VERTICAL FLOAT SUMP PUMP
SET UP And OPERATIng InSTRUCTIOnS
Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
distributed exclusively by Harbor Freight Tools
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MAnUAL.
Copyright
2006 by Harbor Freight Tools
©
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Model
95591 - .75 HP
Model
95592 - 1 HP
Model
95593 - 1.5 HP
3491 Mission Oaks Blvd., Camarillo, CA 93011
. All rights reserved. No portion of this
®
.
®
REV 07l, 08i
Advertisement
Table of Contents
Summary of Contents for Pacific hydrostar 95591 - .75 HP
- Page 1 2006 by Harbor Freight Tools © manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. For technical questions or replacement parts, please call 1-800-444-3353. 95591 - .75 HP 95592 - 1 HP 95593 - 1.5 HP...
-
Page 2: Specifications
Motor Power Switch Type Power Plug Type Self Priming Maximum Pumping Capacity Maximum delivery Height discharge diameter Max. Operating Temperature note: Performance of these products will vary depending on variations in local line volt- age. SAVE THIS MAnUAL You will need this manual for the safety warnings and precautions, assem- bly, operating, inspection, maintenance and cleaning procedures, parts list and... -
Page 3: Work Area
WORK AREA Keep your work area clean and well lit. Cluttered benches and dark areas invite accidents. do not operate power tools in explosive atmospheres, such as in the presence of flammable liquids, gases, or dust. Power tools create sparks which may ignite the dust or fumes. -
Page 4: Specific Safety Rules
Maintain labels and nameplates on the Pump. These carry important SKU 95591/95592/95593 information. If unreadable or miss- ing, contact Harbor Freight Tools for a replacement. sonal safety devices reduce the risk for injury. Safety impact eye goggles are available from Harbor Freight Tools. - Page 5 do not pump hazardous materials. Do not pump explosive or flammable materials such as fuel, oil, kerosene, gasoline, etc. Do not pump in close proximity to flammable or explosive materials. Do not pump fats, oils, salt or waste water. This Pump is designed to move clean or dirty water only.
- Page 6 gROUndIng TO PREVEnT WARnIng ELECTRIC SHOCK And dEATH FROM InCORRECT gROUndIng WIRE COnnECTIOn: Check with a qualified electrician if you are in doubt as to whether the outlet is properly grounded. do not modify the power cord plug provided with the tool. never remove the grounding prong from the plug.
- Page 7 Double insulated tools may be used in either of the 120 volt outlets shown in the preceding illustration. (See Outlets for 2-Prong Plug.) Extension Cords Grounded tools require a three wire extension cord. Double Insulated tools can use either a two or three wire extension cord.
- Page 8 When unpacking, check to make sure all the parts shown on the Parts List on page 12 are included. If any parts are missing or broken, please call Harbor Freight Tools at the number shown on the cover of this manual as soon as possible. ASSEMBLY And OPERATIng InSTRUCTIOnS note: For additional information regarding the parts listed in the following pages, refer to the Assembly diagram on page 13.
- Page 9 TO 115 VOLT, gROUndEd gFCI OUTLET BASE (25) Connect the Discharge Pipe to the Base (25). nOTE: Make sure the Discharge Pipe is secured to a solid surface, with appropriate hardware (not included), to ensure the stability of the Pump. (See Figure E.) Install an additional union (not included) or other means of separating the Dis- charge Pipe just above the floor to facilitate removal of the Pump if necessary.
-
Page 10: Inspection, Maintenance, And Cleaning
Carefully set the Pump in place. Cord or discharge Pipe. (See Figure E.) The Float Switch (2) automatically switches on and off at a water depth of approxi- mately 4 inches. The ON/OFF height can be manually changed by adjusting the Float Switch Lock. -
Page 11: Troubleshooting
To clean the Impeller Cover and Impeller: or Impeller (28) will greatly reduce performance of the Pump. To clean the Impel- ler Cover (31), spray the Cover with clean water. To clean the Impeller, remove the nine Screws (32) at the bottom of the Base (25). Then, remove the Base to expose the Impeller Cover and Impeller. -
Page 12: Please Read The Following Carefully
PLEASE REAd THE FOLLOWIng CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. -
Page 13: Assembly Diagram
ASSEMBLY dIAgRAM For technical questions, please call 1-800-444-3353 SKU 95591/95592/95593 PAGE 13... -
Page 14: Limited 1 Year / 90 Day Warranty
LIMITEd 1 YEAR / 90 dAY WARRAnTY Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that for a period of ninety days from date of purchase that the engine/motor, the belts (if so equipped), and the blades (if so equipped) are free of defects in materials and workmanship.
