Transmitter; Telemetry - Wavetek 3SR Operation Manual

Sweep Rate:
Accuracy:
Display Scaling
and Range:
Sweep Scan:
Reference Storage:
Sweep Trace Storage:
Reverse Option
Transmitter Output:

1.2.6 Transmitter

Frequency Range:
Level Range:
Spectral Purity:

1.2.7 Telemetry

Frequency:
Modulation:
Spectrum Required:
1-4
1 second for 600 MHz sweep, no
scrambled channels
+ 0.5 dB, normalized (dependent on
stability of referenced carriers)
1, 2, 5, and 10 dB/division; 6 vertical
divisions
User definable from 5 to 1,000 MHz
At least 16, including Forward, Reverse, or
Sweepless
At least 50, including Forward, Reverse, or
Sweepless
+10 to +40 dBmV, settable in 2 dB
increments
5 to 1,000 MHz
(1)
+20 to +50 dBmV; settable in 2 dB
increments
Hars -30 dBc; Spurs -35 dBc
User defined, 5 to 1,000 MHz
FSK, 100 kHz deviation
1 MHz recommended
