LG LAC6750R Owner's Manual

Car cd/mp3/wma receiver
Hide thumbs

Advertisement

LAC6750R_JA5ILLB
CAR CD/MP3/WMA Receiver
English
OWNER'S MANUAL
MODEL : LAC6750R
Please read this instruction booklet carefully and completely before installing, operating or
adjusting this product.
Auto-CD-/MP3-/WMA-Receiver
GERMAN
BEDIENUNGSANLEITUNG
MODELL: LAC6750R
Lesen Sie vor Anschluss, Bedienung und Einstellung dieses Gerätes die Anleitungen bitte
sorgfältig und vollständig durch.
Récepteur CD/MP3/WMA pour voiture
FRENCH
MANUEL DE L'UTILISATEUR
MODÉLE : LAC6750R
Prière de lire entièrement et attentivement ce manuel d'instruction avant de procéder à
l'installation, la mise en marche ou le réglage de cet appareil.
Receptor de CD/MP3/WMA para coche
SPANISH
MANUAL DEL USUARIO
MODELO : LAC6750R
Por favor, lea detenidamente este manual de instrucciones antes de instalar, utilizar o
ajustar este producto.
Lettore CD/MP3/WMA per auto
ITALIAN
MANUALE DELL'UTENTE
MODELLO : LAC6750R
Leggere con attenzione questo libretto prima di procedere con l'installazione, usare o
regolare questo prodotto.
P/NO : MFL38271902

Advertisement

Table of Contents
loading

  Related Manuals for LG LAC6750R

  Summary of Contents for LG LAC6750R

  • Page 1 LAC6750R_JA5ILLB CAR CD/MP3/WMA Receiver English OWNER’S MANUAL MODEL : LAC6750R Please read this instruction booklet carefully and completely before installing, operating or adjusting this product. Auto-CD-/MP3-/WMA-Receiver GERMAN BEDIENUNGSANLEITUNG MODELL: LAC6750R Lesen Sie vor Anschluss, Bedienung und Einstellung dieses Gerätes die Anleitungen bitte sorgfältig und vollständig durch.
  • Page 2: Safety Note

    ENGLISH Safety note CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT SPLIT COVER(OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with the arrowhead symbol, within an equilateral triangle is intended to alert the user about the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock.
  • Page 3 • A defective or soiled disc inserted into unit can cause sound to drop out during playback. • Handle the disc by holding its inner and outer edges. • Do not touch the surface of the unlabeled side of the disc. Do not stick paper or tape etc.
  • Page 4: Table Of Contents

    Table of contents Safety note ............2-3 Table of contents .
  • Page 5: Control Panel

    Caution • When detaching or attaching the control panel, do not press the display or control buttons. • The control buttons may not work properly if the control panel is not attached properly. If this occurs, gently press the control panel. •...
  • Page 6: Remote Control

    Remote control Number [0 - 9] Power [POWER] / Mute • CD Skip / Search Select [MENU/SEL] M M? Source [SRC] • Seek / Tune M M? Play / Pause B/X Intro Scan [SCAN] Display [DISP.] Shuffle [SHF] • MP3 Track -10 •...
  • Page 7: Installation

    Installation Basic Installation Before installing, make sure that the ignition-switch is set to Bend the claws OFF and remove the terminal of the car battery to avoid according to the thickness short-circuiting. of the dashboard 1 Remove the existing receiver unit. 2 Make the necessary connections.
  • Page 8: Connection Diagram

    Connection diagram Before connecting, make sure that the ignition switch is set to OFF, and remove the battery # terminal to avoid short circuits. To Speaker To Vehicle PHONE MUTE (ORANGE) GROUND(-) (BLACK) DIMMER (PINK) DIMMER SWITCH TO IGNITION (RED) IGNITION SWITCH TO BATTERY(+) (YELLOW) POWER ANTENNA (BLUE)
  • Page 9 From antenna To the wiring of the vehicle colors of leads. • BLACK: This lead is for the ground connection. • ORANGE: This lead is for the phone line connection. • PINK: This lead is for the dimmer line connection. •...
  • Page 10: Basic Operation

    Basic operation Turning the unit on Press MUTE/PWR (POWER/ on the remote control) or any other button. Note When you insert the CD in the CD slot, the unit turns on. Turning the unit off Press and hold MUTE/PWR and then Press and hold MUTE/PWR one more time(POWER/ on the remote control).
  • Page 11: Changing The General Settings

    Changing the general settings 1 Press and hold MENU (MENU/SEL on remote control) to enter the menus. 2 Press U U /AS or u u /PS (U U /u u on remote control) to scroll between menus. RDS y Display y Setup 3 Press I I or i i ( on remote control) and Press U U /AS or u u /PS (U U /u u on ?m m/M M?
  • Page 12: Adjusting The Sound Level

    Setup Sets the beep sound every time a button is pressed. BEEP 2nd The beep is generated when a key is long pressed. (1 sec) BEEP ALL The beep is generated when any key is pressed. DEMO ON / OFF You can change the initial indication on the display to information name.
  • Page 13: Usb Operation

    Turn right Turn left Indication Increase the volume level. Decrease the volume level. Increase the bass level. Decrease the bass level. Increase the middle level. Decrease the middle level. Increase the treble level. Decrease the treble level. Decrease the level of the left speaker(s). Decrease the level of the right speaker(s).
  • Page 14: Radio Operation

    Note The method of files recorded in a USB memory device is the same as when using a DISC. Moving to another drive When connecting this unit to Multi reader, press DRIVE/BAND to go to the next drive. (Press BAND/DRV on the remote control.) Each time you press the button, the driver modes changes.
  • Page 15: Rds Operation

    Note • Up to 18 FM stations, 6 for each of three FM bands and 6 MW(AM) stations can be stored in the memory. • When a station is stored on the preset numbers on which another station of the same band has already been preset, the previously preset station is automatically erased.
  • Page 16: Cd/Mp3/Wma Operation

    Music group Speech group Pop M, Rock M News, Affairs, Info Easy M, Light M. Sports, Education, Drama Classics, Other M Culture, Science, Varied Jazz, Country Weather, Finance, Children Nation M, Oldies Social, Religion, Phone In Folk M Travel, Leisure, Document Note RDS is only available for FM reception.
  • Page 17 1 Press SCAN. – appears on the display window. 2 Press and hold SCAN for about 2 seconds during playback. – appears on the display window. 3 Press SCAN again. – disappear from the display window and The intro scan is cacelled. Repeat The current selected tracks/files (RPT) or folder ( RPT) on the disc is played repeatedly.
  • Page 18: Troubleshooting

    Troubleshooting : Symptom / : Cause The loaded disc is of a type this unit : Correction cannot play. Check what type the disc. Power doesn’t turn on. / The unit doesn’t operate. No sound is heard. / The volume Leads and connectors are not properly level will not rise.
