TG1311_1312FX(e).book Page 1 Tuesday, August 5, 2008 7:18 PM
Model shown is KX-TG1311.
This unit is compatible with Caller ID. You must subscribe to the
appropriate service offered by your service provider/telephone
company.
(For Czech and Slovakia)
This cordless telephone is possible to use according to General
licence No.: VO-R/8/08.2005-23 (for Czech), VPR-7/2001 (for
Slovakia).
Charge the batteries for about 7 hours before initial use.
Please read these operating instructions before using the unit and
save them for future reference.
Operating Instructions
Digital Cordless Phone
KX-TG1311FX
Model No.
KX-TG1312FX
Table of Contents
Introduction ......................................................... 2
Preparation .......................................................... 6
Making/Answering Calls ................................... 11
Phonebook......................................................... 12
Useful Telephone Settings ............................... 14
Caller ID Service ................................................ 17
Multi-unit Operation .......................................... 19
Useful Information............................................. 20
PNQX1090ZA
DC0808DG0
FX-2/3
Advertisement
Table of Contents
Related Manuals for Panasonic KX-TG1311FX
Summary of Contents for Panasonic KX-TG1311FX
-
Page 1: Table Of Contents
TG1311_1312FX(e).book Page 1 Tuesday, August 5, 2008 7:18 PM Operating Instructions Digital Cordless Phone KX-TG1311FX Model No. KX-TG1312FX Table of Contents Introduction ............2 Preparation ............6 Making/Answering Calls ........11 Model shown is KX-TG1311. Phonebook............12 Useful Telephone Settings ....... 14 Caller ID Service .......... -
Page 2: Introduction
KX-TG1312 KX-TG1311 KX-TGA131 Declaration of Conformity: L Panasonic Communications Co., Ltd. declares that this equipment is in compliance with the essential requirements and other relevant provisions of Radio & Telecommunications Terminal Equipment (R&TTE) Directive 1999/5/EC. Declarations of Conformity for the relevant Panasonic products described in this manual are available for download by visiting: http://www.doc.panasonic.de... - Page 3 L Replace batteries only with a nickel metal hydride (Ni-MH) type of battery. This model requires 2 AAA (R03) batteries for every handset. For best performance, we recommend using Panasonic rechargeable batteries (Model No. P03P or HHR-4MRE). L Replacement batteries may have a different capacity from that of the...
-
Page 4: Important Information
TG1311_1312FX(e).book Page 4 Tuesday, August 5, 2008 7:18 PM Introduction L This product should be kept away from heat sources such as radiators, cookers, etc. It should also not be placed in rooms where the Important information temperature is less than 5 °C or greater than 40 °C. Warning: General L To prevent the risk of electrical shock, do not expose this product to rain... - Page 5 TG1311_1312FX(e).book Page 5 Tuesday, August 5, 2008 7:18 PM Introduction L Do not open or mutilate the battery(ies). Released electrolyte from the For proper treatment, recovery and recycling of old products and used battery(ies) is corrosive and may cause burns or injury to the eyes or batteries, please take them to applicable collection points, in accordance skin.
-
Page 6: Connections
The charger can be mounted on the wall, if required. The base unit can be mounted on the wall, if required. L Use only the supplied Panasonic AC adaptor PQLV209CE. L Use only the supplied Panasonic AC adaptor PQLV207CE. L Use only the supplied telephone line cord. Using another telephone line cord may not allow the unit to work properly. -
Page 7: Battery Installation
High L When flashing: Fully charged. Insert the batteries negative (T) end first. Close the handset cover. Medium L When flashing: Needs charging. Panasonic Ni-MH battery performance (supplied batteries) Operation Operating time In continuous use 17 hours max. Not in use (standby) - Page 8 TG1311_1312FX(e).book Page 8 Tuesday, August 5, 2008 7:18 PM Preparation Note: Controls L It is normal for batteries not to reach full capacity at the initial charge. Maximum battery performance is reached after a few complete cycles of charge/discharge (use). Handset L Actual battery performance depends on a combination of how often the handset is in use and how often it is not in use (standby).
- Page 9 TG1311_1312FX(e).book Page 9 Tuesday, August 5, 2008 7:18 PM Preparation Item Meaning Base unit Call bar is on. (page 15) A Charge contacts B {x} (Locator) Direct call is on. (page 15) Key lock is on. (page 11) Ringer volume is off. (page 14) Displayed when you press {#}.
-
Page 10: Dialling Mode
Press {v} or {e} to select the words in Enter base unit PIN (default: “0000”). i {1} quotations. L If you forget your PIN, contact your nearest Panasonic service centre. Example: {v}/{e}: “OFF” Select the desired setting by pressing {1} for tone dialling mode or {2} for pulse dialling mode. -
Page 11: Making/Answering Calls
TG1311_1312FX(e).book Page 11 Tuesday, August 5, 2008 7:18 PM Making/Answering Calls Making/Answering Calls Redial functions (redialling/storing/editing before Making calls calling/erasing) Dial the phone number. i {C} {R} i {v}/{e}: Select the desired phone number. When you finish talking, press {ih} or place the handset on the base ■... -
Page 12: Phonebook
TG1311_1312FX(e).book Page 12 Tuesday, August 5, 2008 7:18 PM Phonebook Phonebook For call waiting or Call Waiting Caller ID service users Adding entries to the phonebook To use call waiting, you must first subscribe to the call waiting service of The phonebook allows you to make calls without having to dial manually. - Page 13 TG1311_1312FX(e).book Page 13 Tuesday, August 5, 2008 7:18 PM Phonebook Making calls/editing/erasing One touch dialling (Hot key) {k} i {v}/{e}: Select the desired entry. ■ Making calls: Assigning an entry in the phonebook to a one touch dial key Dial keys {1} to {9} can each be used as a one touch dial key, allowing you ■...
-
Page 14: Useful Telephone Settings
TG1311_1312FX(e).book Page 14 Tuesday, August 5, 2008 7:18 PM Useful Telephone Settings Useful Telephone Settings Menu Sub-menu Page Guide to handset settings STANDBY MODE <CLOCK> — DISPLAY OPT To customise the handset (general approach): TALK MODE <TALK TIME> — LANGUAGE <ENGLISH> {j/OK} Press {v} or {e} to select “SETTING HS”. - Page 15 {v}/{e}: “SETTING HS” i {>} Enter the current 4-digit handset PIN. {v}/{e}: “CALL OPT” i {>} L If you forget your PIN, contact your nearest Panasonic service centre. {v}/{e}: “CALL BAR” i {>} Enter the new 4-digit handset PIN. Enter handset PIN (default: “0000”).
-
Page 16: Guide To Base Unit Settings
TG1311_1312FX(e).book Page 16 Tuesday, August 5, 2008 7:18 PM Useful Telephone Settings Code No. Feature (default setting) Guide to base unit settings Call restriction ■ Setting call restriction To customise the base unit (general approach): Enter base unit PIN (default: “0000”). i Enter {j/OK} the desired handset number by pressing the... -
Page 17: Caller Id Service
Important: *1 Only the emergency number setting is not reset. *2 If you forget your PIN, contact your nearest Panasonic service centre. L This unit is Caller ID compatible. To use Caller ID features, you must *3 The recall/flash time depends on your telephone exchange or host PBX. -
Page 18: Voice Mail Service
Enter base unit PIN (default: “0000”). i {4} company, not your telephone. L If you forget your PIN, contact your nearest Panasonic service centre. When you have new messages, 0 is displayed on the handset Select DTMF mode by pressing {2}. -
Page 19: Multi-Unit Operation
TG1311_1312FX(e).book Page 19 Tuesday, August 5, 2008 7:18 PM Multi-unit Operation Multi-unit Operation Intercom Transferring calls, conference calls Available for: Available for: KX-TG1312 KX-TG1312 Intercom calls can be made between handsets. Outside calls can be transferred between 2 handsets. 2 handsets can have a conference call with an outside party. -
Page 20: Useful Information
TG1311_1312FX(e).book Page 20 Tuesday, August 5, 2008 7:18 PM Useful Information Useful Information Problem Cause/solution Troubleshooting I cannot make or receive L The base unit’s AC adaptor or calls. telephone line cord is not connected. If you still have difficulties after following the instructions in this section, Check the connections. - Page 21 TG1311_1312FX(e).book Page 21 Tuesday, August 5, 2008 7:18 PM Useful Information Problem Cause/solution Problem Cause/solution Noise is heard, sound L You are using the handset or base unit Caller information is not L You must subscribe to a Caller ID cuts in and out.
- Page 22 Wait until “BS PIN” is displayed. i Enter the base unit PIN (default: centre. “0000”). i {>} L If you forget your PIN, contact your nearest Panasonic service centre. Caution: L When the handset has been registered successfully, w stops L To avoid permanent damage, do not use a microwave oven to speed up flashing.
-
Page 23: Specifications
TG1311_1312FX(e).book Page 23 Tuesday, August 5, 2008 7:18 PM Useful Information ■ Mass (weight): Specifications Base unit: Approx. 108 g Handset: Approx. 120 g ■ Standard: Charger : Approx. 72 g DECT (Digital Enhanced Cordless Telecommunications) *1 KX-TG1312 ■ Number of channels: 120 Duplex Channels ■... - Page 24 Copyright: web: www.panasonic.ro This material is copyrighted by Panasonic Communications Co., Ltd., and may be reproduced for internal use only. All other reproduction, in whole or in part, is prohibited without the written consent of Panasonic Communications Co., Ltd.
