Electrical Connections (In the UK Only) The wires in this mains lead are coloured in accordance with the following code : GREEN AND YELLOW : EARTH BLUE : NEUTRAL BROWN : LIVE This appliance must be earthed As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows : The wire which is coloured Green and Yellow must be connected to the terminal in the plug which is marked with the letter E or by the earth symbol(b) or coloured...
Introduction Entry The model and serial numbers are found on the inner case or back of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase.
DANGER : Risk of child entrapment. Before you throw away your old refrigerator or freezer : Take off the doors Leave the shelves in place so that children may not easily climb inside. The appliance is not intended for use by young children or infirm persons without supervision.
Door removal Electric Shock Hazard Disconnect electrical supply to refrigerator before installing. Failure to do so could result in death or serious injury. If your access door is too narrow for the refrigerator remove the refrigerator door and pass the refrigerator laterally. Remove the lower cover by lifting upward.
Installation Door replacement Mount them in the reverse sequence of removal after they pass through the access door. Height adjustment Level the door by inserting flat ( - type) driver into the groove of the left height adjusting screw and rotate it to the arrow direction ( Level the door by inserting flat ( - type) driver into the groove of the right height adjusting screw and rotate it to the arrow direction ( The refrigerator doors will close smoothly by heightening the front side by adjusting...
Operation Starting When your refrigerator is first installed, allow it to stabilize at normal operating temperatures for 2-3 hours prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. Adjusting the temperatures and functions...
Operation You can adjust temperature of and freezer room and refrigerator room. ❇ Whenever pressing button, setting is repeated in the order of (Middle) ➔ (Middle Strong) ➔ (Strong) ➔ (Weak) ➔ (Middle Weak). The actual inner temperature varies depending on the food status, as the indicated setting temperature is a target temperature, not actual temperature within refrigerator.
Door open warning 3 times of warning sounds at the interval of 30 seconds if a minute passes with the door of refrigerator and the hombar door opened or completely closed. Please contact with the local service center if warning continue to sound even after closing the door.
Operation Refreshment center (Applicable to some models only) Open the refreshment center door. You can access the refreshment center without opening refrigerator door and thus saving electricity. Inner lamp is lit in refrigerator compartment when the refreshment center door opens. Thus it is easy to identify the contents.
Shelf (Applicable to some models only) You can store taller items such as a gallon container or bottles by simply pushing in front half of shelf underneath back half of shelf. Pull toward you to return to a full shelf. Wine holder (Applicable to some models only) Bottles can be stored laterally with this wine corner.
Operation Egg box (Applicable to some models only) You can move the egg box to wherever you want. Never use the egg box as an ice storage bin. It can be broken. • Never store the egg box in the freezer compartment or fresh compartment. •...
Deodorizer (Applicable to some models only) This system efficiently absorbs strong odors by using the optical catalyst. This system does hot have any affect on stored food. Since it is installed already installed onto the cool air intake duct from the from the refrigerator compartment, you need no separate installation.
Suggestion on food storage Location of foods (Refer to identification of parts) Store wine. Store small foods such as bread, snacks, etc.. Store various frozen foods such as meat, fish, ice cream, frozen snacks, etc.. Store small packed frozen food. Temperature is likely to increase as door opens.
Storing foods Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, and melons.
Care and maintenance How to dismantle parts Dismantling is done in the reverse sequence of assembly. • Be sure to unplug the power plug before dismantling and assembly. Never apply severe force to dismantle parts. Parts may be damaged. Separate the lamp by pulling it out (➂) while slightly striking (➀) and rotating (➁) the lamp cover.
Care and maintenance General information During average length vacations, you will probably find it best to leave the refrigerator in operation. Place freezable items in freezer for longer life. When you plan not to operate, remove all food, disconnect the power cord, clean the interior thoroughly, and leave each door OPEN to prevent odor formation.
Temperatures are too cold Freezer control is set too cold Refrigerator control is set too cold. Refrigerator control is set too cold. Meat should be stored at temperature just below the freezing point of water (32 ˚ F, 0 ˚ C) for maximum fresh storage time. Temperatures are too warm Freezer control is set too warm.
Page 22
Care and maintenance Sound and noise Today’s refrigerators have increased storage capacity and maintain more even temperatures. Refrigerator operates at higher pressures during the start of the ON cycle. Floor is uneven or weak. Refrigerator rocks on the floor when it is moved slightly.
Page 23
Odors in refrigerator Interior needs to be cleaned. Food with strong odor is in refrigerator. Some containers and wrapping paper produce odors. Opening/Closing of doors/Drawers Food package is keeping door open. Door was closed too hard, causing other door to open slightly. Refrigerator is not level.
