green Gray GN/BK WH/BK Blue Orange VI/BK GY/BK White Yellow Violet BL/WH OR/WH OR/WH GN/BK VI/BK WH/BK GY/BK 3 BL/WH (No.MA467<Rev.002>)1-23...
  • Page 24 16 PIN CORD DIAGRAM (For KD-R611/KD-R612) Black Green GN/BK WH/BK Gray VI/BK GY/BK Blue Brown White Orange Violet Yellow BL/WH OR/WH BL/WH OR/WH RD3 BK OR/WH BL/WH GN/BK VI/BK WH/BK GY/BK VI/BK GY/BK WH/BK GN/BK 1-24 (No.MA467<Rev.002>)
  • Page 25 16 PIN CORD DIAGRAM (For KD-R616) Black Green Gray GN/BK WH/BK Blue Orange VI/BK GY/BK White Yellow Violet BL/WH OR/WH BL/WH 2 RD OR/WH GN/BK VI/BK WH/BK GY/BK (No.MA467<Rev.002>)1-25...
  • Page 26 Victor Company of Japan, Limited Mobile Entertainment Division 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan (No.MA467<Rev.002>) Printed in Japan...
  • Page 27 REVISION INFORMATION CD RECEIVER KD-A615J, KD-R610J, KD-R611E, KD-R611EU, KD-R611EY, KD-R612E, KD-R616U, KD-R616UH, KD-R616UN, KD-R618J ■ OVERVIEW Add KD-R612E. ■ DETAILS COVER SECTION Title Line No.MA467<Rev.001> No.MA467<Rev.002> Description Revision Rev.001 Rev.002 Issue Date 2010/02 2010/06 Model No. KD-A615J, KD-R610J, KD-R611E, KD-A615J, KD-R610J, KD-R611E, KD-R611EU,...
  • Page 28 Electrical parts list Main board [01] Part No. Symbol Part Name Description Models <Rev.001> <Rev.002> 01 C303 ------------ NCB21CK-474X-A C CAPACITOR (Addition) 1 06 01 C304 ------------ NCB21CK-474X-A C CAPACITOR (Addition) 1 06 01 C313 ------------ NCB21CK-474X-A C CAPACITOR (Addition) 1 06 01 C314 ------------...
  • Page 29 PARTS LIST CD RECEIVER KD-A615J KD-R610J KD-R611E KD-R611EY KD-R611EU KD-R616U KD-R616UN KD-R616UH KD-R618J (No.MA467<Rev.001>)1/16...
  • Page 30 ■ PRECAUTIONS ON SCHEMATIC DIAGRAMS Due to the improvement in performance, some part numbers shown in the circuit diagrams may not agree with those indicated in the Parts List. The parts numbers, values and rated voltage etc. in the Schematic Diagrams are for reference only.
  • Page 31 Exploded view of general assembly Block No.M1MM Except KD-R610 Main board Switch board The parts without symbol number are not service. No.MA467 created date:2010-02-09 (No.MA467<Rev.001>)3/16...
  • Page 32 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-A615J KD-R610J KD-R611E KD-R611EY KD-R611EU KD-R616U KD-R616UN KD-R616UH KD-R618J Safe Symbol No. Parts No. Parts Name Description Local General assembly <M1MM> GE10248-012A TOP CHASSIS A,C,D,E,F,G,H,I GE10248-003A TOP CHASSIS GE33323-002A HEAT SINK GE20248-003A...
  • Page 33 CD mechanism assembly Block No.MBMM Grease JVG-31N FG-87HS JVS-1003 Photo board Rest switch board Back side 11.1mm ± 0.1mm Mecha control board 11.1mm ± 0.1mm The parts without symbol number are not service. No.MA467 created date:2010-02-09 (No.MA467<Rev.001>)5/16...
  • Page 34 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-A615J KD-R610J KD-R611E KD-R611EY KD-R611EU KD-R616U KD-R616UN KD-R616UH KD-R618J Safe Symbol No. Parts No. Parts Name Description Local FMU-CD6-21D CD mechanism <MBMM> LV11598-001A MECHA FRAME A,B,C,D,E,F,G,H,I LV36800-002A LINK ARM A,B,C,D,E,F,G,H,I LV22300-002A SLIDE CAM (L)
  • Page 35 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-A615J KD-R610J KD-R611E KD-R611EY KD-R611EU KD-R616U KD-R616UN KD-R616UH KD-R618J Safe Symbol No. Parts No. Parts Name Description Local Q881 RT1N141C-X DIGI TRANSISTOR Q881 UN2211-X TRANSISTOR Q891 RT1N141C-X DIGI TRANSISTOR C,D,E Q921 2SB1132/QR/-W...
  • Page 36 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-A615J KD-R610J KD-R611E KD-R611EY KD-R611EU KD-R616U KD-R616UN KD-R616UH KD-R618J Safe Symbol No. Parts No. Parts Name Description Local C313 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J C314 NRSA02J-0R0X MG RESISTOR 0Ω 1/10W J...
  • Page 37 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-A615J KD-R610J KD-R611E KD-R611EY KD-R611EU KD-R616U KD-R616UN KD-R616UH KD-R618J Safe Symbol No. Parts No. Parts Name Description Local NRS181J-4R7X MG RESISTOR 4.7Ω 1/8W J NRSA63J-472X MG RESISTOR 4.7kΩ 1/16W J NRS181J-472X MG RESISTOR 4.7kΩ...
  • Page 38 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-A615J KD-R610J KD-R611E KD-R611EY KD-R611EU KD-R616U KD-R616UN KD-R616UH KD-R618J Safe Symbol No. Parts No. Parts Name Description Local R730 NRSA63J-102X MG RESISTOR 1kΩ 1/16W J R731 NRSA63J-101X MG RESISTOR 100Ω 1/16W J...
  • Page 39 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-A615J KD-R610J KD-R611E KD-R611EY KD-R611EU KD-R616U KD-R616UN KD-R616UH KD-R618J Safe Symbol No. Parts No. Parts Name Description Local L930 NQLH25M-4R7X COIL 4.7uH M CN501 QGB2027ME-28 CONNECTOR B-B (1-28) CN701 QGZ1101J1-20 CONNECTOR (1-20)
  • Page 40 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-A615J KD-R610J KD-R611E KD-R611EY KD-R611EU KD-R616U KD-R616UN KD-R616UH KD-R618J Safe Symbol No. Parts No. Parts Name Description Local R674 NQR0007-002X FERRITE BEADS R675 NQR0007-002X FERRITE BEADS R676 NQR0007-002X FERRITE BEADS R681 NRSA63J-471X MG RESISTOR 470Ω...
  • Page 41 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-A615J KD-R610J KD-R611E KD-R611EY KD-R611EU KD-R616U KD-R616UN KD-R616UH KD-R618J Safe Symbol No. Parts No. Parts Name Description Local C351 NDC31HJ-270X C CAPACITOR 27pF 50V J A,B,C,D,E,F,G,H,I C352 NDC31HJ-270X C CAPACITOR 27pF 50V J...
  • Page 42 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-A615J KD-R610J KD-R611E KD-R611EY KD-R611EU KD-R616U KD-R616UN KD-R616UH KD-R618J Safe Symbol No. Parts No. Parts Name Description Local R525 NRSA63J-473X MG RESISTOR 47kΩ 1/16W J A,B,C,D,E,F,G,H,I CN101 QGB2027L5-28X CONNECTOR B-B (1-28) A,B,C,D,E,F,G,H,I...
  • Page 43 Packing materials and accessories Block No.M3MM No additional / supplemental order of WARRANTY CARDs are available. KD-R610 E,EY,U The parts without symbol number are not service. No.MA467 created date:2010-02-09 (No.MA467<Rev.001>)15/16...
  • Page 44 MODEL MARK MODEL MARK MODEL MARK MODEL MARK KD-A615J KD-R610J KD-R611E KD-R611EY KD-R611EU KD-R616U KD-R616UN KD-R616UH KD-R618J Safe Symbol No. Parts No. Parts Name Description Local Packing and accessories <M3MM> GET0640-001A INST BOOK GET0639-002B INST BOOK KOR CHI(TAIWAN) ARA PER...

  • Page 45: Schematic Diagrams

    SCHEMATIC DIAGRAMS CD RECEIVER KD-A615J KD-R610J KD-R611E KD-R611EY KD-R611EU KD-R616U KD-R616UN KD-R616UH KD-R618J (No.MA467<Rev.001>)1/21...
  • Page 46 ■ PRECAUTIONS ON SCHEMATIC DIAGRAMS Due to the improvement in performance, some part numbers shown in the circuit diagrams may not agree with those indicated in the Parts List. The parts numbers, values and rated voltage etc. in the Schematic Diagrams are for reference only.
  • Page 47 TU.L, TU.R EEPROM FOCUS+ CD6_SO IC301 CD PICK UP FOCUS- VF1, VF2 LINE OUT DRIVER CD6_SI TRK+ KD-A615J, KD-R618J & VT1, VT2 X301 CD6_UCS TRK- U, UN, UH versions MD, LD FRONT L 16.9344MHz PICK UP Q321 CD6_CLK FRONT R...

  • Page 48: Main Section

    4.2V KEY1 /BUSIO R717 DC_ERR 3.3V BUSIO BUSIO DC OFFSET C734 DIMIN CH.R VREF+ CH.L KD-R618J BUSCLK C709 KD-A615J KD-R611E KD-R615U JVC BUS KD-R610J BUSINT BUSINT R805 1.ANTO ANTENNA /BUSIO R803 Q921,Q922,R921,R922 NOT USED C851,C852,R851,R762 NOT USED USED R801 IC801...
  • Page 49 <Switch section> LCD1 LCD DISPLAY QLD0631-001 54 53 52 51 50 49 48 47 46 45 44 43 42 41 40 LCD1 CLASSIC HIPHOP JAZZ ROCK POPS USER LOUD J601 DISC HOLD REMOCON QNS0280-001 R670 STMO AUX IN R671 IC681 KSM-2003TN2M C687 0.0047...
  • Page 50 <Sub section> To Switch section SUB BOARD: GEB10284A2 T1-2 T1-3 To Switch section T1-4 D624 NSSM065T-X No.MA467 created date:2010-02-09 (No.MA467<Rev.001>)6/21...
  • Page 51 <DC-DC Sub section> GEB10284A3 DC-DC USB 5V SUPPLY SUBBOARD C934 L931 C937-C938: 5.1V NQL52EM-220X NCJ11EK-106X-R SWDC/DC 10.9V BOOT USBNPP 14.4V 3.0V 0.5V D930 COMP MBRX130-TP-X To Main section 0.8V USB5V 2.2V SS/TR VSNS C939 5.0V 14.4V RT/CL PWRGD R931 4.3K 0.5V R932 270K...
  • Page 52 <Mecha control section> D503 D502 1SR154-400-X 1SR154-400-X CN101 QGB2027L5-28X 7.8V CD5V 7.9V CD8V D501 0.0V 1SR154-400-X 0.0V M.GND 0.0V Q501 SL001 5.0V 2SB1424/R/-W 1.7V OUTL R340 3.3V 0.0V AGND 1.7V OUTR 0.0V 4.3V 3.3V 3.2V 3.2V 3.1V To Main section 0.0V BCLK 0.0V...
  • Page 53 <Photo section> PHOTO PWB LVB10834-A2 Q212 PS1191RB22/BC/X Q211 PS1191RB22/BC/X To Mecha control section No.MA467 created date:2010-02-09 (No.MA467<Rev.001>)9/21...
  • Page 54 <Rest switch section> REST SW PWB LVB10834-A3 To Mecha control section NSW0291-001X No.MA467 created date:2010-02-09 (No.MA467<Rev.001>)10/21...

  • Page 55: Main Board

    <Main board> (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) C320 IC301 C319 J801 R891 C323 CN901 C321 J321 D342 C992...
  • Page 56 <Switch board> (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) R611 S608 R612 R613 R610 R631 S601 R658 R681 S609 GEA10284-...
  • Page 57 <Switch board> (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) CN603 GEB10284A1 R624 R627 C628 R666 IC601 C691 R665 C601 D661...

  • Page 58: Sub Board

    <Sub board> (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) No.MA467 created date:2010-02-09 (No.MA467<Rev.001>)14/21...
  • Page 59 <Sub board> (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) No.MA467 created date:2010-02-09 (No.MA467<Rev.001>)15/21...
  • Page 60 <DC-DC Sub board> (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) C940 C932 D930 IC930 L931 R934 No.MA467 created date:2010-02-09 (No.MA467<Rev.001>)16/21...
  • Page 61 <DC-DC Sub board> (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) C934 MARK R937 R932 R936 C936 R938 R931 C937 R933...
  • Page 62 <Mecha control board> (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) R343 R345 C392 C317 C312 C306 C331 C346 C305 C308...
  • Page 63 <Mecha control board> (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) RFGND1 FCS- TRK+ FCS+ TRK- Q301 C102 C321 R245 R313...
  • Page 64 <Photo board> (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) ORANGE MARK LVA10872-A3 BROWN No.MA467 created date:2010-02-09 (No.MA467<Rev.001>)20/21...
  • Page 65 <Rest switch board> (Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)) (Lead free solder used in the board (material : Sn-Cu, melting point : 230 Centigrade)) No.MA467 created date:2010-02-09 (No.MA467<Rev.001>)21/21...
