WASHER
INSTALLATION
INSTRUCTIONS
INSTRUCCIONES
DE INSTALACION
DE LA LAVADORA
Table
of Contents
WASHER SAFETY ........................................................................
1
iNSTALLATiON REQUIREMENTS
...............................................
2
Tools and Parts .....................................................................
2
Location
Requirements
.......................................................
2
Drain System ........................................................................
3
Electrical
Requirements
......................................................
4
iNSTALLATiON
iNSTRUCTiONS
.......................................
4
Before you start: remove shipping
materials
.................... 4
Connect
Drain Hose .............................................................
5
Connect
Inlet Hoses .............................................................
6
Level Washer ........................................................................
7
Complete
Installation Checklist
..........................................
8
P
•
In&ce
SEGURIDAD
DE LA LAVADORA .................................................
9
REQUISITOS
DE INSTALACION
................................................
9
Herramientas
y piezas ...........................................................
9
Requisitos de ubicaciSn
......................................................
10
Sistema de desag_e .............................................................
11
Requisitos el_ctricos
...........................................................
12
INSTRUCCIONES
DE INSTALACION .......................................
13
Antes de comenzar:
quite los materiales
de transporte
.. 13
Cone×iSn de la manguera
de desagi3e ...............................
14
Cone×iSn de las mangueras
de entrada ............................
14
NivelaciSn
de la lavadora
....................................................
16
Complete
la instalaciSn .......................................................
17
iNSTALLATiON NOTES
NOTAS SOBRE LA INSTALACION
Date of purchase:
Date of installation:
Installer:
Model number:
Serial number:
Fecha de compra:
Fecha de instalaciSn:
Instalador:
N_mero de modelo:
N_mero de serie:
WASHER
S_ETY
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety
messages.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING."
These words mean:
You can be killed or seriously injured if you don't immediately
follow
instructions.
You can be killed or seriously
injured if you don't follow
instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you what can
happen if the instructions are not followed.
W10486822A
