- Page 1 OWNER’S MANUAL REFRIGERATOR Please read this owner's manual thoroughly before operating and keep it handy for reference at all times. GR-C267FSN GR-B267FSN www.lg.com P/No. : MFL66986009...
-
Page 2: Table Of Contents
Table of contents Introduction Entry Basic safety precautions Identification of parts Installation Where to install Door removal Door replacement Height adjustment Operation Starting Adjusting the temperatures and functions Door Ice Maker Refreshment center (Applicable to some models only) Shelf Folding Shelf Egg box Deodorizer Fresh compartment... -
Page 3: Introduction
Introduction Entry The model and serial numbers are found on the inner case or Right side of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. - Page 4 Introduction WARNING To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety precautions should be followed, including the following. Read all instructions before using this appliance. 1. When connecting the power The dedicated outlet should be used. •...
- Page 5 Introduction Do not pull out the cord or touch the power plug with wet hands. It may cause electric shock or injury. Remove water or dust from the power plug and insert it with the ends of the pins securely connected. Dust, water or unstable connection may fire or electric shock.
- Page 6 Introduction 2. When using the refrigerator Do not place the heavy object or the dangerous object (container with liquid) on the refrigerator. It may be dropped to cause injury, fire or electric shock when opening or closing the door. Do not install the refrigerator in the wet place or the place which water or rain splashes.
- Page 7 Introduction Do not use the combustible spray near the refrigerator. It may cause fire. Install in places away from the fire such as the place where flammable gas is leaked. It may cause fire. Do not place flower vase, cup, cosmetics, medicine or any container with water on the refrigerator.
- Page 8 Introduction Do not spray water at the outside or the inside of the refrigerator or do not clean it with benzene or thinner. Deterioration of insulation of electric parts may cause electric shock or fire. Service When any strange smell or smoke is detected from the center refrigerator, disconnect the power plug immediately and contact to the service center.
- Page 9 Introduction Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
- Page 10 Introduction Do not touch food or containers at the freezer with wet hands. It may cause frostbite. Do not put ice in thin crystal cup or ceramic ware. It may break cup or ceramic ware to cause injury. When the electricity is off, remove ice from the ice bucket (only for the model with the dispenser).
-
Page 11: Identification Of Parts
Introduction Because opening or closing the door or the home bar of the refrigerator may cause injury to the person around it, be careful, please. Opening or closing the door may cause feet or hands to be caught in the chink in door or the child to be get hurt by the corner. -
Page 12: Installation
Installation Where to Install Select a good 1. Place your appliance where it is easy to location use. 2. Avoid placing the unit near heat sources, direct sunlight or moisture. 3. To ensure proper air circulation around the fridge -freezer, please maintain sufficient space on both the sides as well as top and maintain at least 2 inches (5 cm) from the rear wall. -
Page 13: Door Replacement
Installation Remove the 1) Removing the hinge cover by loosening the Hinge cover Connection freezer screws. Separate all connection wires. wires compartment door Upper hinge Ground Line Upper hinge Keeper 2) Remove the keeper by rotating it counter clockwise ( ) and then lifting the upper hinge up ( ). -
Page 14: Height Adjustment
Installation Height adjustment When the floor is - When the height of the door may not be not leveled leveled when the floor is not leveled. When the freezer door is lower – Use the (-) driver or spanner to turn the groove or nut of the height adjustment screw on the left to the counterclockwise direction to level the door. - Page 15 Installation Handle removal To move the refrigerator through a house door, it may be necessary to remove the refrigerator door handles. NOTE • Handle appearance may vary from illustrations on this page. Mounting Fasteners Set Screw Allen Wrench Loosen the set screws with a 2.5 mm (3/32") Allen wrench and remove the handle.
-
Page 16: Operation
Operation Starting When your refrigerator is first installed, allow it to stabilize at normal operating temperatures for 2-3 hours prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. Adjusting the temperatures and functions Function display board NOTE Your model may not include every option. - Page 17 Operation This function save the display power Display power saving Press the buttons simultaneously and hold them for 5 seconds until the Ding sounds. All LED/LCDs will then turn ON, then OFF. When the power saving mode is activated, the display will remain off until the next time the door is opened.
- Page 18 Operation Express freezer Please select this function for prompt freezer. OFF➝ ON➝ OFF is repeated whenever pressing button. The arrow mark graphic remains at the On status when selecting Special Refrigeration On. Prompt freezer function automatically turns off after a fixed time passes. Lock This button stops operation of different button.
-
Page 19: Door Ice Maker
Operation Door Ice Maker How to freeze ice - Take out the ice tray, fill it with water, and carefully push it back in with caution not to spill. - Slowly push it all the way to the back. There is a risk of damage. - Page 20 Operation 1. Lift and take out the door basket at the top of the How to disassemble the door ice maker by holding both end sides. door ice maker 2. Hold both sides of the ice making section of the door ice maker and pull out upward.
-
Page 21: Refreshment Center (Applicable To Some Models Only)
Operation Refreshment center (Applicable to some models only) How to use the 1. Press the top central part of the Home Bar until you hear the Press until you Home Bar "Click" sound. hear the "Click" - You can save electricity because you do not have to open sound the refrigerator door. -
Page 22: Shelf
Operation Shelf How to use You can store side dish or refrigerated food on the shelf with sufficient space in between the containers. How to 1. Hold the front part of the shelf and pull it out until it disassemble gets blocked by the hooking part. -
Page 23: Egg Box
Operation Egg box You can move the egg box to wherever you want. [Type-1] [Type-2] NOTE Never use the egg box as an ice storage bin. It can be broken. • Never store the egg box in the freezer compartment or fresh compartment. •... -
Page 24: Fresh Compartment
Operation Fresh compartment How to use You can store fruits or vegetables. How to 1. Hold the front handle of the fresh compartment and pull disassemble the it out until it gets blocked by the hooking part. upper fresh compartment 2. -
Page 25: Air Tight Vegetable Compartment
Operation Air tight vegetable compartment You can store vegetables or fruits freshly for a long period of time. How to use - In the middle air tight compartment, you can store the vegetable or fruit for a longer period of time with the improved seal and vacuum effect. 1. -
Page 26: Freezer/Fridge Basket
Operation Freezer/Fridge basket How to use You can store small packaged frozen food (Freezer basket), small packaged refrigerated food or beverages (Fridge basket) such as milk, beer etc. But, do not store ice cream or food to store for a long period of time (Freezer basket) etc. -
Page 27: Suggestion On Food Storage
Suggestion on food storage Location of foods (Refer to identification of parts) Freezer Store various frozen foods such as meat, fish, compartment ice cream, frozen snacks, etc.. shelf Store small packed frozen food. Freezer Temperature is likely to increase as door compartment opens. -
Page 28: Storing Foods
Suggestion on food storage Storing foods Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, and melons. -
Page 29: Care And Maintenance
Care and maintenance General information During average length vacations, you will probably find it best to leave the refrigerator Vacation time in operation. Place freezable items in freezer for longer life. When you plan not to operate, remove all food, disconnect the power cord, clean the interior thoroughly, and leave each door OPEN to prevent odor formation. -
Page 30: Trouble Shooting
Care and maintenance Trouble shooting Before calling for service, review this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Occurrence Possible cause Solution Runing of refrigerator... - Page 31 Care and maintenance 0 Suggestion on food storage Occurrence Possible cause Solution Refrigerator Thermostat is keeping the refrigerator This is normal. The refrigerator goes on compressor at a constant temperature. and off to keep the temperature constant. does not run. Temperatures are too cold Temperature in the...
- Page 32 Care and maintenance Possible cause Solution Occurrence Sound and noise Louder sound Today’s refrigerators have increased It is normal for sound levels to be higher. levels when storage capacity and maintain more refrigerator is on. even temperatures. Louder sound Refrigerator operates at higher pressures This is normal.
- Page 33 Care and maintenance Occurrence Possible cause Solution Odors in refrigerator Clean interior with sponge,warm water Interior needs to be cleaned. and baking soda. Cover food completely. Food with strong odor is in the refrigerator. Some containers and wrapping materials Use a different container or brand of produce odors.
-
Page 34: It Is Normal
Care and maintenance It is Normal... The following occurrences are normal. Occurrence Solution Noise This is the sound of various parts expanding/contracting When you hear "Tak" or "Took" sound or various control devices operating depending on the temperature change within the refrigerator. When you hear This is the count of compressor or fan operating when "Deureureuk~", "Dulkuk"... - Page 35 Printed in Korea 韩国庆南昌原市加音丁洞391-2...
