A4Tech MeetingMan G10-770L User Manual page 18

Usage:
Press and hold the gesture button to draw any of 16 lines and directions as shown on the right,
then release the button. The corresponding commands will be executed immediately, including
Keyboard, Mouse, Hyperlink, Office, Text, Multimedia, Internet and Key Setting Reminder,
which can be preset and store to your receiver memory.
Example 1:
Using as "Zoom In" command by default, when you are viewing a picture with ACDSee, or browsing a PPT file in the
Office, or Reading a PDF file...etc, just pressing the "Gesture Button" and draw the line as shown below, then release the
button, the picture or the document will be zoomed in immediately.
Example 2:
See the contrast in EXCEL after drawing the line.
Now let's take " " as example to show you how to use these functions：
1. Select " " icon to represent "Zoom In" as shown:
2. Click " " to close the setup screen.
3. Click " " to save to receiver's memory.
4. Draw the line in Excel.
a. Start: Press the "Gesture Button"
b. Track of the drawing line: Draw the line as the
c. End: Release the "Gesture Button"
d. Then the picture has been zoomed in.
- 17 -
Diagrams of 16 mouse
gestures
arrow direction.
