- Page 1 Installation Instructions / Warranty Axor Citterio 39020XX1...
- Page 2 Technical Information / Données techniques / Datos tecnicos Recommended water Pression d’eau recommandée Presión recomendada pressure Max. water pressure Pression d’eau maximum Recommended hot Température recommandée water temp. d'eau chaude Max. hot water temp Température maximum d'eau chaude Flow rate Capacité...
-
Page 3: Installation Considerations
Installation Considerations • For best results, Hansgrohe recommends that this unit be installed by a licensed, profes- sional plumber. • Please read over these instructions thoroughly before beginning installation. Make sure that you have all tools and supplies needed to complete the installation. -
Page 4: Installation
English Installation Place the faucet and sealing ring on the mounting surface. Install the friction washer, metal washer, and mounting nut. Tighten the tensioning screws. Install the pull rod. Connect the hoses to the stops. Use two wrenches, as shown, to prevent hose twisting. -
Page 5: Instalación
Français Installation Placez le robinet et l’anneau d’étanchéité sur la surface de montage. Installez la rondelle en fibre, la rondelle métal- lique et l’écrou de montage. Serrez l’écrou de montage. Serrez les vis de pression. Installez la tirette. Connectez les tuyaux d’arrivée sur les butées d’arrêt. -
Page 6: Install The Pop-Up Drain
English Install the pop-up drain Remove the plunger. Unscrew the flange from the tee. Unscrew the tailpiece from the tee. Wrap the tailpiece threads with Teflon tape. Install the tailpiece on the tee. Install the sealing gasket on the flange. Rest the flange in the sink outlet. - Page 7 Français Installez l’obturateur à clapet Retirez le plongeur. Dévissez la collerette du raccord en T. Dévissez la queue du raccord en T. Enveloppez les filets de la queue avec du ruban de Téflon. Installez la queue sur le raccord en T. Installez le joint d’étanchéité...
- Page 8 Replacement Parts / Pièces détachées / Repuestos 39091xx0 97466xx0 97157000 96783000 13185xx0 96923xx0 96316001 13961000 XX = finish / couleurs / acabados 00 chrome brushed nickel...
- Page 9 Cleaning Recommendation for Hansgrohe Products Modern lavatory faucets, kitchen faucets, and showers consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and returns, it is necessary to consider certain criteria when cleaning. Cleaning Materials for Faucets and Showers Acids are a necessary ingredient of cleaning materials for removing lime, however please pay attention to the following points when cleaning faucets and showers:...
- Page 10 Nettoyez vos produits de robinetterie et de douche aussi souvent que nécessaire. • Utilisez la quantité de produit nettoyant et respectez la durée recommandée par le fabricant. Ne laissez pas le produit sur les articles de robinetterie plus longtemps que nécessaire. •...
-
Page 11: Limited Lifetime Consumer Warranty
Limited Lifetime Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”). This warranty is limited to Hansgrohe products which are purchased by a consumer in the United States after March 1, 1996, and installed in either the United States or Canada. - Page 12 Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may have other rights which vary from State to State. You may be required by law to give us a reasonable opportunity to correct or cure any failure to comply before you can bring any action in court against us under the Magnuson-Moss Warranty Act.
