- Page 1 LAC6700R_ENG CAR CD/MP3/WMA Receiver OWNER’S MANUAL MODEL : LAC6700R Please read this instruction booklet carefully and completely before installing, operating or adjusting this product. P/NO : MFL37340827...
- Page 2 Safety note CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT SPLIT COVER(OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with the arrowhead symbol, within an equilateral triangle is intended to alert the user about the presence of uninsulated dangerous voltage within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock.
- Page 3 • A defective or soiled disc inserted into unit can cause sound to drop out during playback. • Handle the disc by holding its inner and outer edges. • Do not touch the surface of the unlabeled side of the disc. Do not stick paper or tape etc.
-
Page 4: Table Of Contents
Table of contents Safety note ............2-3 Table of contents . -
Page 5: Control Panel
Control panel [SOURCE] • Traffic Announcement Repeat [RPT] • Skip / Search I I /i i [TA] Intro Scan [SCAN] • Seek/ Tune I I /i i • Programme Type [PTY] Play/Pause B/X • Auto Store [U U /AS] • Equalizer [EQ] •... -
Page 6: Installation
Battery Installation 1 Remove the battery holder with a sharp product like a ball point pen. 2 Install the battery on the battery holder. 3 Install the battery holder back into its original position. Note • Use only one CR2025 (3V) lithium battery. •... -
Page 7: Connection Diagram
Connection diagram Before connecting, make sure that the ignition switch is set to OFF, and remove the battery # terminal to avoid short circuits. To Speaker To Vehicle 1 . Violet : Rear Right + 2 . Violet/ Black Stripe : Rear Right – 3 . -
Page 8: Basic Operation
Speaker Connections REAR FRONT FRONT REAR Connecting to Auxiliary Equipment (Optional) Connect the AUDIO OUTPUT jack of this unit to RL (Rear Left) FL (Front Left) the AUDIO INPUT jack of the Auxiliary RR (Rear Right) FR (Front Right) Equipment. To AUDIO OUT To AUDIO IN To AUDIO IN... - Page 9 Selecting a source Press SOURCE repeatedly to select a source. The indicator lights up in the following order. TUNER → CD → USB → TUNER... Note You cannot select a source if is not ready. Adjusting the volume Rotate MUTE/PWR (Press VOLUME on the remote control) to adjust the sound level.
- Page 10 PI (Programme Identification) SOUND / MUTE PI SOUND : If the sound of a station with different PI is heard intermittently, the receiver mutes the sound after 1 second. PI MUTE : If the sound of a station with different PI is heard intermittently, the receiver mutes the sound right now.
-
Page 11: Radio Operation
Turn right Turn left Indication Increase the volume level. Decrease the volume level. Increase the bass level. Decrease the bass level. Increase the middle level. Decrease the middle level. Increase the treble level. Decrease the treble level. Decrease the level of the left speaker(s). Decrease the level of the right speaker(s). -
Page 12: Rds Operation
Note • Up to 18 FM stations, 6 for each of three FM bands and 6 MW(AM) stations can be stored in the memory. • When a station is stored on the preset numbers on which another station of the same band has already been preset, the previously preset station is automatically erased. -
Page 13: Cd/Mp3/Wma Operation
Note RDS is only available for FM reception. TA (Traffic Announcement) function TA reception allows the unit to switch temporarily to a Traffic Announcement from the current source (another FM station, CD, or other connected components). To switch the TA (Traffic Announcement) function on or off, press TA/PTY. •... - Page 14 Repeat The current selected tracks/files (1 RPT) or folder ( RPT) on the disc is played repeatedly. 1 Press RPT during playback. – 1 RPT appears on the display window. 2 Press and hold RPT for about 2 seconds during playback. –...
-
Page 15: Usb Operation
USB operation If the plug length of the USB device is under 10mm, the USB device may not be correctly inserted or a connection failure may occur. Playing a USB device 1 Connect one end to the USB port on your USB device and then plug the other end into your unit's USB port. -
Page 16: Troubleshooting
