Contents:
SAFETY INSTRUCTION ...................................................................................................... 1
Purpose of use .............................................................................................................. 1
Operating Safety ........................................................................................................... 1
Repair .......................................................................................................................... 1
Setting up location......................................................................................................... 2
Intended Environment .................................................................................................... 2
Connecting ................................................................................................................... 2
Power Supply.............................................................................................................. 2
Standards/Electro-Magnetic Compatibility ......................................................................... 3
Recycling and disposal.................................................................................................... 3
Maintenance and care .................................................................................................... 3
FCC Compliance Statement........................................................................................... 4
Declaration of Conformity ............................................................................................. 4
INTRODUCTION ............................................................................................................... 5
Notes on these instructions ............................................................................................. 5
Our Target Group ........................................................................................................ 5
Quality....................................................................................................................... 5
Service ...................................................................................................................... 5
INCLUDED EQUIPMENT ..................................................................................................... 5
START-UP ....................................................................................................................... 6
Preparations on Your Computer ....................................................................................... 6
Supported Monitor Settings .......................................................................................... 6
Display Properties ....................................................................................................... 7
Unpacking .................................................................................................................... 8
Installing the base plate ................................................................................................. 8
Connecting the Monitor................................................................................................... 8
Connecting VGA Signal Cable..................................................................................... 9
Connecting Audio Cable ............................................................................................ 9
Connecting the Power Supply..................................................................................... 9
Positioning of the Monitor ............................................................................................... 9
CONTROLS.................................................................................................................... 11
SETTING THE LCD MONITOR ........................................................................................... 11
How to operate the OSD menu ...................................................................................... 11
Leaving the OSD menu................................................................................................. 12
OSD Menu .................................................................................................................. 12
Brightness / Contrast ................................................................................................. 12
Image control ........................................................................................................... 12
Color ....................................................................................................................... 13
OSD Control ............................................................................................................. 13
Other ...................................................................................................................... 13
Reset....................................................................................................................... 13
SAVING ENERGY ............................................................................................................ 14
USB CONNECTIONS ON THE MONITOR STAND (OPTIONAL) ................................................. 14
Advertisement
Table of Contents
Related Manuals for Medion LCD Monitor
Summary of Contents for Medion LCD Monitor
-
Page 1: Table Of Contents
Connecting Audio Cable .................... 9 Connecting the Power Supply..................9 Positioning of the Monitor ....................9 CONTROLS........................11 SETTING THE LCD MONITOR ................... 11 How to operate the OSD menu ..................11 Leaving the OSD menu....................12 OSD Menu ........................12 Brightness / Contrast .................... - Page 2 Medion ® assumes no responsibility for the use or reliability of its software on equipment that is not furnished by Medion ® This document contains proprietary information that is protected by copyright. All rights are reserved. No part of this document may be photo- ®...
-
Page 3: Safety Instruction
LCD monitor. Always keep these instructions handy and close by your LCD monitor. Keep the instructions and the packaging so that if you sell or give a- way your LCD monitor you can give them to the new owner. -
Page 4: Setting Up Location
• If you use an extension cable, ensure that it fulfills the VDE requirements. Please ask your electrician. • You should lay the LCD Monitor cables in a manner that no one can trip or step on it. • To avoid damage of cable do not place any objects or furniture on the cable. -
Page 5: Standards/Electro-Magnetic Compatibility
Maintenance and care You can increase the service life of your LCD monitor by taking the following precautions: Caution! There are no parts which can be serviced or cleaned inside of the monitor housing. -
Page 6: Fcc Compliance Statement
Shielded interface cables, if any, must be used in order to comply with the emission limits. Declaration of Conformity According to 47CFR, Parts 2 and 15 for Class B Personal Computers: Medion Aktiengesellschaft____________ (Name of the Responsible Party) Located at: Gänsemarkt 16 – 18_________________ D-45127 Essen_____________________... -
Page 7: Introduction
Quality We focused on great features, ease of use and reliability in manufacturing your LCD monitor. The balanced hardware and software concept offers you an advanced display design which will provide you a great deal of pleasure for your work and entertainment. -
Page 8: Start-Up
If you have operated your computer previously with a CRT monitor, it will be necessary for you to make a few preparations. This is required when your previous monitor was operated with settings which are not supported by your new LCD monitor. Supported Monitor Settings... -
Page 9: Display Properties
Display Properties This Windows program offers you the possibility of adapting the display to your monitor. This includes items such as the background image, the screen saver, the Active Desktop (Web) as well as other set- tings for your monitor and video card. The program can be started as follows: •... -
Page 10: Unpacking
We recommend that you also read all the other sections as these contain detailed explanations and tips on how to use your LCD display. 1. Ensure that the LCD monitor is not yet connected to the line power (power cord not yet plugged in) and neither the LCD monitor nor the computer is switched on. -
Page 11: Connecting Vga Signal Cable
Connecting VGA Signal Cable 3. Plug the signal cable into the matching VGA sockets on the computer. If your PC features a DVI port, you can connect your monitor by means of the DVI plug. Connecting Audio Cable 4. Plug the audio cable into the matching sockets on the computer. Connecting the Power Supply 5. - Page 12 (similar picture) • Hand’s support rest: 2” – 4” • Top line of screen should keep eye’s level or be a little beneath • Eye’s distance to screen: 20” – 28” • Legroom (vertical): at least 26” • Legroom (horizontal): at least 24” N N G G L L I I S S H H...
-
Page 13: Controls
• Executing it directly raises the volume Increase volume On/Off switch • With this switch you can switch the LCD monitor ON and OFF Operation indicator • Indicates the operating state. Blue = Normal mode, Orange = Stand-by mode. MENU OSD •... -
Page 14: Leaving The Osd Menu
Leaving the OSD menu To exit the OSD menu you have different possibilities: • Choose Exit • The OSD vanishes from the screen automatically, when you do not press any key on the monitor during the preset time interval (factory setting is 10 seconds). OSD Menu The following will introduce the main functions and settings of the OSD. -
Page 15: Color
Color • 9300K / 6500K Set one of the preset values using the < and > keys. • Custom color Select this option using the MENU key, if you want to set the values for red, green and blue individually. The new values will be saved automatically on exiting this menu item. OSD Control •... -
Page 16: Saving Energy
Saving Energy This monitor can be switched into various states of energy saving by the respective computer or operating system. This meets the current requirements for reduction of power consumption. The monitor supports the following states of low energy consumption: Status Power consumption Color of the... -
Page 17: Service
Service Troubleshooting If your LCD monitor should have problems please check if it is properly installed and plugged ac- cording to the information given in the “Start-Up” section beginning on page 6). If the problems cannot be solved, read the following chapter for possible solution. -
Page 18: Do You Require Additional Support
The display is too light or too dark: • Check that the video output level of the computer matches the technical data of the monitor. • Select Auto Setup, to optimize the settings for brightness and contrast. The display should show a text page (e.g. -
Page 19: Specifications
Specifications Parameter Data Visible display size 20,1“ Resolution 1680 x 1050 (WSXGA Refresh rate max. 75 Hz Brightness 300 cd/m² (typ) Contrast 1000:1 (typ.) Viewing angle 88° / 88° (horizontal/vertikal) Refresh rate GtG 8 ms (typ.) Video input Analog (15-wired mini Sub-D ) Digital (24-wired DVI-D) User control ON/OFF... -
Page 20: Warranty
There have been several attempts in the past to define the acceptable number of defective pixels. But this can be difficult and varies widely between different manufacturers. MEDION, therefore, adheres to the clear and strict requirements of ISO 13406-2, class II, for the warranty handling of all TFT display products. These requirements are summarized below. - Page 21 Types of Pixel Failures: • Type 1: A constantly lit pixel (a bright, white spot), even though it is not addressed. A white pixel is caused when all three sub-pixel are lit. • Type 2: A pixel that does not light up (dark, black spot), although it is addressed. •...
-
Page 22: Liability Limitations
Liability limitations The contents of this manual are subject to unannounced changes caused by technical progress. Manufacturer and sales shall not be responsible for any damages which have been caused as a re- sult of omissions or errors in the information provided in this manual: 1.
