- Page 1 Cordless Impact Driver Equipped with Electric Brake MODEL BTD120 002806 I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
-
Page 2: Specifications
SPECIFICATIONS Model BTD120 Machine screw 4 mm - 8 mm (5/32” - 5/16”) Capacities Standard bolt 5 mm - 12 mm (3/16” - 1/2”) High tensile bolt 5 mm - 10 mm (3/16” - 3/8”) No load speed (RPM) 0 - 2,300/min. - Page 3 Electrical Safety Tool Use and Care 4. A battery operated tool with integral bat- 12. Use clamps or other practical way to teries or a separate battery pack must be secure and support the workpiece to a recharged only with the specified charger stable platform.
-
Page 4: Specific Safety Rules
22. When servicing a tool, use only identical SERVICE replacement parts. Follow instructions in 21. Tool service must be performed only by the Maintenance section of this manual. qualified repair personnel. Service or main- Use of unauthorized parts or failure to follow tenance performed by unqualified personnel Maintenance instructions may create a risk of may result in a risk of injury. - Page 5 SYMBOLS USD302-1 The followings show the symbols used for tool. V ....... volts .../min....revolutions or reciprocation per minute ....direct current ....number of blow ....no load speed IMPORTANT SAFETY INSTRUCTIONS FOR BATTERY CARTRIDGE ENC005-1 1. Before using battery cartridge, read all (2) Avoid storing battery cartridge in a instructions and cautionary markings on container with other metal objects...
- Page 6 3. Charge the battery cartridge with room Always stop tool operation and charge the battery cartridge when you notice less temperature at 10°C - 40°C (50°F - 104°F). tool power. Let a hot battery cartridge cool down before charging it. 2.
-
Page 7: Functional Description
Release the switch trigger to stop. Electric brake This tool is equipped with an electric brake. If the tool consis- tently fails to quickly stop after switch trigger release, have tool serviced at a Makita service center. - Page 8 Reversing switch action 001257 This tool has a reversing switch to change the direction of rotation. Depress the reversing switch lever from the A side for clockwise rotation or from the B side for counterclockwise rotation. When the reversing switch lever is in the neutral position, the switch trigger cannot be pulled.
-
Page 9: Operation
OPERATION The proper fastening torque may differ depending upon the kind or size of the screw/bolt, the material of the workpiece to be fastened, etc. The relation between fastening torque and fastening time is shown in the figures. Hold the tool firmly and place the point of the driver bit in the 002848 Standard bolt screw head. -
Page 10: Maintenance
1 minute. Then check the tool while running and elec- tric brake operation when releasing the switch trigger. If elec- tric brake is not working well, ask your local Makita service 1. Brush holder cap center for repair. -
Page 11: Recycling The Battery
EN0001-1 Recycling the Battery The only way to dispose of a Makita battery is to recycle it. The law prohibits any other method of disposal. To recycle the battery: 1. Remove the battery from the tool. Ni-Cd 2. a) Take the battery to your nearest Makita Factory Ser-... - Page 12 Memo...
- Page 13 Stamp Timbre Makita Canada Inc. 1950 Forbes Street, Whitby, Ontario L1N 7B7 Fold...
- Page 14 Your answers to the following questions are appreciated. 1. This product was purchased from? 3. How did you first learn of Makita Power Tools? Hardware/lumber Store Industrial Supply Magazine/Newspaper Catalog Tool Distributor Other ( From dealer Other ( Store display 2.
- Page 15 When you need service... DATE • Explain the problem in a letter PURCHASED: • Enclose the letter with the tool DEALER’S NAME • Package carefully and send prepaid & ADDRESS: to the nearest Makita factory or authorized service centre MODEL NO.: SERIAL NO.:...
- Page 16 WARRANTY. “The Makita Warranty is the only and the entire written warranty given by Makita for the Makita tools. No dealer or his agent or employee is authorized to extend or enlarge upon this warranty by any verbal or written statement or advertisement.”...
