  • Page 2 Table of contents...

  • Page 3: Important Safety Instruction

    Entry The model and serial numbers are found on the inner case or back of refrigerator compartment of this unit. These numbers are unique to this unit and not available to others. You should record requested information here and retain this guide as a permanent record of your purchase.

  • Page 4: Identification Of Parts

    DANGER: Risk of child entrapment. Before you throw away your old refrigerator or freezer: Take off the doors but leave the shelves in place so that children may not easily climb inside. The appliance is not intended for use by young children or infirm persons without supervision.

  • Page 5: Where To Install

    Where to Install 1. Place your appliance where it is easy to use. 2. Avoid placing the unit near heat sources, direct sunlight or moisture. 3. Air must circulate properly around your appliance to ensure efficient operation. If your appliance is placed in a recessed area in the wall, allow at least a 12 Inches (30 cm) or greater clearance above the appliance and 2 inches (5 cm) or more...

  • Page 6: Door Removal

    Door removal Electric Shock Hazard Disconnect electrical supply to refrigerator before installing. Failure to do so could result in death or serious injury. If your access door is too narrow for the refrigerator to pass through, remove the Lower cover refrigerator door and pass the refrigerator laterally.

  • Page 7: Door Replacement

    Pass the refrigerator laterally through the access door as shown in the right figure. Door replacement Mount them in the reverse sequence of removal after they pass through the access door. Feed water pipe installation Automatic ice maker operation needs water pressure of 147~834 kPa (1.5~8.5 kgf/cm ) (That is, an instant paper cup (180 cc) will be fully filled within 3 sec.).

  • Page 8: Height Adjustment

    Height adjustment Level the door by inserting flat ( - type) driver into the groove of the left height adjusting screw and rotate it clockwise ( ). Level the door by inserting flat ( - type) driver into the groove of the right height adjusting screw and rotate it clockwise ( ).

  • Page 9: Adjusting The Temperatures And Functions

    Starting When your refrigerator is first installed, allow it to stabilize at normal operating temperatures for 2-3 hours prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. Adjusting the temperatures and functions...
  • Page 10 You can adjust temperature of and freezer room and refrigerator room. Whenever pressing button, setting is repeated in the order of (Middle) (Middle Strong) (Strong) (Weak) (Middle Weak). The actual inner temperature varies depending on the food status, as the indicated setting temperature is a target temperature, not actual temperature within refrigerator.
  • Page 11 The icemaker can automatically make 8 pieces of ice cubes at anyone time, approximately 80 pieces per day. However these quantities may vary according to certain conditions. E.g. the duration and amount of times the refrigerator door is opened. The Ice making proceeds ceases automatically when the ice storage bin is full. If you choose not to use the automatic ice making function, repositioned the icemaker selection switch to the off position or the on position for reselection.

  • Page 12: Door Open Warning

    Ambient temperature display window. Temperature is displayed only by –9 C ~ 49 C. ROOM TEMP Temperature less than -10 C is indicated with ‘LO’ and temperature more than 50 C is indicated with ‘HI’. Temperature may differ from the actual ambient temperature as it is monitors on the upper part of refrigerator (top of door).
  • Page 13 As demonstrated below, it displays the months left in units of 30 days until the filter replacement is required, starting from when the refrigerator power usage is authorized. After 6 months, the following sentence and will appear on the filter condition FILTER RESET HOLD 3 SEC.

  • Page 14: Wine Holder

    Shelf You can store taller items such as a gallon container or bottles by simply pushing in front half of shelf underneath back half of shelf. Pull toward you to return to a full shelf. Wine holder Bottles can be stored laterally with this wine corner. This can be attached to any shelf.

  • Page 15: Humidity Control In The Vegetable Compartment

    Egg box You can move the egg box to wherever you want. [Normal] [For Many Eggs] Never use the egg box as an ice storage bin. It can be broken. • Never store the egg box in the freezer compartment or fresh compartment. •...

  • Page 16: Location Of Foods

    Location of foods (Refer to identification of parts) Store wine. Store small foods such as bread, snacks, etc.. Store various frozen foods such as meat, fish, ice cream, frozen snacks, etc.. Store small packed frozen food. Temperature is likely to increase as door opens.

  • Page 17: Storing Foods

    Storing foods Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, and melons.

  • Page 18: How To Dismantle Parts

    How to dismantle parts Dismantling is done in the reverse sequence of assembly. • Be sure to unplug the power plug before dismantling and assembly. Never apply severe force to dismantle parts. Parts may be damaged. Separate the lamp by pulling it out ( ) while slightly striking ( ) and rotating ( ) the lamp cover.
  • Page 19 To remove the lamp cover, press the protrusion under the lamp cover to the front and then pull the lamp cover out. Turn the bulb counterclockwise. Max. 40 W bulb for refrigerator is used and can be purchased at a service center. Be sure to remove parts from the refrigerator door when removing the vegetable •...

  • Page 20: General Information

    General information During average length vacations, you will probably find it best to leave the refrigerator in operation. Place freezable items in freezer for longer life. When you plan not to operate, remove all food, disconnect the power cord, clean the interior thoroughly, and leave each door OPEN to prevent odor formation.

  • Page 21: Troubleshooting

    Trouble shooting Before calling for service, review this list. It may save you both time and expense. This list includes common occurrences that are not the result of defective workmanship or materials in this appliance. Runing of refrigerator Refrigerator control is off. Set refrigerator control.
  • Page 22 Thermostat is keeping the refrigerator This is normal. The refrigerator goes on at a constant temperature. and off to keep the temperature constant. Temperatures are too cold Set the freezer control to a warmer Freezer control is set too cold setting until the freezer temperature is satisfactory.
  • Page 23 Sound and noise Today’s refrigerators have increased It is normal for sound levels to be higher. storage capacity and maintain more even temperatures. Refrigerator operates at higher pressures This is normal. The sound will level off as during the start of the ON cycle. the refrigerator continues to run.
  • Page 24 Odors in refrigerator Clean interior with sponge,warm water Interior needs to be cleaned. and baking soda. Cover food completely. Food with strong odor is in the refrigerator. Some containers and wrapping materials Use a different container or brand of produce odors. wrapping materials.
  • Page 25 Ice has melted and frozen around auger Remove ice storage bin, and thaw and due to infrequent use, temperature the contents. Clean bin, wipe dry and fluctuations and/or power outrages. replace in proper position. When new ice is made, dispenser should operate.

  • Page 28: When Replacing Panel

    When replacing PANEL……. (Be sure to read before replacing Panel.) When replacing Panels (A, B, C, D), contact a qualified service representative to perform this operation, and follow these important steps. 1. Avoid damaging the Panel. If damaged, it may cause personal injury. 2.
