Operating Instructions

© 2006
All rights reserved.
This manual is protected by Copyright.
The Copyright is owned by Medion
Trademarks:
®
MS-DOS
and Windows
®
Pentium
is a registered trademark of Intel
Other trademarks are the property of their respective owners.
®
Medion
makes no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose.
®
Medion
shall not be liable for errors contained herein or for incidental or consequential damages in connection with the
furnishing, performance, or use of this material.
Medion
®
assumes no responsibility for the use or reliability of its software on equipment that is not furnished by Medion
This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this docu-
ment may be photocopied, reproduced, or translated to another language without the prior written consent of Medion
The information in this document is subject to change without notice.
19 Inch TFT

Color Monitor

®
.
®
are registered trademarks of Microsoft
®
.
®
.
®
.
®
.

Advertisement

Table of Contents
loading

Related Manuals for Medion TFT Color Monitor

Summary of Contents for Medion TFT Color Monitor

  • Page 1: Color Monitor

    Medion ® assumes no responsibility for the use or reliability of its software on equipment that is not furnished by Medion ® This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this docu- ®...

  • Page 2: Table Of Contents

    Contents: Notes on these instructions....................1 Our Target Group ......................1 Quality ..........................1 Service ..........................1 Purpose of use........................1 Included Equipment ......................1 Safety and Precautions....................... 2 Operating Safety .......................2 Point of use ........................2 Repair ..........................3 Intended Environment......................

  • Page 3: Notes On These Instructions

    Notes on these instructions Please read through these operating instructions carefully and follow the instructions given. In this way you will guarantee reliable operation and a long life for your TFT monitor. Always keep these instructions handy and close by your TFT monitor. Keep the instructions and the packaging so that if you sell or give away your TFT monitor you can give them to the new owner.

  • Page 4: Safety And Precautions

    Safety and Precautions Operating Safety • Do not allow children to play unattended on electrical equipment. Children may not always correctly recognize danger. • Keep the packing materials, such as foil away from children. The danger of suffocation could arise in the case of misuse. •...

  • Page 5: Repair

    Repair • Leave all repairs of your TFT monitor to authorized and qualified personnel only. • Should a repair be necessary, please contact one of our authorized service partners only. Intended Environment • The TFT monitor can be operated at an ambient temperatures of between +41°F and +95°F (5°...

  • Page 6: Standards/Electro-Magnetic Compatibility

    Standards/Electro-Magnetic Compatibility Your monitor fulfils the requirements for electro-magnetic compatibility and electrical safety speci- fied in the following standards: EN 55022, EN 55024, EN 60950, EN 61000-3-2, EN 61000-3-3 UL60950 / CAN CSA 22.2 No 60950, FCC • When connecting ensure that Guidelines for Electro-Magnetic Compatibility (EMC) are ob- served.

  • Page 7: Fcc Compliance Statement

    Shielded interface cables, if any, must be used in order to comply with the emission limits. Declaration of Conformity According to 47CFR, Parts 2 and 15 for Class B Personal Computers: Medion Aktiengesellschaft____________ (Name of the Responsible Party) Located at: Gänsemarkt 16 – 18_________________ D-45127 Essen_____________________ Germany__________________________ (Address, City, State, Zip Code) Fax : 0 201 / 81 081 –...

  • Page 8: Start-Up

    Start-Up Note Before start-up always read the Chapter "Safety and Precautions" on page 1ff. Mounting the Monitor Stand Mount the monitor stand as shown in the diagram. Perform this step before connecting the monitor. Ill.: Mounting the monitor stand Preparations on Your Computer If you have operated your computer previously with a CRT monitor, it will be necessary for you to make a few preparations.
  • Page 9 • Right mouse click on Windows desk top and left mouse click on "Properties". • Start the "Display" program in "System control". (Ill.: Display Properties) The resolution can be set under “Screen resolution”. Your monitor can display a maximum of 1280 x 1024 image dots.

  • Page 10: Connecting The Monitor

    Connecting the Monitor To start using the TFT monitor straight away, please read the "Safety and Precautions" section (page 1). We recommend that you also read all the other sections as these contain detailed explanations and tips on how to use your TFT display. Power Power DVI-D...

  • Page 11: Positioning Of The Monitor

    Positioning of the Monitor Please ensure that the monitor is set up in such a way that that reflections, glare and light-dark con- trast are avoided (as this will make the screen less attractive to look at). (Ill.: Monitor positioning) Your posture Sitting in one position for long periods can be uncomfortable.

  • Page 12: Working Ergonomics

    Working Ergonomics (Ill.: Workplace) • Hand’s support rest: 2” – 4” • Top line of screen should keep eye’s level or be a little beneath • Eye’s distance to screen: 20” – 28” • Legroom (vertical): at least 26” • Legroom (horizontal): at least 24” The illustration above should give you a guideline for an ergonomic workplace.

  • Page 13: Controls

    Controls (Ill.: Front view controls) Ref. Function Description Menu/Enter When this key is pressed the OSD (ON screen display) starts on your TFT monitor Confirm you selection by pressing this key. Down When OSD is active this key sets a parameter value and decreases Decrease volume Executing it directly lowers the volume.

  • Page 14: Setting The Tft Monitor

    Setting the TFT Monitor You can set certain parameters for the TFT monitor on the OSD menu (ON screen display). OSD Menu (On screen display, all pictures similar) (Ill.: OSD menu) Press the menu key to activate the OSD. 1. Select the options from the main menu with the function selection key 2. 2.
  • Page 15 Icon Item Auto Auto adjust display mode to its utmost performance according to VGA setting. Reset Reset the currently highlighted control of the factory setting. Language Language selection of OSD. H. Position V. Position Exit To exit the OSD. T T F F T T M M E E T T T T I I N N G G T T H H E E O O N N I I T T O O R R...

  • Page 16: Saving Energy

    Saving Energy This monitor can be switched into various states of energy saving by the respective computer or operating system. This meets the current requirements for reduction of power consumption. The monitor supports the following states of low energy consumption: Status Power Consumption Colour of the indicator...

  • Page 17: Service

    Service Troubleshooting If your TFT monitor should have problems please check if it is properly installed and plugged accord- ing to the information given in the “Start-Up” section beginning on page 6. If the problems cannot be solved, read the following chapter for possible solution. Finding the problem Many times, problems have simple causes.

  • Page 18: Do You Require Additional Support

    Characters displayed dark, picture too small, too large or not centered, etc.: • Readjust the corresponding settings. (Setting TFT monitor, page 11) The display is too light or too dark: • Check that the video output level of the computer matches the technical data of the monitor. •...

  • Page 19: Precautions

    Precautions You can increase the service life of your TFT monitor by taking the following precautions: Caution! There are no parts which can be serviced or cleaned inside of the monitor housing. • Before cleaning always disconnect the power line and all connection cables. •...

  • Page 20: Guarantee

    Guarantee The receipt serves as proof of first purchase and should be kept in a safe place. It is required should you need to make use of the guarantee. If the product is passed onto another user, then he shall be entitled to guarantee services for the remaining period of the guarantee.

  • Page 21: Pixel Defects On Tfts (Lcd-Displays)

    There have been several attempts in the past to define the acceptable number of defective pixels. But this can be difficult and varies widely between different manufacturers. MEDION, therefore, adheres to the clear and strict requirements of ISO 13406-2, class II, for the warranty handling of all TFT display products. These requirements are summarized below.
  • Page 22 Class I type failure only applies to special applications, e.g. medical applications, and results in cor- responding price increases. Class II type failure is the established standard for quality conscious manufacturers with high quality displays. Example 1: A 15” - XGA-display consists of 1024 horizontal and 768 vertical picture dots (pixel), which amounts to a total of 786,432 pixel.
