- Page 1 Installation Instructions / Warranty Electronic 15180XX1 Electronic 15181XX1...
-
Page 2: Technical Data
Hansgrohe Electronic Lavatory Faucet with Temperature Control 15180XX1 Hansgrohe Electronic Lavatory Faucet 15181XX1 Technical data Max. water pressure: Recommended pressure: Hot water temperature: Recommended hot water temperature: Rate of flow: Automatic shutoff: Hole size in mounting surface: Max. mounting surface thickness Requires standard 110V electrical outlet.** *please know and follow all applicable local plumbing codes when setting the temperature on the water heater. -
Page 3: Installation
Installation Flush the hot and cold supplies thoroughly before installing this faucet. Place the faucet in the hole in the mounting surface (1). From beneath the sink, install the fiber washer, metal washer and mounting nut (). Install the adapters on the stops (3). Install the filters (4) and supply lines (5). - Page 4 Turn the water on to the faucet (1). Peel the protective film from the sensor (). Wait 15 seconds, then put a hand in front of the sensor. The water should turn on automatically. Model 15180 only: Pivot the temperature control lever forward to make the water cooler.
- Page 5 Pull the faucet housing off (1). Use a screwdriver to set the water temperature (). Turn the screw to the rear to make the water warmer, to the front to make it cooler. Replace the faucet housing. Tighten the set screw. Cleaning: Block the sensor for 5 seconds (1).
- Page 6 Faucet Maintenance Reset the faucet: Remove the set screw with a .5 mm Allen wrench. Block the sensor for seconds. Wait 10 seconds (1), then replace the set screw ().
- Page 7 Wait 15 seconds (3), then place a hand in front of the sensor (4). The water should turn on. Cleaning the filters and aerator If the flow of water is reduced, the filters and/or the aera- tor must be cleaned. To clean the aerator: Block the sensor for 5 seconds to temporarily shut off the water (1).
- Page 8 To clean the filters: Turn the water off at the stops (1). Disconnect the supply hoses from the adapters (). Pull the filters out and clean them.
-
Page 9: Replacement Parts
Replacement Parts aerator solenoid valve fixation set connection hose back flow preventor cartridge electronics AC adapter transformer 6788XX X 8854000 781000 6405000 606000 605000 760000 768001... - Page 10 Cleaning Recommendation for Hansgrohe Products Modern faucetry and shower products utilize a combination of materials to comply with the needs of the market with regard to design and functionality. To avoid damage, it is necessary to use some caution when cleaning. Damage caused by improper treatment is not covered under the Hansgrohe warranty.
-
Page 11: Limited Lifetime Consumer Warranty
Limited Lifetime Consumer Warranty his product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”). This warranty is limited to Hansgrohe products which are purchased by a consumer in the United States after March 1, 16, and installed in either the United States or Canada. WHO IS COVERED BY THE WARRANTY This warranty extends to the original consumer purchaser only. -
Page 12: Exclusions And Limitations
TO OBTAIN WARRANTY PARTS OR INFORMATION Contact your Hansgrohe retailer, or contact Technical Service at: Hansgrohe Inc. 14 Bluegrass Lakes Parkway Alpharetta GA 30004 Toll-free (800) 334-0455. In requesting warranty service, you will need to provide The sales receipt or other evidence of the date and place of purchase. A description of the problem.
