Ethernet Switch
ieS4028FP
Specifications
Product Specifications
Physical Features
Ports
Switching
Capacities
Forwarding
Rate
Weight
Dimension
AC Input
Power
Consumption
Power-over-
Ethernet
Network
Interface
Software Features
Feature
Flow Control
Spanning Tree
MAC Addresses
VLAN
IGMP Snooping
Link Aggregation
MVR
Jumbo Frame
QnQ
Quality of Service
©2010 Samsung Telecommunications America, LLC. Samsung and Ubigate are registered
trademarks of Samsung Electronics America, Inc., and its entities.
* Specifications are subject to change without prior notice
SAMSUNG TECHWIN AMERICA Inc.
100 Challenger Road, Suite 700, Ridgefield Park, NJ 07660, UNITED STATES
Tol Free : 1-877-213-1222 Fax : 1-201-373-0124
www.samsung-security.com
iES4028FP
24 10/100 BASE-T ports with PoE
2 10/100/1000 BASE-T ports
2 Gigabit combo ports
1 Console port
12.8Gbps
9.5Mpps
4.13kg
9.11lbs
4.3 x 44 x 33cm
1.7 x 17.3 x 12.992inch
100 to 240V, 50-60Hz
225W (System 45W, PoE 180W)
Maximum output power per port
: 15.4W
Maximum output power per port
: 7.5W simultaneously
10/100 BASE-T ports
10/100/1000 BASE-T ports
SFP Transceiver slots supporting SX, LX and ZX SFP
Multimode fiber cable : 62.5/125 or 50/125 microns
Single mode fiber cable : 9/125 micron
Description
IEEE 802.3x for full duplex mode
Back pressure flow control half duplex mode
IEEE 802.1D STP
IEEE 802.1w RSTP
IEEE 802.1s MSTP
Spanning Tree Fast Forwarding
Auto Edge
Loop Protection
8K MAC address entries
802.1Q Tag-based VLAN
802.1Q Port-based VLAN
802.1v Protocol-based VLAN
256 VLANs entries out of 4K VLAN IDs
GVRP
Voice VLAN
V1, V2, V3
Querier
Immediate Leave
Filtering and throttling
IEEE 802.3ad with LACP
: 8 aggregation groups up to 8 ports
Yes
10K in gigabit ports
Yes
Priority queue : Scheduling (Strict priority, WRR),
4 queues per port
DiffServ
COS : IEEE 802.1p, DSCP based COS
Rate limiting (Per Port based) : Ingress, Egress
For more information or to locate a
dealer, go to www.samsung.com/bcs
Eco mark
The
Samsung Techwin's will to create
environment-friendly products,and indicates
that the product satisfies the EU RoHS Directive.
iES4028F
24 10/100 BASE-T ports
4 Gigabit combo ports
1 Console port
12.8Gbps
9.5Mpps
3kg
6.7 lbs
4.3 x 44 x 17.2cm
1.7 x 17.3 x 6.7inch
100 to 240V, 50-60Hz
30W
NA
Feature
Description
Storm Control
: Broadcast storm, Multicast storm,
DLF (Destination Lookup Failure)
MAC Address filtering
Username/Password authentication
Access control list (L2/L3/L4)
AAA : RADIUS, TACACS+
MAC based Authentication
Security
HTTPS/SSL
SSHv1/v2
802.1x
: Port-Based, Supplicant Support, VLAN Assignment,
Guest VLAN, Co-works with Radius, TACACS+ server
Management Interface Access filtering : SNMP, WEB, Telnet
DHCP Snooping
IP Source Guard
Management method
: Web-based, Telnet (4 sessions)
Software download : TFTP, Xmodem
Dual Firmware Images
Configuration file download : TFTP
SNMP v1/v2c/v3
RMON (group 1, 2, 3, 9)
BOOTP : Client
DHCP : Client, Relay (Option 82)
Management
Port mirroring (one-to-many)
Event/Error Log : Local, Syslog, SMTP
Remote Ping
SNTP
NTP
IEEE 802.1ab (LLDP)
UPnP, Banner, Web authentication
IP Clustering (36 members)
* Specifications are subject to change without prior notice
represents
iES4024GP
22 10/100/1000 BASE-T ports with PoE
2 Gigabit combo ports with PoE
1 Console port
48Gbps
35.7Mpps
4.33kg
9.53 lbs
4.3 x 44 x 32cm
1.7 x 17.3 x 12.6inch
100 to 240V, 50-60Hz
225W (System 45W, PoE 180W)
Maximum output power per port
: 15.4W
Maximum output power per port :
: 7.5W simultaneously
