User Manual
Ascom a71 Alarm Tranceiver and Ascom p71 Transceiver
2

Description

This section describes the transceiver and available accessories.
Figure 2.
Soft key field
Soft keys
OK key
Mute button
Menu key
Figure 2. Overview of the transceiver
2.1

General Design

Display
The icons and text in the display shows the current status.
Figure 3.
05:12:06
John Doe
4321
Info
Figure 3. Example of a display configuration in stand-by mode.
The display can be divided into the following segments:
• Icon row - Shows information on active alarms, battery level.
• Date & Time - Shows the date and time.
• Identity - Shows the owner ID.
• Call number - Shows the call number.
• Status - Shows the status of the transceiver. For examples; In charger.
• Soft key field - Shows the user defined function of the three soft keys beneath the
display.
2009-03-11/ Ver. C
LED
Alarm button
13:22
In charger
Doctor Jobs
Pull-cord
C key
Navigation key
Return key
IR-receiver
}
Icon row
}
Date & Time
}
Identity
}
Call number & Status
}
Soft key field (User defined)
TD 92417GB
