User Manual
Ascom a71 Alarm Tranceiver and Ascom p71 Transceiver
Display Icons
!
Menu Icons
2009-03-11/ Ver. C
The "Audio signal off" icon is shown when all alert signals,
including ring signal, message tone, key beep etc. are turned off.
High priority messages will however override this setting.
The "Battery" icon is always shown in the display in stand-by mode.
When the level is low it is time to charge the battery.
The "New message" icon appears when a new message is received.
The number on the right side of the icon shows the total number of
unread messages. The symbol will remain until the message is read.
The "Unread message" icon is added in front of not read messages
in the message list.
The "Read message" icon is added in front of read messages in the
message list.
The "Response required" icon is added in front of messages that
requires a response.
The "Response sent" icon is added in front of messages that has
been responded to.
The "Key" icon shows that the keypad is locked.
The "No-movement alarm on" icon shows that the no-movement
alarm is activated.
The "Man-down alarm on" icon shows that the man-down alarm is
activated.
The "Pull-cord alarm on" icon shows that the pull-cord alarm is
activated.
The "Error" icon appears when an error has occured. Service is
needed.
"Messages", see 9.1 Messages
"Profiles", see 9.2 Profiles
"Services", see 9.3 Services
"Settings", see 9.4 Settings
on page 20 for more information.
on page 21 for more information.
on page 22 for more information.
on page 22 for more information.
TD 92417GB
3
