1.2.8 Spectrum Mode

Spans:
Sweep Rates:
Display Scaling
and Range:
Spurious Free
Dynamic Range:

1.2.9 Intermodulation Distortion

CSO / CTB Characteristics
Out of Measurement Range
60
50
40
30
20
10
0
-20 -10
Video Signal Level (dBmV)
*Typical Specifications
Range:
Resolution:
3, 5, 10, 20, and 50 MHz (0.3, 0.5, 1, 2, and
5 MHz/div)
1 second (5 MHz)
2 seconds (10, 20 & 50 MHz)
0.5, 1, 2, 5, and 10 dB/division; 6 vertical
divisions
60 dB (typical specifications)
*
0 10 20
60 dB maximum
1 dB
30
1-5
