- Page 1 OWNER’S MANUAL REFRIGERATOR Please read this owner's manual thoroughly before operating and keep it handy for reference at all times. GR-M317SGKR www.lg.com P/No. : MFL67604002...
-
Page 2: Table Of Contents
Table of contents Introduction Entry Basic safety precautions Identification of parts Installation Where to install Door removal Door replacement Height adjustment Operation Starting Adjusting the temperatures and functions Fresh Air Filter Smart Eco Door Door Ice Maker Shelf Dairy corner Egg box Deodorizer Freezer/Fridge basket... -
Page 3: Introduction
Introduction Entry The model and serial numbers are found on the inner case or Right side of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase. - Page 4 Introduction WARNING To reduce the risk of fire, electric shock, or injury to persons when using your product, basic safety precautions should be followed, including the following. Read all instructions before using this appliance. 1. When connecting the power The dedicated outlet should be used. •...
- Page 5 Introduction Do not pull out the cord or touch the power plug with wet hands. It may cause electric shock or injury. Remove water or dust from the power plug and insert it with the ends of the pins securely connected. Dust, water or unstable connection may fire or electric shock.
- Page 6 Introduction 2. When using the refrigerator Do not place the heavy object or the dangerous object (container with liquid) on the refrigerator. It may be dropped to cause injury, fire or electric shock when opening or closing the door. Do not install the refrigerator in the wet place or the place which water or rain splashes.
- Page 7 Introduction Do not use the combustible spray near the refrigerator. It may cause fire. Install in places away from the fire such as the place where flammable gas is leaked. It may cause fire. Do not place flower vase, cup, cosmetics, medicine or any container with water on the refrigerator.
- Page 8 Introduction Service center When any strange smell or smoke is detected from the refrigerator, disconnect the power plug immediately and contact to the service center. It may cause fire. Do not allow any person except the qualified engineer to disassemble, repair or alter the refrigerator. It may cause injury, electric shock or fire.
- Page 9 Introduction Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. Do not damage the refrigerant circuit. Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
- Page 10 Introduction Do not touch food or containers at the freezer with wet hands. It may cause frostbite. Do not put ice in thin crystal cup or ceramic ware. It may break cup or ceramic ware to cause injury. When the electricity is off, remove ice from the ice bucket (only for the model with the dispenser).
-
Page 11: Identification Of Parts
Introduction Because opening or closing the door or the home bar of the refrigerator may cause injury to the person around it, be careful, please. Opening or closing the door may cause feet or hands to be caught in the chink in door or the child to be get hurt by the corner. -
Page 12: Installation
Installation Where to Install 1. Place your appliance where it is easy to Select a good location use. 2. Avoid placing the unit near heat sources, direct sunlight or moisture. 3. To ensure proper air circulation around the fridge -freezer, please maintain sufficient space on both the sides as well as top and maintain at least 2 inches (5 cm) from the rear wall. -
Page 13: Door Removal
Installation Door removal Hinge cover Remove the 1) Removing the hinge cover by loosening the screws. Separate all connection wires. freezer Connection compartment wires Upper door hinge 2) Remove the keeper by rotating it counter clockwise ( ) and then lifting the upper Upper hinge Keeper hinge up ( ). -
Page 14: Height Adjustment
Installation Height difference Height adjustment When the floor is - When the height of the door may not be not leveled leveled when the floor is not leveled. When the freezer door is lower – Use the spanner to turn the nut of the height adjustment screw on the left to the counterclockwise direction to level the door. -
Page 15: Operation
Operation Starting When your refrigerator is first installed, allow it to stabilize at normal operating temperatures for 2-3 hours prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. Adjusting the temperatures and functions Function display board Refreshment Center... - Page 16 Operation You can adjust temperature of and freezer room and refrigerator room. Freezer Freezer Compartment temperature adjustment control Setting temperature Refrigerator Refrigerator Compartment temperature adjustment control Setting temperature The actual inner temperature varies depending on the food status, as the indicated setting temperature is a target temperature, not actual temperature within refrigerator.
- Page 17 Operation Use fast freezing to store foods such as meat at optimal -35°C Fast freezer storage conditions. You can quickly freeze foods in the separated drawer. The “Express freezer”, “-35°C Fast freezer”, ”Off” is set off by pressing the button. -35°C Fast -35°C Fast freezer ON...
-
Page 18: Fresh Air Filter
Operation Fresh Air Filter Fresh Air Filter provides the antibacterial function of removing virus or bacteria as well Fresh Air Filter as the deodorizer function of removing the odor within the refrigerator. The performance test of the Fresh Air Filter has been done and proved through a public certification organization ( Intertek •... - Page 19 Operation Install the new filter. How to install the new filter - Insert the new Fresh Air Filter in the filter cover so that the white part of the filter and the BACK label is visible. Be careful not to switch the direction of the Fresh Air CAUTION Filter inserted on the filter cover.
-
Page 20: Smart Eco Door
Operation Smart Eco Door Press until you hear Press the mid left part of the Smart Eco Door Using the Smart the "Click" Eco Door until you hear a click sound. sound • You can store more food in the larger Smart Eco Door. -
Page 21: Door Ice Maker
Operation Door Ice Maker How to freeze ice - Take out the ice tray, fill it with water, and carefully push it back in with caution not to spill. - Slowly push it all the way to the back. There is a risk of damage. How to use ice - Be careful for overflow, and level line... - Page 22 Operation 1. Lift and take out the door basket at the top of the How to disassemble the door ice maker by holding both end sides. door ice maker 2. Hold both sides of the ice making section of the door ice maker and pull out upward.
-
Page 23: Shelf
Operation Shelf How to use You can store side dish or refrigerated food on the shelf with sufficient space in between the containers. How to 1. Hold the front part of the shelf and pull it out disassemble until it gets blocked by the hooking part. 2. -
Page 24: Egg Box
Operation Egg box You can move the egg box to wherever you want. [Type-1] [Type-2] CAUTION NOTE Never use the egg box as an ice storage bin. It can be broken. • Never store the egg box in the freezer compartment or fresh compartment. •... -
Page 25: Fresh Compartment
Operation Fresh compartment You can store fruits or vegetables. How to use 1. Hold the front handle of the fresh compartment and pull How to disassemble the it out until it gets blocked by the hooking part. upper fresh compartment 2. -
Page 26: Fresh Compartment
Operation V Fresh compartment How to use Keep Vegetables and Fruits Fresh Longer. - Store vegetables and fruits in the bigger vegetable drawer with enhanced sealing capability. The new Magic Crisper feature can maintain the vegetable drawer in optimal humidity by absorbing moisture when humidity is high and releasing moisture when humidity is low. -
Page 27: Suggestion On Food Storage
Suggestion on food storage Location of foods (Refer to identification of parts) Freezer Store various frozen foods such as meat, fish, compartment ice cream, frozen snacks, etc.. shelf Store small packed frozen food. Freezer Temperature is likely to increase as door compartment opens. -
Page 28: Storing Foods
Suggestion on food storage Storing foods Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, and melons. -
Page 29: Care And Maintenance
Care and maintenance General information During average length vacations, you will probably find it best to leave the refrigerator Vacation time in operation. Place freezable items in freezer for longer life. When you plan not to operate, remove all food, disconnect the power cord, clean the interior thoroughly, and leave each door OPEN to prevent odor formation. -
Page 30: Trouble Shooting
Care and maintenance Trouble shooting Before calling for service, review this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Occurrence Possible cause Solution Runing of refrigerator... - Page 31 Care and maintenance Occurrence Possible cause Solution Refrigerator Thermostat is keeping the refrigerator This is normal. The refrigerator goes on compressor at a constant temperature. and off to keep the temperature constant. does not run. Temperatures are too cold Temperature in the Set the freezer control to a warmer Freezer control is set too cold freezer is too cold...
- Page 32 Care and maintenance Possible cause Solution Occurrence Sound and noise Louder sound Today’s refrigerators have increased It is normal for sound levels to be higher. levels when storage capacity and maintain more refrigerator is on. even temperatures. Louder sound Refrigerator operates at higher pressures This is normal.
- Page 33 Care and maintenance Occurrence Possible cause Solution Odors in refrigerator Clean interior with sponge,warm water Interior needs to be cleaned. and baking soda. Cover food completely. Food with strong odor is in the refrigerator. Some containers and wrapping materials Use a different container or brand of produce odors.
-
Page 34: It Is Normal
Care and maintenance It is Normal... The following occurrences are normal. Occurrence Solution Noise This is the sound of various parts expanding/contracting When you hear "Tak" or "Took" sound or various control devices operating depending on the temperature change within the refrigerator. When you hear This is the count of compressor or fan operating when "Deureureuk~", "Dulkuk"... -
Page 35: Product Information
Care and maintenance Product information Model GR-M317SGKR Producer LG Electronics Category Refrigerator-Freezer Capacity (l) ISO Gross Total Freezer Refrigerator ISO Storage Total Freezer Refrigerator Weight (kg) Net / Packing 147/161 Width x Height x Depth Product 912 x 1785 x 915... - Page 36 LG Customer Information Center LG Twin Tower, 20, Yoido-Dong, Printed in Korea Youngdungpo-Gu, Seoul, 150-721, Korea.
