Contents
Preparation
Before Initial Use ......................... 2
Important Information .................. 3
Setting up .................................... 4
Cordless Telephone
Using the Telephone ................... 9
Making Calls .............................. 10
Answering Calls......................... 11
Phonebook ................................ 12
Handset Settings ....................... 16
Base Unit Settings ..................... 23
Initial Settings ............................ 24
Useful Information
Before Requesting Help ............ 26
Technical Information ................ 28
Index.......................................... 29
Guarantee ................................. 30
PLEASE READ BEFORE USE AND SAVE.
Charge the battery for about 7 hours before initial use.
Digital Cordless Phone
Operating Instructions
KX-TCD400E
Model No.
Advertisement
Table of Contents
Related Manuals for Panasonic KX-TCD400E
Summary of Contents for Panasonic KX-TCD400E
-
Page 1: Table Of Contents
Digital Cordless Phone Operating Instructions KX-TCD400E Model No. Contents Preparation Before Initial Use ......2 Important Information ....3 Setting up ........4 Cordless Telephone Using the Telephone ....9 Making Calls ......10 Answering Calls......11 Phonebook ........ 12 Handset Settings ....... -
Page 2: Before Initial Use
Dear purchaser, You have acquired a KX-TCD400E, which is a product made in regard with the Digital Enhanced Cordless Telecommunications (DECT). DECT technology is characterized by high-security protection against interceptions as well as high-quality digital transmission. -
Page 3: Important Information
Important Information Only use the power supply included with Battery Caution the product. Use only specified batteries. Do not connect the AC Adaptor to any AC Only use rechargeable batteries. outlet other than the standard AC220- Do not mix old and new batteries. 240 V. -
Page 4: Setting Up
Setting up Connection Do not connect the telephone line cord to the phone socket until the handset is fully charged. Plug in the AC adaptor and the telephone line cord in order (Switch on AC mains outlet.) Hooks LI NE Fasten the AC adaptor cord to prevent it from being disconnected. -
Page 5: Battery Charge
Setting up Battery Charge Battery Life At the time of shipment, the batteries are Battery life is dependent on use and not charged. To charge, place the conditions but in general when using fully handset on the base unit. Please charge charged Ni-MH batteries (700 mAh): the batteries for about 7 hours before Talk time: 10hrs approx. -
Page 6: Replacing The Batteries
• Do not use non-rechargeable batteries. If non-rechargeable batteries are fitted and start charging, it may cause the leakage of the battery electrolyte. Please use only Panasonic P03P(Ni-MH) or P03H(Ni-Cd) batteries. -
Page 7: Location Of Controls
Setting up Location of Controls Handset PHONEBOOK Button Receiver TALK Button Navigator Key Display REDIAL/PAUSE Button RECALL Button MENU/OK Button OFF/POWER Button Charge CLEAR Button Contact Charge Microphone HOLD Button Contact Handset Display Within range of a base unit Call BAR ON (p. 20) Out of range/ No power on base unit Direct Call ON (p. -
Page 8: Wall Mounting
Setting up Wall Mounting This unit can be mounted on a wall. - Insert screws into the wall. The centre of the screw hole should be 8 cm horizontally apart. - Connect the AC adaptor and the telephone line cord. - Arrange the wires as shown, then mount the unit. -
Page 9: Using The Telephone
Using the Telephone Power On/Off Power on Power off Press for more than Press for more than 1 second.*1 2 second.*2 *1 When button is released, the display changes to the standby mode. *2 The display goes blank. Making a Call Pre-dialling Post-dialling Phone Number... -
Page 10: Making Calls
Making Calls Redialling The last 10 numbers dialled are stored in the redial list automatically. Dialling with the Redial List Dialling the Last Number Dialled Search the desired Press REDIAL. Press Press Press TALK. REDIAL.*1 dialled item. TALK. Editing the Dialled Number in the Redial List The 1st digit of the desired dialled Press REDIAL.*1... -
Page 11: Answering Calls
Answering Calls Auto Talk If you set Auto Talk to on, you can answer the phone by lifting the handset off the base unit. Press Search/Select Search/Select Search/Select Search/Select MENU. "ON" or "OFF". "SETTING HS". "OTHER OPT". "AUTO TALK". • To exit the operation, press any time. -
Page 12: Phonebook
Phonebook You can store up to 20 caller information in the phonebook. Storing a Caller Information Phone Number Press MENU. Select Enter phone number. Press OK. (max. 24 digits)*1 "NEW PHONE". Name Enter name. Press OK.*2 (max. 9 characters)*1 • To exit the operation, press any time. - Page 13 Phonebook Editing a Caller Information The 1st digit of the desired phone Press Search/Select Select "EDIT". number blinks. PHONEBOOK.*1 desired item. <Phone Number> AND/ Number Edit the phone Press CLEAR.*2 Press OK. Move cursor. number.*3 <Name> AND/ Name Move cursor. Press CLEAR.*2 Edit the name.*4 Press OK.
- Page 14 Phonebook Storing the Phone Number into the Phonebook When Pre-dialling Phone Number Name Enter name.*2 Press OK to Press OK twice. store the number. Press OK. • To exit the operation, press any time. *1 If you need correction, press CLEAR. Digit is cleared to the left, then enter numbers. *2 To enter characters, see Character Selection on page 12.
-
Page 15: Hot Key
Phonebook Hot Key You can assign the dialling buttons 1 through 9 as hot keys. You can choose 9 phone numbers from the phonebook. Registering a Phone Number as a Hot Key Press Search/Select Search/Select Search/Select PHONEBOOK.*1 desired item. desired dialling "HOT KEY REG". -
Page 16: Handset Settings
Handset Settings : Time Alarm Before programming, please follow steps 1 to 3. You must set the clock before setting the time alarm. Press MENU. Search/Select Search/Select "SETTING HS". "TIME ALARM". Setting Alarm Time Time Search/Select Enter time. Press OK. Search/Select 4-digit "SET TIME". -
Page 17: Ringer Option
Handset Settings : Ringer Option Before programming, please follow steps 1 to 3. Press MENU. Search/Select Search/Select "SETTING HS". "RINGER OPT". Setting the Ringer Volume The choices are 6 levels and off. Search/Select Search/Select desired ringer volume. "RINGER VOL". • If "RINGER OFF"... -
Page 18: Tone Option
Handset Settings : Tone Option You can set the following sounds on or off. Key Tone "KEY TONE": Key tone will sound when you press any key, and a confirmation tone and an error tone will be heard during operation. Range Warning Alarm "RANGE ALARM": Alarm will sound when you move out of range of a base unit. -
Page 19: Display Option
Handset Settings : Display Option Before programming, please follow steps 1 to 3. Press MENU. Search/Select Search/Select "SETTING HS". "DISPLAY OPT". Selecting the Talk Mode Display Even if you select "PHONE NO", the other party’s phone number will not appear on your display when you receive calls. -
Page 20: Call Option
Handset Settings : Call Option Before programming, please follow steps 1 to 3. Press MENU. Search/Select Search/Select "SETTING HS". "CALL OPT". Call BAR On/Off This allows you to make an emergency call. 4-digit Handset PIN Search/Select Search/Select "ON" or "OFF".*2 "CALL BAR". -
Page 21: Other Options
The factory preset is 0000. Once you have programmed the handset PIN, you cannot confirm it. We recommend you write down the handset PIN. If you forget it, please consult our Panasonic Customer Care Helpline. U.K. 08700 100 076 R.O.I. 01289 8333 Search/Select Press MENU. -
Page 22: Key Lock
Handset Settings Key Lock You can lock the handset dialling buttons. Only incoming calls are accepted while the key lock is on. The key lock is cancelled if the handset is turned off. When the key lock is on, emergency calls cannot be made until key lock is cancelled. -
Page 23: Base Unit Settings
The factory preset is 0000. Once you have programmed the base unit PIN, you cannot confirm it. We recommend you write down the base unit PIN. If you forget it, please consult our Panasonic Customer Care Helpline. U.K. 08700 100 076 R.O.I. 01289 8333... -
Page 24: Initial Settings
Initial Settings : Reset Handset Settings You can reset all of the handset settings to their initial settings. 4-digit Handset PIN Press MENU. Search/Select Search/Select "SETTING HS". "RESET HS". Search/Select "YES" or "NO". • To exit the operation, press any time. *1 The factory preset is 0000. - Page 25 Initial Settings Reset Base Unit Settings "INPUT CODE" Press MENU. Press 0. Search/Select "SETTING BS". 4-digit Base Unit PIN Press OK. • To exit the operation, press any time. *1 The factory preset is 0000. Base Unit Initial Settings Function Initial Setting Earth/Time Break Recall Time Break Recall...
-
Page 26: Before Requesting Help
Before Requesting Help If you experience any problems with the normal use of your apparatus, you should unplug it from the telephone outlet and connect a known working telephone in its place. If the known working telephone still has problems, then please contact the customer service department of your Network provider. - Page 27 Before Requesting Help Problem Possible cause Solution • • Last number redial does not Number exceeded 24 digits. Redial manually. work. • • icon flashes. Battery low. Recharge batteries. • • icon is disappeared. Wrong battery type Set the correct battery type. selected.
-
Page 28: Technical Information
Connections: The telephone will not work during a power failure. We therefore recommend you use a standard telephone and T Adaptor to connect this Digital Cordless Phone to the line. Your Panasonic Sales Shop can offer you more information about connection possibilities. -
Page 29: Index
Index AC Adaptor .......... 2, 4 Range Warning Alarm ......18 Accessories..........2 Recall ............. 22 Answering Calls ........11 Receiver Volume ........11 Auto Talk ..........11 Ringer Pattern........17 Ringer Volume ........17 Base Unit Initial Settings........25 Setting up.......... -
Page 30: Guarantee
8. The guarantee period applicable to this product shall be 12 months. Please keep these Operating Instructions with your receipt. Panasonic Business Systems U.K. Receipt No. Date of Purchase Model No. KX-TCD400E... - Page 32 Hereby, Panasonic Communications Co., Ltd., declares that this Dect Cordless Telephone is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. A copy of the manufacturer’s declaration of conformity to the essential requirements of the R&TTE Directive is available at the following web address: http://doc.panasonic-tc.de...
