- Page 1 40000160.qxd 18/09/2003 16:38 Page 1 ® Washer Dryer Instructions for use HW5513...
-
Page 2: Table Of Contents
40000160.qxd 18/09/2003 16:38 Page 2 Contents Page Introduction General delivery notes Safety notes Quick start Installation & testing Useful advice for the user Description of controls Detergent drawer Detergents, washing aids and amounts to use Programme selector The main wash Consumption data Programme Table Technical data... -
Page 3: Introduction
40000160.qxd 18/09/2003 16:38 Page 3 Introduction Please read and follow these instructions carefully and operate the machine accordingly. This booklet provides important guidelines for safe installation, use, maintainance and some useful advice for best results when using your machine. Keep all documentation in a safe place for future reference or for any future owners. -
Page 4: General Delivery Notes
A) Disconnect the plug from the mains supply. B) Turn off the water supply. C) Hoover equips all its appliances with earthing. Ensure that the mains power supply is earthed, if not, seek assistance from a qualified electrician. D) Do not touch the appliance when hands or feet are wet or damp. Do not use the appliance when bare-footed. - Page 5 40000160.qxd 18/09/2003 16:38 Page 5 K) When moving the appliance never lift it by the controls, the detergent drawer, the hoses or the power cable. To avoid damaging the door when moving the appliance never rest the door against objects e.g a trolley. L) IMPORTANT! If the appliance is installed on a carpeted floor ensure that the ventilation through the base of the appliance is not obstructed.
-
Page 6: Quick Start
40000160.qxd 18/09/2003 16:38 Page 6 Quick start Washing – Open the door by pressing the DOOR button – Select the laundry and put it in the machine – Close the door – Put detergent in the dispenser compartments. Please refer to the programme guide table within this manual. -
Page 7: Installation & Testing
40000160.qxd 18/09/2003 16:38 Page 7 Installation & testing Note: when lifting the machine always use two people to avoid injuries. Remove the machine from the packaging – close to where it will finally be positioned remembering the plug must be easily accessible after installation – and proceed as follows: On the back of the machine 1) Remove the central screw A and side screws... - Page 8 40000160.qxd 18/09/2003 16:38 Page 8 Note: we recommend you keep the transit bracket and screws to protect the machine for future transit. The Manufacturers will not be responsible for any damage to the machine caused by not following the instructions relating to releasing the transit protection. The user is responsible for all installation costs.
-
Page 9: Water Supply Requirements
40000160.qxd 18/09/2003 16:38 Page 9 If the inlet hose’s connection point is changed, check that the 3/4” threaded ferrule on the inlet hose is firmly attached to the electrovalve connector. Water supply requirements Connect the machine to the drainage system used by household sinks. THIS MACHINE MUST BE CONNECTED IN ACCORDANCE WITH THE WATER SUPPLY REGULATIONS. -
Page 10: Testing The Installation
40000160.qxd 18/09/2003 16:38 Page 10 Testing the installation Refer to the programme guide for details of how to select programmes. 1. Turn on the water supply and check for leaks from fill hoses. 2. Switch on the electricity supply. 3. Select a spin programme and then press the on/off button to start the machine. - Page 11 Blue – NEUTRAL Brown – LIVE Green and Yellow – EARTH. If the mains cord on this appliance is damaged, it must be replaced by a special cord which is only obtainable from the Hoover spares service, GIAS (01204 556111).
-
Page 12: Useful Advice For The User
ARIEL – Chosen and recommended by Hoover When we produce a new washing machine we subject it to every test possible. And one of the most important tests is the one that enables our experts to identify the most suitable detergent for solving laundry problems. -
Page 13: Description Of Controls
Mega Wash Button This option can only be utilised for cotton programmes. Hoover has designed a special wash boost system specially for Large Wash Loads – by selecting this, the volume of water within the selected wash cycle and the length of time of the programme are increased to improve the wash performance for the bigger load. -
Page 14: Detergent Drawer
40000160.qxd 18/09/2003 16:38 Page 14 PROGRAMME Selector Note: never turn the knob anti-clockwise (Turn it clockwise and do not press the on/off button before selecting the programme). The tables in the washing section describe the various programmes and illustrate the number or symbol to select for them. DRYING TIME Selector For tumble drying select the appropriate drying programme via the drying time selector. -
Page 15: Detergents, Washing Aids And Amounts To Use
40000160.qxd 18/09/2003 16:38 Page 15 Note: some forms of detergents are difficult to dispense from the drawer e.g. concentrated powders. For these, we suggest you use the recommended dispenser which is placed inside the drum. This ensures that the liquid detergent is dispersed in the drum only when needed. –... - Page 16 40000160.qxd 18/09/2003 16:38 Page 16 Special detergents – Detergents for coloureds and delicates, without added bleach, also often without any optical brightening agents, to preserve the colour. – Detergents for a thorough wash, without added bleach or enzymes, particularly suitable for handling woollen fibres. –...
- Page 17 40000160.qxd 18/09/2003 16:38 Page 17 The amount of detergent to use depends on: water hardness, depending on the hardness of the water and the type of detergent used, it is possible to reduce the amount of detergent. The softer the water supply, the less detergent is required.
-
Page 18: Programme Selector
40000160.qxd 18/09/2003 16:38 Page 18 Programme selector The washing machine has 3 different programme groups according to type of wash, temperature, spin speeds and duration for handling the various types of fabric and their level of soiling (see wash programme guide). 1. -
Page 19: The Main Wash
40000160.qxd 18/09/2003 16:38 Page 19 Main wash Auto half load The washing machine is fitted with a self adjusting water level system. This system enables the machine to use the optimum amount of water needed to wash and rinse the laundry in relation to the particular load. This results in a reduction of the water and electricity used without in any way compromising the washing and rinsing performance. - Page 20 40000160.qxd 18/09/2003 16:38 Page 20 Note: when sorting laundry – check there are no metal objects in the laundry (such as paper clips, safety pins, pins, coins etc...); In the event of a machine failure during the warranty period and foreign objects are found to be the cause of the failure a labour charge may be made for the...
- Page 21 40000160.qxd 18/09/2003 16:38 Page 21 Putting detergent in machine D) Open the drawer, choose the detergent and put in the correct amount, according to the manufacturer’s instructions and the detergent advice on page 15. Add any other laundry aids (see page 16).
-
Page 22: Consumption Data
40000160.qxd 18/09/2003 16:38 Page 22 Note: actual drying time will depend: • the materials in the load • the level of moisture in the load • the required level of drying To test the laundry for dryness: Switch the machine off via the ON/OFF button. Wait for the door locked indicator neon to go out and then open the door. -
Page 23: Programme Table
40000160.qxd 18/09/2003 16:38 Page 23 Programme guide PROGRAMME FABRIC TYPE PROGRAMME FOR DETERGENT LOAD WATER TEMP °C Whites Colourfast fabrics Intensive – heavily 90° Normal Cotton, linen, hemp soiled Coloureds Cotton, colourfast Normal soiling 60° Fast mixed fibres Coloureds Cotton, mixed fabrics Normal-Light soiling 50°... -
Page 24: Technical Data
40000160.qxd 18/09/2003 16:38 Page 24 Points to consider: When washing heavily soiled laundry it is recommended the load is reduced by about 1-1.5 kg. By doing so the laundry is allowed to circulate more freely. Energy label data based on programme 2 tested in accordance with EN60456. Technical data •... -
Page 25: Cleaning And Routine Maintenance
40000160.qxd 18/09/2003 16:38 Page 25 Cleaning and routine maintenance Do not use alcohol-based scourers and /or thinners on the outside of your washing machine, just a wipe with a damp cloth will suffice. The washing machine needs very little maintenance: –... - Page 26 40000160.qxd 18/09/2003 16:38 Page 26 Transporting or storing the appliance for long periods when appliance is not in use If the appliance is being transported or is out of use for long periods in unheated places, all remaining water must be completely removed from all hoses.
-
Page 27: Trouble Shooting
40000160.qxd 18/09/2003 16:38 Page 27 Trouble shooting What might be the cause of... Defects you can remedy yourself Before calling GIAS Service for technical advice please run through the following checklist. A charge will be made if the machine is found to be working or has been installed incorrectly or used incorrectly. -
Page 28: Power Failure
40000160.qxd 18/09/2003 16:38 Page 28 Power failure If there is a power failure the wash cycle will be interrupted, the wash programme and functions will be suspended. When the power is restored, the wash programme and functions will re-start from the same point and complete the programme. -
Page 29: Customer Service
Your Guarantee Hoover guarantees all parts of this product for 5 years from the date of purchase. During that time Hoover will replace or repair all defective parts free of charge, except for parts subject to fair wear and tear such as belts. - Page 30 40000160.qxd 18/09/2003 16:38 Page 30...
- Page 31 40000160.qxd 18/09/2003 16:38 Page 31...
- Page 32 Hoover Spares Service Tel : 01204 556111 Hoovercare To maintain your Hoover product in peak condition you may wish to take out a Hoovercare policy, which for an annual payment provides a comprehensive maintenance and repair scheme. For more information please call 08705 400 600.
