OWNER'S MANUAL
MODELS EASASD-10ASC, EASASD-11ASC
EASASD-12ASC, EASASD-18ASC

ELECTRONIC AIR CLEANERS

IMPORTANT: PLEASE READ MANUAL BEFORE OPERATING UNIT
Features
Lifetime Filter System never needs replacing
Electronically removes dust, mites, pollen, pet dander, tobacco smoke, cooking smoke
and grease, mold, fungi, bacteria, viruses and more, down to 0.01 micron
Dual Voltage, Aluminum Collecting Cells are durable and easy to maintain
Cell Guide ensures proper placement of collecting cells
Activated Carbon Filters remove unpleasant odors
Electronic Air Proving Switch for quick wiring
Dual Indicator Lights show Air Cleaner is working at a glance
Galvanized Steel Cabinet for solid vertical or horizontal installation
Durable Scratch-Resistant powder coat paint finish resists corrosion

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EASASD-10ASC and is the answer not in the manual?

Questions and answers

Summary of Contents for Electro-Air EASASD-10ASC

  • Page 1: Electronic Air Cleaners

    OWNER’S MANUAL MODELS EASASD-10ASC, EASASD-11ASC EASASD-12ASC, EASASD-18ASC ELECTRONIC AIR CLEANERS IMPORTANT: PLEASE READ MANUAL BEFORE OPERATING UNIT Features Lifetime Filter System never needs replacing Electronically removes dust, mites, pollen, pet dander, tobacco smoke, cooking smoke and grease, mold, fungi, bacteria, viruses and more, down to 0.01 micron...
  • Page 2: Table Of Contents

    WARNING IMPORTANT: Please read entire instructions before installing the Electronic Air Cleaner. Before beginning any installation or modification, be certain that the main line electrical disconnect switch is CONTENTS in OFF position. Electric shock could result. Tag disconnect switch with suitable warning labels. SAFETY CONSIDERATIONS WHAT THE ELECTRONIC AIR CLEANER DOES Installation and...
  • Page 3: Specifications

    Table 1 — SPECIFICATIONS MODEL EASASD-10ASC EASASD-11ASC EASASD-12ASC EASASD-18ASC House Size Area <2400 ft² <3000 ft² <3000 ft² >3000 ft² <222.96 m² <278.70 m² <278.70 m² >278.70 m² Airflow up to 1200 CFM up to 1400 CFM up to 1400 CFM up to 2000 CFM up to 2040 m³/hr...
  • Page 4: Installation Location With Humidifier

    Fig. 3 — DIMENSIONS DIMENSIONS — in (cm) MODEL 19.8 15.9 23.2 13.1 20.7 23.7 21.2 EASASD-10ASC (50.4) (40.5) (58.9) (33.3) (52.5) (3.2) (60.2) (53.9) 19.8 15.9 26.1 13.6 24.1 26.6 25.8 EASASD-11ASC (50.4) (40.5) (66.3) (34.6) (61.2) (2.5) (67.7) (65.4)
  • Page 5: Electronic Air Cleaner Installation

    WARNING Electronic Air Cleaner Installation Electrical shock can cause injury or death. Be certain 1. Remove existing equipment filter. Thoroughly clean main line disconnect switch is off before wiring. fan compartment and ductwork where Air Cleaner is to be installed. Wiring should only be performed by qualified 2.
  • Page 6: Operation

    Note: There may be some arcing or snapping sounds 3. Rinse cells well with hot water (maximum 120°F/ from the collecting cells. This is normal when the unit is 49°C). new. In about 2 weeks, as the sharp edges of the cells 4.
  • Page 7: Service

    functions: APS output with the jumper, replace the APS. 1. Turn Air Cleaner power switch OFF. 7. If there is no output from the APS, check the output 2. Turn off system fan. voltage from the on/off switch. 3. Open access door. 8.
  • Page 8: Replacing A Power Board

    4. Push the new light into the power box. If the power board fails to come on with the fan on, check that the sensor is properly set down, to the bottom 5. Connect the wiring to the LED terminals on the power of the plastic bushing, in the front of the power box.
  • Page 9: Setting Voltage Of Power Board

    without the transformer connected. Resistance should 8. Remove the high voltage meter. read above 20K ohms with an analog meter and above 9. Replace the power box cover. 4M ohms with a digital meter. If the resistance readings 10. Turn ON the Air Cleaner. are below these values, the power board may be the cause of the transformer failure.
  • Page 10: Removing Power Box

    ohmmeter can be used. Always discharge the cell with source wires to the Air Cleaner. Cap off the wires so a screw driver before testing with an ohmmeter. the system can still be operated. 4. Remove the two nuts holding the power box to the 1.
  • Page 11: Parts List

    Parts List Use the diagram on the preceding page to identify the part which is required. To order parts call the number listed at the bottom of the page or call your local contractor. Part Description EASASD-10 EASASD-11 EASASD-12 EASASD-18 On/Off Switch R1-0205 R1-0205...
  • Page 12: Troubleshooting Guide

    Table 4 — TROUBLESHOOTING GUIDE PROBLEM PROBABLE CAUSE REMEDY Unit does not function System fan is not on. Turn system fan on. correctly. Power light Wiring improperly connected. Check wiring or if plug is inserted and receptacle is powered. and performance indi- Defective power switch.
  • Page 13 Cleaning Record The collecting cells and prefilters must be cleaned on a regular basis for the Air Cleaner to function at its peak of efficiency. The frequency of cleaning will vary from one house to another. On average, the cells should be cleaned every 3 months. Use the chart below to keep track of your cleaning schedule.
  • Page 14 NOTES:...
  • Page 15: Warranty

    ELECTRONIC AIR CLEANER LIMITED FIVE (5) YEAR WARRANTY This ELECTRO-AIR product is warranted to be free from electrical and mechanical defects in material and workmanship, under normal use and maintenance, within its listed capacity for a period of FIVE (5) years from the date of original purchase.
  • Page 16 ATTENTION INSTALLER IMPORTANT WIRING INFORMATION This Electronic Air Cleaner is equipped with an Air Proving Switch (APS). The recommended source for the input voltage to the Air Cleaner is from the same source that is supplying the heating/cooling equipment, providing it is the same voltage as the Air Cleaner.

This manual is also suitable for:

Easasd-11ascEasasd-12ascEasasd-18asc
