REPAIR PARTS

Rail Assembly Parts

1
2 3
6

Installation Parts

1
4
6
7
10
11
12
4
3
2
5
6
8
9
14
13
5
KEY PART
NO. NO.
1 41A4795
2 12B569-1
3 12B569-2
4 81C168
5 41C4677
6 1D4828-1
7 41A4836
8 25C20
KEY PART
NO. NO. DESCRIPTION
1 41A5273-1 Multi-function door control
2 41A4166 Lighted door control button
3 41A2828 Emergency release rope & handle
4 971LMC 1-button remote control
5 973LMC 3-button remote control
6 10A20 3V 2032 Lithium battery (1 required)
7 29B137 Visor clip
8 41A5047 Door bracket w/clevis pin & fastener
9 178B34 Straight door arm section
10 41A4353 Header bracket w/clevis pin & fastener
11 41A5034 Safety sensor kit: receiving and sending
eyes with 3' 2-conductor bell wire
attached
12 41A5266-1 Safety sensor bracket
13 41B4494-1 2-Conductor bell wire: white & white/red
14 178B35 Curved door arm section
NOT SHOWN
41A4675-7 Installation hardware bag (see page 3)
114A2485 Owner's manual
33
7
8
DESCRIPTION
Hardware bag (includes
sprocket coupling)
Left rail bracket
Right rail bracket
Rack
Complete trolley assembly
Screw Drive one-piece rail
Drive sprocket kit
Sprocket coupling
