3/8" IMPACT WRENCH
Model 93296
ASSEMBLY AND OPERATING
INSTRUCTIONS
Due to continuing improvements, actual product may differ slightly from the product described herein.
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
TO PREVENT SERIOUS INJURY,
READ AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE.
©
®
Copyright
2005 by Harbor Freight Tools
. All rights reserved. No portion of this manual or any
artwork contained herein may be reproduced in any shape or form without the express written
consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Central Pneumatic 93296
Summary of Contents for Central Pneumatic 93296
- Page 1 AND INSTRUCTIONS BEFORE USE. © ® Copyright 2005 by Harbor Freight Tools . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools.
-
Page 2: Specifications
Do not overreach. Keep proper footing and balance at all times. Do not reach over or across running machines or air hoses. SKU 93296 For technical questions, please call 1-800-444-3353 Specifications 75 Ft. Lbs. - Page 3 Use of any other parts will void the warranty. Only use accessories intended for use with this tool. Approved accessories are available from Harbor Freight Tools. 17. Do not operate tool if under the influence of alcohol or drugs. Read warning labels if taking prescription medicine to determine if your judgement or reflexes are impaired while taking drugs.
- Page 4 When unpacking, check to make sure the parts listed on page 7 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number on the cover of this manual as soon as possible.
- Page 5 When the nut is loosened, release the Trigger (34). Turn off the air compressor and disconnect the hose. If needed, remove the nut from the socket. SKU 93296 For technical questions, please call 1-800-444-3353 Operation (continued) Page 5...
- Page 6 Air Inlet (29) is facing up. Squeeze the Trigger (34), and place one or two drops of oil into the Air Inlet (29). Squeezing the Trigger (34) allows the oil to circulate in the motor. Anvil (6) Trigger (34) SKU 93296 For technical questions, please call 1-800-444-3353 Maintenance Oil Screw...
-
Page 7: Parts List
OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. NOTE: Some parts are listed and shown for illustration purposes only and are not available individually as replacement parts. SKU 93296 For technical questions, please call 1-800-444-3353 Parts List "... - Page 8 Assembly Drawing SKU 93296 For technical questions, please call 1-800-444-3353 Page 8...
