Cordless Jig Saw
MODEL 4331D
MODEL 4333D
002700
I N S T R U C T I O N
M A N U A L
WARNING:
For your personal safety, READ and UNDERSTAND before using.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

Advertisement

   Related Manuals for Makita 4331D

   Summary of Contents for Makita 4331D

  • Page 1

    Cordless Jig Saw MODEL 4331D MODEL 4333D 002700 I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.

  • Page 2: Specifications

    As a result of the extensive accessory and saw blade MAKITA INTERNATIONAL EUROPE LTD. program, the tool can be used for many purposes and is Michigan Drive, Tongwell, Milton Keynes, Bucks MK15 very well suited for curved or circular cuts. 8JD, ENGLAND Responsible manufacturer: Makita Corporation Anjo Aichi Japan...

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES GEA002-3 WARNING: Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term “power tool” in all of the warnings listed below refers to your mains-operated (corded) power tool or battery- operated (cordless) power tool.

  • Page 4: Specific Safety Rules

    the power tool. Power tools are dangerous in the GEB016-1 hands of untrained users. 20. Maintain power tools. Check for misalignment or SPECIFIC SAFETY RULES binding of moving parts, breakage of parts and any other condition that may affect the power DO NOT let comfort or familiarity with product tools operation.

  • Page 5

    IMPORTANT SAFETY INSTRUCTIONS FOR BATTERY CARTRIDGE ENC004-1 (1) Do not touch the terminals with any con- Before using battery cartridge, read all instruc- tions and cautionary markings on (1) battery ductive material. charger, (2) battery, and (3) product using bat- (2) Avoid storing battery cartridge in a con- tery.

  • Page 6: Functional Description

    FUNCTIONAL CAUTION: DESCRIPTION • Always be sure that the tool is switched off and the battery cartridge is removed before adjusting or checking function on the tool. Installing or removing battery cartridge 002702 • Always switch off the tool before insertion or removal of the battery cartridge.

  • Page 7

    002711 The tool speed can be infinitely adjusted between 500 and 2,800 (Model 4331D), 500 and 2,600 (Model 4333D) strokes per minute by turning the adjusting dial. Higher speed is obtained when the dial is turned in the direction of number 5; lower speed is obtained when it is turned in the direction of number 1.

  • Page 8

    With the blade teeth facing forward, insert the blade into the blade holder as far 002718 as it will go. Make sure that the back edge of the blade fits into the roller. Then tighten the screw clockwise to secure the blade. To remove the blade, follow the installation procedure in reverse.

  • Page 9

    Plastic base plate (optional accessory) 002735 Use the plastic base plate when cutting decorative veneers, plastics, etc. It protects sensitive surfaces from damage. To replace the base plate, remove the four screws. 1. Screw 2. Plastic base plate 3. Hex wrench Rip fence (optional accessory) 002737 When cutting widths of under 150 mm repeatedly, use of the rip fence (guide...

  • Page 10

    To attach the vacuum head on the tool, insert the hooks of the vacuum head 002741 into the hole in the base. The vacuum head can be installed on either left or right side of the base. Then connect a Makita vacuum cleaner to the vacuum head. 1. Vacuum head 2. Base 002742...

  • Page 11

    Loosen the bolt on the back of the base with the hex wrench. Move the base 002752 so that the bolt is positioned in the center of the cross-shaped slot in the base. 1. Cross-shaped slot 2. Hex wrench 3. Bolt Tilt the base until the desired bevel angle is obtained.

  • Page 12

    To maintain product SAFETY and RELIABILITY, repairs, any other mainte- nance or adjustment should be performed by Makita Authorized Service Cent- ers, always using Makita replacement parts. 1. Brush holder cap...

  • Page 13

    CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.

  • Page 14

    Memo...

  • Page 15

    Memo...

  • Page 16

    Makita Corporation Anjo, Aichi, Japan 884339C223...
