User's Guide
L1760SR
M
ake sure to read the Important Precautions before using the monitor.
Keep the User's Guide(CD) in an accessible place for furture reference.
S
ee the label attached on the monitor and give the information to your
dealer when you ask for service.

Advertisement

Table of Contents
loading

Related Manuals for LG L1760SR

Summary of Contents for LG L1760SR

  • Page 1 User’s Guide L1760SR ake sure to read the Important Precautions before using the monitor. Keep the User's Guide(CD) in an accessible place for furture reference. ee the label attached on the monitor and give the information to your dealer when you ask for service.

  • Page 2: Important Precautions

    Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
  • Page 3 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.

  • Page 4: Connecting The Display

    Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Attaching/Separating the stand base Place the monitor with its front facing downward on a soft cloth. .
  • Page 5 Connecting the Display To attach or separate the back cap To attach the back cap, fix into the 3 holes first then slide it up to fit to the upper groove. Back Cap NOTE - Cover the back cap after connecting the cables before use. (To connect the cable, see page A5 for reference.) To separate the back cap, hold the bottom part and pull it out.

  • Page 6: Connecting With The Pc

    Connecting the Display Connecting with the PC Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connect the signal cable . When attached, tighten the thumbscrews to secure the connection.

  • Page 7: Front Panel Controls And Functions

    Control Panel Functions Side Front Panel Controls Control Function Use this button to enter or exit the On Screen Display. MENU Button OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds.
  • Page 8 Control Panel Functions Control Function Use this button to enter a selection in the On Screen SET/AUTO Display. Button AUTO IMAGE ADJUSTMENT When adjusting your display settings, always press the SET/AUTO button before entering the On Screen Display(OSD). This will automatically adjust your display image to the ideal settings for the current screen resolution size (display mode).

  • Page 9: On Screen Display (Osd) Control Adjustment

    On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD.
  • Page 10 On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub menu Reference To adjust the brightness, PICTURE BRIGHTNESS contrast and gamma of the CONTRAST screen GAMMA COLOR PRESET sRGB To customize the color of the screen...

  • Page 11: On Screen Display(Osd) Selection And Adjustment

    On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears.
  • Page 12 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description PICTURE To adjust the brightness of the screen. BRIGHTNESS P I C T U R E To adjust the contrast of the screen. CONTRAST Set your own gamma value. : -50/0/50 GAMMA On the monitor, high gamma values display whitish images and low gamma...
  • Page 13 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description TRACKING CLOCK To minimize any vertical bars or stripes T R A C K I N G visible on the screen background. The horizontal screen size will also change. PHASE To adjust the focus of the display.

  • Page 14: Flatron F-Engine

    On Screen Display(OSD) Selection and Adjustment The OSD screen will appear when you touch the button on the right side of the monitor. Menu Name Icons Sub-menu Name FLATRON F-ENGINE Screen when applied Screen when not applied When you execute F-ENGINE, two tones will appear on the screen as shown.

  • Page 15: Troubleshooting

    Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the • Check and see if the power cord is connected display connected? properly to the power outlet. Is the power on and the •...

  • Page 16: Display Image Is Incorrect

    Troubleshooting Display image is incorrect Display Position is • Press the SET/AUTO button to automatically incorrect. adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display.

  • Page 17: Have You Installed The Display Driver

    Troubleshooting Have you installed the display driver? Have you installed the • Be sure to install the display driver from the display driver CD (or diskette) that comes with your display driver? display. Or, you can also download the driver from our web site: http://www.lge.com.

  • Page 18: Specifications

    Specifications Display 17 inches (43.2 cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating 17 inches viewable 0.264 mm pixel pitch Sync Input Horizontal Freq. 30 - 83 kHz (Automatic) Vertical Freq. 56 - 75 Hz (Automatic) Input Form Separate TTL, Positive/Negative SOG (Sync On Green) Video Input Signal Input...

  • Page 19: Preset Modes (Resolution)

    Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.469 640 x 350 31.468 720 x 400 31.469 640 x 480 VESA 37.500 640 x 480 VESA 37.879 800 x 600 VESA 46.875 800 x 600 49.725 832 x 624 48.363...

  • Page 20: Installing The Wall Mount Plate

    Installing the Wall mount plate This monitor satisfies the specifications of the Wall mount plate or the interchange device. Place the monitor with its front facing downward on a soft cloth. Separating the back cap Press and hold on to the button on the right side of the stand body and fold the stand base in the direction of the arrow which it indicates.
  • Page 21 Digitally yours...
