HP Compaq 500B Overview

HP Compaq 500B Overview

Compaq microtower pc
Hide thumbs Also See for Compaq 500B:
Table of Contents

Advertisement

Quick Links

See also: Maintenance and Service Manual
QuickSpecs
Overview
1. 300-watt power supply
2. (1) external 5.25-inch bay for optional optical drive
3. (1) internal 3.5-inch bay for hard disk drive
4. Rear I/O includes (4) USB 2.0 ports, RJ-45 network port, VGA
video port, audio in/out jacks, microphone jack
5. Front I/O includes (2) USB 2.0 ports, audio in/out jacks,
Media Card Reader (select countries/models only)
Microtower
Microtower
Microtower
Microtower
DA - 13418
North America — Version 2 — October 30, 2009
Compaq 500B Microtower PC
Compaq 500B Microtower PC
Compaq 500B Microtower PC
Compaq 500B Microtower PC
Windows®. Life without Walls™.
Windows®. Life without Walls™.
Windows®. Life without Walls™.
Windows®. Life without Walls™.
HP recommends Windows 7.
HP recommends Windows 7.
HP recommends Windows 7.
HP recommends Windows 7.
6. Full height expansion slots include (1) PCI 2.3 slot,
(2) PCIe x1 slots, (1) PCIe x16 graphics slot
7. Compaq USB Optical Scroll Mouse
8. Compaq USB Standard Keyboard
9. Monitor (sold separately)
Page 1
