Connecting to the water supply

line
1. First, shut off the main water supply line.
2. Locate the nearest cold, drinking water line.
3. Follow the Water line Installation
Instructions in the installation kit.
Close Main
Water pipe
4. After connecting the water supply to the water filter, turn your main water
supply back on and dispense about 3L to clear and prime the water filter.
Connecting the water line to the refrigerator
1. Remove the cap from water line on the unit and insert compression nut to
the water line on the unit after disassembling from provided water line.
2. Connect both water line from the unit and water line in the kit.
3. Tighten the compression nut onto the compression fitting. There should be
no gaps between (A, B & C )
4. Turn water on and check for any leakage.
Loosen a
Only connect the water line to a drinkable water source.
If you have to repair or disassemble the water line, cut off 6.5mm of the
plastic tubing to make sure you get a snug, leak-free connection.
Before being used, the leakage in these places should be examined
CAUTION
• Samsung Warranty does not cover WATER
LINE INSTALLATION.
• It will be done at customer's charge unless the
retail price includes installation cost.
• Please contact Plumber or Authorized Installer
for the installation if needed.
• If Water leakage occurs due to improper
installation, Please contact installer.
14_Setting Up
Remove
cap
CAUTION
The water line must be
connected to the cold water
pipe. If it is connected to the
hot water pipe, it may cause
the purifier to malfunction.
Close Main
NO GAP
Water pipe
Water Line
from unit
No gap
Water Line
from unit
