Test Report No.: GETEC-E3-07-018 FCC Class B Class II Permissive Change APPENDIX H : USER’S MANUAL EUT Type: 19” LCD Monitor FCC ID: BEJL1960TQ...
Page 2
User’s Guide L1760TQ L1960TQ ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for furture reference. ee the label attached on the product and give the information to your dealer when you ask for service.
Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential eletrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing.
Page 4
Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
Connecting the Display Before setting up the product, ensure that the power to the product, the computer system, and other attached devices is turned off. Attaching/Separating the stand base Place the product with its front facing downward on a soft cloth. .
Page 6
Connecting the Display To attach or separate the back cap To attach the back cap, fix into the 3 holes first then slide it up to fit to the upper groove. NOTE - Cover the back cap after connecting the cables before use. (To connect the cable, see page A5 for reference.) To separate the back cap, hold the bottom part and pull it out.
Connecting the Display Connecting with the PC Before setting up the product, ensure that the power to the product, the computer system, and other attached devices is turned off. Connect the signal cable . When attached, tighten the thumbscrews to secure the connection.
Control Panel Functions Side Front Panel Controls Control Function Use this button to enter or exit the On Screen Display. MENU Button OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for several seconds.
Page 9
Control Panel Functions Control Function Use this button to enter a selection in the On Screen SET/AUTO Display. Button AUTO IMAGE ADJUSTMENT When adjusting your display settings, always press the SET/AUTO button before entering the On Screen Display(OSD). This will automatically adjust your display image to the ideal settings for the current screen resolution size (display mode).
On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD.
Page 11
On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub-menu Reference BRIGHTNESS To adjust the brightness, PICTURE contrast and gamma of the CONTRAST screen GAMMA 6500K To customize the color of COLOR PRESET the screen...
On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears.
Page 13
On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description PICTURE To adjust the brightness of the screen. BRIGHTNESS P I C T U R E To adjust the contrast of the screen. CONTRAST GAMMA Set your own gamma value. : -50/0/50 On the product, high gamma values display whitish images and low gamma values display high contrast images.
Page 14
On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description TRACKING CLOCK To minimize any vertical bars or stripes T R A C K I N G visible on the screen background. The horizontal screen size will also change. PHASE To adjust the focus of the display.
Page 15
On Screen Display(OSD) Selection and Adjustment The OSD screen will appear when you touch the button on the right side of the product. Menu Name Icons Sub-menu Name FLATRON F-ENGINE Screen when applied Screen when not applied When you execute F-ENGINE, two tones will appear on the screen as shown.
Troubleshooting Check the following before calling for service. No image appears No image appears ● Is the power cord of the • Check and see if the power cord is connected display connected? properly to the power outlet. ● Is the power on and the •...
Page 17
Troubleshooting Display image is incorrect ● Display Position is • Press the SET/AUTO button to automatically incorrect. adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display.
Page 18
Troubleshooting Have you installed the display driver? ● Have you installed the • Be sure to install the display driver from the display display driver? driver CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lge.com.
Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.469 640 x 350 31.468 720 x 400 640 x 480 31.469 VESA 37.500 640 x 480 VESA 37.879 800 x 600 VESA 46.875 800 x 600 49.725 832 x 624 48.363...
Specifications Signal Connector Pin Assignment DVI-D Connector Signal(DVI-D) Signal(DVI-D) Hot Plug Detect T. M. D. S. Data2- T. M. D. S. Data2+ T. M. D. S. Data0- T. M. D. S. Data0+ T. M. D. S. Data2/4 Shield T. M. D. S. Data4- T.
Page 23
How to Install the wall mounting This product meets VESA-compliant mounting interface pad specifications. Place the product with its front facing downward on a soft cloth. Pless and hold on to the button on the right side of the stand body and fold the stand base in the direction of the arrow which it indicates.
Regulatory Information cont. respecte toutes les exigences du Règlement sur le FCC Compliance Statement matériel brouilleur du Canada. This equipment has been tested and found to comply NOTICE within the limits of a Class B digital device pursuant to Part The regulations are applied only to the products with the 15 of the FCC Rules.
Page 27
Regulatory Information cont. computer and/or display, after a certain period of inactivity, Why do we have environmentally labelled computers? In many countries, environmental labelling has become an shall reduce its power consumption to a lower level, in one established method for encouraging the adaptation of or more stages.
Page 28
Regulatory Information cont. relevant bio-accumulative TCO’95 requirement permits Monitor Disposal the inclusion of lead, as no replacement has yet been WARNING developed. If you need to dispose of a monitor, ask a qualified service representative for the proper procedure. Improper disposal could Cadmium is present in rechargeable batteries and in the result in personal injury from implosion.
Page 29
Regulatory Information cont. Approval requirements cover a wide range of issues: ecology, ergonomics, emission of electrical and TCO’99 requires that plastic components weighing more magnetical fields, energy consumption and electrical than 25 grams shall not contain flame retardants with safety. organically bound bromine or chlorine.
Page 30
The product must be prepared for recycling and the If you want to find out more information about our recycling manufacturer must have a certified environmental program, please contact your local LG vendor or a management system such as EMAS or ISO 14 001 corporate representative of LG.
