Installation

Installing the refrigerator

The refrigerator comes on four casters to enable it to be moved easily.
Carefully read through the section "Choosing the right location", and install the refrigerator in the best location.
Once the installation location has been decided upon, secure the refrigerator, and adjust it so that it is level.
Removing the front grille
When the two doors are opened and the front grille is viewed from
above, two screws – one on the left and the other on the right – will
be seen.
Turn these screws counterclockwise, and remove them.
There is a connecting area slightly to the right of the centre of the
front grille at the bottom. Take hold of this area, and pull the grille
toward you to remove it.
Securing the refrigerator
Insert a flat screwdriver into a slot on the adjustable legs at the left
and right, turn them in the direction shown by the arrows to lower
the legs to the floor level, and then secure the legs firmly.
Levelling the refrigerator
Turn the adjustable legs so that the refrigerator is installed flush with the floor.
If the left and right doors are not flush with each other, turn one of the adjustable legs, and bring the doors
into alignment.
If the left door is lower than the right door
Insert a flat screwdriver into a slot on the
adjustable leg on the left, turn it in the direction
shown by the arrow, and adjust.
Attaching the front grille
Follow the steps for removing the grille in their reverse order.
● Take care not to pinch or damage the water supply hose.
12
Front grille
Adjustable legs
If the right door is lower than the left door
Insert a flat screwdriver into a slot on the
adjustable leg on the right, turn it in the direction
shown by the arrow, and adjust.
Connecting area
