BATTERY CHARGER
Instruction Manual
BEFORE USING OUR BATTERY CHARGER, READ IN DETAILS ALL
INSTRUCTIONS CONTAINED IN THIS MANUAL. KEEP THIS MANUAL IN A
SAFE PLACE AS YOU MAY NEED TO USE IT AT A LATER DATE.
We draw the attention of all users of this device: please follow the safety
and maintenance instructions which are part of this manual. Also read the
caution markings on the charger, the manual, and the gift box.
27

Advertisement

Table of Contents
loading

Related Manuals for La Crosse Technology Battery Charger

Summary of Contents for La Crosse Technology Battery Charger

  • Page 1 BATTERY CHARGER Instruction Manual BEFORE USING OUR BATTERY CHARGER, READ IN DETAILS ALL INSTRUCTIONS CONTAINED IN THIS MANUAL. KEEP THIS MANUAL IN A SAFE PLACE AS YOU MAY NEED TO USE IT AT A LATER DATE. We draw the attention of all users of this device: please follow the safety and maintenance instructions which are part of this manual.
  • Page 2 INTRODUCTION: Congratulations on purchasing this intelligent charging unit which enables definitely quick and optimum charging to “AA” and “AAA” rechargeable batteries. With charging, discharging, refreshing and capacity test functions as well as individual LCD displays for charging compartments; this charging unit is reliable, user-friendly and ideal for use in the home, office or on journey.
  • Page 3 CAUTIONS: The charger is restricted to charging NiCd and NiMH rechargeable batteries only. Never adopt this charger to other types of batteries such as alkaline, lithium, carbon zinc or other types that are not specified. The charging unit shall only be used only at normal indoor room conditions. Always follow the charging instructions for the rechargeable battery.

  • Page 4: Inventory Of Contents

    Minus delta voltage (-dV) detection for charge termination Damaged batteries detection Discharge mode (first discharging and then charging) to remove memory effect of rechargeable batteries Refreshing old rechargeable batteries by discharging/ charging cycles Test function to check the capacities of rechargeable batteries Different Charging/ Discharging functions can be launched independently and simultaneously to each rechargeable battery in the compartments Various display modes during charging/ discharging –...

  • Page 5: Mode Key

    Compartment Number keys MODE key CURRENT key DISPLAY Compartment Number key Press and release the Number key to select a particular battery compartment for charge modes and/or display mode adjustment. MODE key The mode key shall first be pressed and held for about 1 second to activate the mode change. The subsequent pressing of the mode key will enable to toggle between the “Charge”, “Discharge”, “Test”...

  • Page 6: Display Key

    DISPLAY key Press and release to select the displays of the charging current (in mA), time elapsed (in hh:mm), the terminal voltage (in V) and accumulated capacities (in mAh or Ah) during the charging or discharging process. To change the display content of a particular rechargeable battery, first press corresponding NUMBER key then press the DISPLAY key.

  • Page 7: Charge Mode

    those have not been used for a long times, refreshing may bring the rechargeable battery back to the optimum condition. Check the rechargeable battery capacity in mAh/ Ah (TEST) CHARGE MODE Charging at 200 mA is the default-operating mode of the charging unit. User may select a charging current of 200, 500 or 700 mA.
  • Page 8 Note: User shall always observe the recommended maximum charging current of the rechargeable batteries. In general, 200 mA is a recommended charging current if rapid charging is not necessary. It is definitely safe and optimum to the rechargeable batteries. It may be necessary to charge and discharge the new rechargeable batteries for several times in the beginning before the optimum capacity of the rechargeable batteries can be obtained.
  • Page 9 START CHARGING THE RECHARGEABLE BATTERIES Once a rechargeable battery is inserted after the transformer has been plugged to the power source, the battery voltage (for example, “1.39V”) will be displayed for 4 seconds. Then “200 mA Charge” (default mode) will be shown on LCD for another 4 seconds, indicating that charging with 200 mA is to be started if no alternation in setting is made.
  • Page 10 Charging current: 200 mA After 8 seconds from no more keys pressing, the LCD will blink once to indicate the setting is confirmed and Charge Mode the selected mode activated During charging, the different displays- Charging current (in mA), Time elapsed (in hh:mm), Terminal voltage (in V) and Accumulated capacities (in mAh or Ah) may be toggled and selected by pressing the DISPLAY key (refer Table 4).
  • Page 11 “Full” sign is shown -The battery is fully charged Note : The current cannot be altered once the setting has been confirmed in the initial stage. This can avoid the user changing the current setting accidentally while doing setting on other rechargeable batteries.

  • Page 12: Discharge Mode

    selecting all rechargeable batteries) or NUMBER key then MODE key (for selecting individual rechargeable battery). 8 seconds after the last key press the LCD will blink one time to indicate the end of changing. When overheating condition occurs (over about 53°C, usually due to too high a charging current selected), the charging will be stopped immediately and the display will shown “000 mA”, the charging process will only resume once the temperature of the rechargeable batteries drops to a safe level.
  • Page 13 the memory effects of rechargeable batteries. By pressing the MODE key within 8 seconds after inserting the rechargeable batteries, the Discharge mode can be selected. (The mode key shall first be pressed and held for about 1 second to activate the mode change. The subsequent pressing of the mode key will enable to toggle between the “Charge”, “Discharge”, “Test”...

  • Page 14: Refresh Mode

    Table 2. DISCHARGE MODE Current User-selected Discharging 100 mA 250 mA 350 mA current Thereafter Charging 200 mA 500 mA 700 mA current Finally batteries will be fully charged in discharge mode and “Full” will be displayed. If user presses DISPLAY key at this time, "charge" icon instead of "discharge" icon will be displayed. REFRESH MODE Old rechargeable batteries and those have not been used for a long time require refreshing.
  • Page 15 Discharging current: 250 mA Refresh mode (the battery is being discharged) Note: By pressing the MODE key within 8 seconds after inserting the rechargeable batteries, the Refresh mode can be selected. (The mode key shall first be pressed and held for about 1 second to activate the mode change.

  • Page 16: Test Mode

    TEST MODE In Test mode the rechargeable batteries will first be fully charged and then discharged to determine the capacities. Finally, the rechargeable batteries are charged up again and the capacity in (mAh) of (Ah) will be estimated and shown after the discharging ends. By pressing the MODE key within 8 seconds after inserting the rechargeable batteries, the Test mode can be selected.
  • Page 17 Table 3). Table 3. TEST MODE Current User-selected Charging 200 mA 500 mA 700 mA current Thereafter Discharging 100 mA 250 mA 350 mA current The maximum charging current is 700 mA. After the test mode is finished, the display will shift between the “Full” sign and the battery capacity (in mAh or Ah) automatically in 3-second intervals until the rechargeable batteries are removed.

  • Page 18: Trickle Charging

    TRICKLE CHARGING After the rechargeable battery is fully charged in any of the operating modes, the charger will give a small amount of current to the rechargeable batteries to maintain the fully charged level. This mode is automatically launched after rechargeable batteries are fully charged and kept at the charging unit.
  • Page 19 Table 4. Various displays in Charge Mode Various displays (toggled by pressing DISPLAY key) Stage in Charge Capacity mode Voltage (V) Current (mA) *Time (hh:mm) (mAh/ Ah) During charging Charging current Instantaneous Charging time Accumulated Battery voltage elapsed capacity Full stage Trickle charging current...
  • Page 20 Table 5. Various displays in Discharge Mode Stage in Various displays (toggled by pressing DISPLAY key) Discharge Capacity Voltage (V) Current (mA) *Time (hh:mm) mode (mAh/ Ah) During Discharging Discharging time Capacity during discharging current elapsed discharging Instantaneous During charging Battery voltage Charging current Charging time...
  • Page 21 Table 6. Various displays in Refresh Mode Various displays (toggled by pressing DISPLAY key) Stage in Capacity Refresh mode Voltage (V) Current (mA) *Time (hh:mm) (mAh/ Ah) During Instantaneous Discharging Discharging time Capacity during discharging Battery voltage current elapsed discharging processes Capacity During charging...
  • Page 22 Table 7. Various displays in Test Mode Various displays (toggled by pressing DISPLAY key) Stage in Test Capacity mode Voltage (V) Current (mA) *Time (hh:mm) (mAh/ Ah) Charging time During charging Charging current “--- mAh” elapsed During Discharging Discharging time “--- mAh”...

  • Page 23: Care And Maintenance

    operated, the operational mode will automatically be set to “Charge mode at 200 mA” to charge up the battery once the power source is back to normal, regardless the operating mode (Charge, Discharge, Refresh or Test) which has been selected by user before. CARE AND MAINTENANCE: Extreme temperatures, vibration and shock should be avoided as these may cause damage to the unit...

  • Page 24: Liability Disclaimer

    Dimensions (L x H x W) of Charging unit 75 x 130 x 40 mm LIABILITY DISCLAIMER: The manufacturer and supplier cannot accept any responsibility for any improper or incorrect use and any consequences occur. Any performance of repairs or alternations by someone other than the original supplier will invalidate the warranty.
  • Page 25 Do not operate the charger if it has received a blow or has been subject to any • damage. • Do not use the Battery charger for other purposes than the Only one originally forecast Do not open or/and disassemble the charger: such handling may result in a risk •...
