BATTERY CHARGER RS-900
Instruction Manual
BEFORE USING OUR BATTERY CHARGER RS-900, READ IN DETAILS ALL
INSTRUCTIONS CONTAINED IN THIS MANUAL. KEEP THIS MANUAL IN A
SAFE PLACE AS YOU MAY NEED TO USE IT AT A LATER DATE.
We draw the attention of all users of this device: please follow the safety
and maintenance instructions which are part of this manual. Also read the
caution markings on the charger, the manual, and the gift box.
33

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS-900 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for La Crosse Technology RS-900

Summary of Contents for La Crosse Technology RS-900

  • Page 1 BATTERY CHARGER RS-900 Instruction Manual BEFORE USING OUR BATTERY CHARGER RS-900, READ IN DETAILS ALL INSTRUCTIONS CONTAINED IN THIS MANUAL. KEEP THIS MANUAL IN A SAFE PLACE AS YOU MAY NEED TO USE IT AT A LATER DATE. We draw the attention of all users of this device: please follow the safety and maintenance instructions which are part of this manual.
  • Page 2 INTRODUCTION: Congratulations on purchasing this intelligent charging unit which enables definitely quick and optimum charging to “AA” and “AAA” rechargeable batteries. With charging, discharging, refreshing and capacity test functions as well as individual LCD displays for charging compartments; this charging unit is reliable, user-friendly and ideal for use in the home, office or on journey.
  • Page 3 CAUTIONS: The charger is restricted to charging NiCd and NiMH rechargeable batteries only. Never adopt this charger to other types of batteries such as alkaline, lithium, carbon zinc or other types that are not specified. The charging unit shall only be used only at normal indoor room conditions. Always follow the charging instructions for the rechargeable battery.

  • Page 4: Inventory Of Contents

    charging current can be set up to 1500 or 1800 mAh when two batteries are charged. Fast charging – 70 mins to charge up 2000 mAh batteries Individual LCD display for compartments Charging both “AA” and “AAA” rechargeable batteries simultaneously Overheat detection to protect rechargeable batteries from over-charging Minus delta voltage (-dV) detection for charge termination Damaged batteries detection...

  • Page 5: Function Keys

    Size “C” battery adapter (4 nos.) & Size “D” battery adapter (4 nos.) Holding Bag “AA” rechargeable battery (4 nos.) & “AAA” rechargeable battery (4 nos.) Instruction Manual FUNCTION KEYS: There are three easy-to-use function keys and four number keys in the charging unit: Compartment Number keys MODE key...

  • Page 6: Mode Key

    Compartment Number key Press and release the Number key to select a particular battery compartment for charge modes and/or display mode adjustment. MODE key The mode key shall first be pressed and held for 1 second to activate the mode change. The subsequent pressing of the mode key will enable to toggle between the “Charge”, “Discharge”, “Test”...
  • Page 7 CURRENT key Press to select the amount of current to be applied (within the first 8 seconds after batteries are inserted) in different operating modes (also see “Start charging the rechargeable batteries” below). OPERATING MODES OF THE CHARGING UNIT This powerful charging unit provides the following operating modes: Charge up the rechargeable battery (CHARGE) –...

  • Page 8: Charge Mode

    CHARGE MODE Charging at 200 mA is the default-operating mode of the charging unit. When only one or two numbers of rechargeable batteries are charged, provided that only compartment 1 and compartment 4 are used, a charging current up to 1500 or 1800 mA may be set by the pressing the CURRENT key.
  • Page 9 When charging two batteries at When charging four batteries – compartment 2 & 3 – max. max. charging current: 1000 mA charging current: 1000 mA The estimated time of charging by various charging current is tabulated in Table 1.
  • Page 10 Table 1. Charging Time with various charging current Size of battery Battery Capacity Charging current selected (mA) Estimated charging time 1800 ~75 min 1500 ~90 min 1000 ~2 hr 15 min 2300 mAh ~3 hr 15 min ~4 hr 30 min ~11 hr 30 min 1800 ~70 min...
  • Page 11 Note: User shall always observe the recommended maximum charging current of the rechargeable batteries. In general, 200 mA is a recommended charging current if rapid charging is not necessary. It is definitely safe and optimum to the rechargeable batteries. When the transformer has been plugged to the power source, the version number of the charger (for example “29”...
  • Page 12 START CHARGING THE RECHARGEABLE BATTERIES Once a rechargeable battery is inserted after the transformer has been plugged to the power source, the battery voltage (for example, “1.39V”) will be displayed for 4 seconds. Then “200 mA Charge” (default mode) will be shown on LCD for another 4 seconds, indicating that charging with 200 mA is to be started if no alternation in setting is made.
  • Page 13 Charging current: 200 mA After 4 seconds from no more keys pressing, the LCD will blink once to indicate the setting is confirmed and Charge Mode the selected mode activated During charging, the different displays- Charging current (in mA), Time elapsed (in hh:mm), Terminal voltage (in V) and Accumulated capacities (in mAh or Ah) may be toggled and selected by pressing the DISPLAY key (refer Table 4).
  • Page 14 “Full” sign is shown -The battery is fully charged Note : The current cannot be altered once the setting has been confirmed in the initial stage. This can avoid the user changing the current setting accidentally while doing setting on other rechargeable batteries.
  • Page 15 Therefore, user is recommend to place the battery with the highest expected charging current at Compartment 1 first. To release the restriction of setting charging current, user shall take out all four rechargeable batteries from the charging unit. To change the operating mode during charging, one can press the MODE key (for selecting all rechargeable batteries) or NUMBER key then MODE key (for selecting individual rechargeable battery).

  • Page 16: Discharge Mode

    For new rechargeable battery it is recommended to charge it with 200 mA current for re- conditioning it from the long storage status. DISCHARGE MODE Discharge mode will first discharge the rechargeable battery then charge it. It is for removing the memory effects of rechargeable batteries.
  • Page 17 Discharging current: 250 mA Discharge Mode Note: The discharging current is always set to be half of the coming charging current whose upper limit is 1000 mA (see Table 2). Therefore user is recommended to carefully select the discharging current so that the charging current afterward will not be too high. Table 2.

  • Page 18: Refresh Mode

    Finally batteries will be fully charged in discharge mode and “Full” will be displayed. If user presses DISPLAY key at this time, "charge" icon instead of "discharge" icon will be displayed. REFRESH MODE Old rechargeable batteries and those have not been used for a long time require refreshing. This process will recover the optimum capacity of the rechargeable batteries.

  • Page 19: Test Mode

    Note: By pressing the MODE key within 8 seconds after inserting the rechargeable batteries, the Refresh mode can be selected. (The mode key shall first be pressed and held for 1 second to activate the mode change. The subsequent pressing of the mode key will enable to toggle between the “Charge”, “Discharge”, “Test”...
  • Page 20 By pressing the MODE key within 8 seconds after inserting the rechargeable batteries, the Test mode can be selected. (The mode key shall first be pressed and held for 1 second to activate the mode change. The subsequent pressing of the mode key will enable to toggle between the “Charge”, “Discharge”, “Test”...
  • Page 21 Table 3. TEST MODE Current User-selected Charging 200 mA 500 mA 700 mA 1000 mA current Thereafter Discharging 100 mA 250 mA 350 mA 500 mA current The maximum charging current is 1000 mA and not affected by the number of rechargeable batteries inserted.

  • Page 22: Trickle Charging

    TRICKLE CHARGING After the rechargeable battery is fully charged in any of the operating modes, the charger will give a small amount of current to the rechargeable batteries to maintain the fully charged level. This mode is automatically launched after rechargeable batteries are fully charged and kept at the charging unit.

  • Page 23: Display Mode Information

    DISPLAY MODE INFORMATION User can use different display modes to monitor the rechargeable battery condition during the different operations (see below figure and Table 4 to 7). Different display modes are exhibited: Charging current, Time, Voltage and Capacity Different operating modes...
  • Page 24 Table 4. Various displays in Charge Mode Various displays (toggled by pressing DISPLAY key) Stage in Charge Capacity mode Voltage (V) Current (mA) *Time (hh:mm) (mAh/ Ah) During charging Charging current Instantaneous Charging time Accumulated Battery voltage elapsed capacity Full stage Trickle charging current...
  • Page 25 Table 5. Various displays in Discharge Mode Various displays (toggled by pressing DISPLAY key) Stage in Capacity Discharge mode Voltage (V) Current (mA) *Time (hh:mm) (mAh/ Ah) During Discharging Discharging time Capacity during discharging current elapsed discharging Instantaneous During charging Battery voltage Charging current Charging time...
  • Page 26 Table 6. Various displays in Refresh Mode Various displays (toggled by pressing DISPLAY key) Stage in Refresh Capacity mode Voltage (V) Current (mA) *Time (hh:mm) (mAh/ Ah) During Instantaneous Discharging Discharging time Capacity during discharging Battery voltage current elapsed discharging processes Capacity During charging...
  • Page 27 Table 7. Various displays in Test Mode Various displays (toggled by pressing DISPLAY key) Stage in Test Capacity mode Voltage (V) Current (mA) *Time (hh:mm) (mAh/ Ah) Charging time During charging Charging current “--- mAh” elapsed During Discharging Discharging time “--- mAh”...
  • Page 28 THE SIZE C AND SIZE D BATTERY ADAPTERS (FREE ACCESSORY) The battery adapters are used for connecting the AA battery to the electric devices requiring Size C or D batteries. To apply the adapter: Install the AA battery to Size C or Size D adapter as below. The AA battery used with the The AA battery used with the Size D Size C adapter...

  • Page 29: Care And Maintenance

    Ensure the polarity is correct and the assembling condition is good. Note: User shall stopping using the adaptor when there are any cracks or damages observed in the adaptor, and in case undesired smell comes out while applying the adapter in certain kinds of electric device.

  • Page 30: Specifications

    SPECIFICATIONS: Input voltage for AC/DC adapter 100-240 VAC Charging current range 200 mA - 1800 mA Max charging capacity (capacity of rechargeable batteries) 3000 mAh Dimensions (L x H x W) of Charging unit 75 x 129 x 37.2 mm LIABILITY DISCLAIMER: The manufacturer and supplier cannot accept any responsibility for any improper or incorrect use and any consequences occur.

  • Page 31: Caution: Safety Instructions

    • Do not use any accessories not supplied with the charger, unless recommended by La Crosse Technology. Especially, never use any power cable and transformer other than those originally supplied with the charging unit. • Disconnect the AC/DC when not in use •...
