Braeburn Builder 1010 User Manual

MODEL
1010
USER MANUAL
Compatible with low voltage single stage gas,
oil or electric heating or cooling systems,
including single stage heat pumps. Do not use
this thermostat on applications with voltages
above 30 Volts AC.
READ ALL INSTRUCTIONS BEFORE PROCEEDING
CONTENTS

SPECIFICATIONS

1
2 INSTALLATION
3 TESTING YOUR NEW THERMOSTAT
PROGRAMMING USER SETTINGS
4
5 ADDITIONAL OPERATION FEATURES
TROUBLESHOOTING
6
WIRING DIAGRAMS
7
© 2004 Braeburn Systems LLC • Patents Pending • All Rights Reserved.
Builder Series
Non-Programmable
Single Stage Heat/Cool
Thermostat
Pub. No. 1010-100-005
WARNING!
Important Safety Information
• Always turn off power to the air conditioning or heating system prior to installing,
removing, cleaning or servicing thermostat.
• Read this manual thoroughly prior to installing, programming or operating
this thermostat.
• This thermostat is designed for use with a 24 Volt-AC low voltage single stage gas,
oil or electric heating or cooling systems, including single stage heat pumps.
• Do not use this thermostat on applications with voltages above 30 Volts AC.
• The system must have 24 Volt AC power present for proper system operation and control.
• Wiring must conform to all building codes and ordinances as required by local and
national code authorities having jurisdiction.
• Do not short (or jumper) across terminals on the gas valve or at the heating or
cooling system control board to test the thermostat installation. This could
damage the thermostat and void the warranty.
• Do not select COOL mode of operation if the outside temperature is below 50˚ F
(10˚ C). This could possibly damage the controlled cooling system and may cause
personal injury.
• This thermostat should only be used as described in this manual. Any other use is
not recommended and will void the warranty.
1
SPECIFICATIONS
• Electrical Rating: 24 Volt AC (18-30 Volt AC)
1 amp maximum load per terminal
2 amp total maximum load (all terminals)
• Control Range: 45˚ - 90˚ F (7˚ - 32˚ C)
• Accuracy: +/- 1˚ F (+/- .5˚ C)
• Compatibility with low voltage single stage gas, oil or electric heating or cooling
systems, including single stage heat pumps.
• Terminations: R, C, G, Y, W, O, B
1
