BATTERY CHARGER BC-700U
Instruction Manual
INTRODUCTION:
Congratulations on purchasing this intelligent charging unit which enables quick and optimum
charging to "AA" and "AAA" rechargeable batteries. With charging, discharging, refreshing and
capacity test functions as well as individual LCD displays for charging compartments; this
charging unit is reliable, user-friendly and ideal for use in the home, office or on a journey.
The Charging unit
FEATURES:
The Charging unit
Charging rechargeable batteries in various currents (200, 500 or 700 mA).
z
Fast charging - 70 mins to charge up 2000 mAh batteries
z
Individual LCD display for all compartments
z
Charging both "AA" and "AAA" rechargeable batteries simultaneously
z
Overheat detection to protect rechargeable batteries from over-charging
z
Minus delta voltage (-dV) detection for charge termination
z
Damaged batteries detection
z
Discharge mode (first discharging and then charging) to remove memory effect of
z
rechargeable batteries
Refreshing old rechargeable batteries by discharging/ charging cycles
z
Test function to check the capacities of rechargeable batteries
z
Charging/ Discharging functions can be launched independently and simultaneously to
z
each rechargeable battery in the compartments
Various display modes during charging/ discharging - the charging current (in mA), time
z
elapsed (in hh:mm), the terminal voltage (in V) and accumulated capacities (in mAh or Ah)
2
4
TABLE OF CONTENT
Topic
Features
Page
Inventory Of Contents
Function Keys
Operating Modes
1
Trickle Charge
Troubleshooting
CAUTIONS:
1.
The charger is restricted to charging NiCd and NiMH rechargeable batteries only.
Never use this charger for other types of batteries such as alkaline, lithium, carbon zinc
or other types that are not specified.
2.
The charging unit should only be used at normal indoor room conditions.
3.
Place charger on a hard flat surface.
4.
Always follow the charging instructions for the rechargeable battery. Observe the
recommended charging current of the rechargeable batteries. Never use a charging
current higher than recommended in the charging process.
5.
Never use any power cable and transformer other than those originally supplied with the
charging unit.
6.
The rechargeable batteries may become hot during charging (especially when a high
charging current is chosen). User should take extra care when taking out the batteries
after charging.
7.
Unplug the charging unit from the power source when not in use.
INVENTORY OF CONTENTS
1.
Charging unit
2.
Transformer
3.
Instruction Manual
FUNCTION KEYS:
There are three easy-to-use function keys and four number keys on the charging unit:
CURRENT key
DISPLAY
Page
14
16
18
20
21
26
27
28
32
1
3
Compartment
Number keys
MODE key
5
4
5
5
7
