Ascom a71 Alarm Tranceiver and Ascom p71 Transceiver
9.1.3

Send Data

The data send function can be used for opening a door, starting/stopping a machine etc.
1 Press
2 Select "Messages".
3 Select "Send Data".
4 Use
• To insert a digit in the middle of the text string, press "Edit", use
where to insert the digit.
• Press "Insert" and insert the digits.
• To remove previous digit, press
5 Enter data and press "Send".
9.2

Profiles

It is possible to for the user to define up to five different profiles in the transceiver. Three
profiles are preset at delivery; Normal, Silent and Loud.
1 Enter the menu by pressing
2 Select "Profiles" and press
3 Navigate the Profiles list using
Figure 14.
Normal
Silent
Loud
Profile 3
Figure 13. Profiles list
The profiles are configured in the PDM and can, for example, consist of different ring
signals and volumes. Another example is when several users are sharing the same
transceiver. Each user can then define their own settings, for example; type of ring signal,
volume, soft key settings etc.
9.2.1

Change Profile

To change profile:
1 Select "Profiles" and press
2 Select the profile with
3 Press
automatically return to the profiles list.
A soft key can be programmed to change profiles, see Configuration Manual for more
information.
2009-03-11/ Ver. C
.
to mark a digit in the virtual digit pad, press
.
.
Profiles
. A list with all profiles is shown.
.
. The name of the marked profile is shown. The transceiver will
.
.
TD 92417GB
to select the digit.
to select
