  • Page 1 User’s Guide Compaq P1100 Color Monitor...
  • Page 2 Compaq Computer Corporation. 1999 Compaq Computer Corporation. All rights reserved. Printed in Singapore. Compaq and Deskpro are registered in the U. S. Patent and Trademark Office. Microsoft, MS-DOS, Windows, Windows NT, and other names of Microsoft products referenced herein are trademarks or registered trademarks of Microsoft Corporation.

  • Page 3: Product Features

    English Product Features The Compaq P1100 Color Monitor is a microprocessor-based, high- resolution monitor with auto-scanning. The monitor features include the following: ?# 21-inch (19.8-in/50.3 cm viewable) FD Trinitron ® ?# 1920 × 1440 resolution, plus full-screen support for lower...
  • Page 4 Compaq platforms ensuring cross- compatibility and backward-compatibility. The resulting solution enables customers to manage and control ongoing software maintenance costs. The UDM is available on the Compaq Support Software CD for Compaq Desktop, Portable, and Workstation Products and the Compaq web site (www.compaq.com).

  • Page 5: Setting Up The Monitor

    Setting Up the Monitor To set up the monitor, ensure that the power is turned off to the monitor, computer system, and other attached devices, then follow these steps: Place the monitor in a convenient, well-ventilated location near your computer. Connect the monitor signal cable 3 to one of the two 15-pin connectors 4 on the rear panel of the computer and tighten the screws.
  • Page 6 WARNING: To reduce the risk of electric shock or damage to your equipment: „ Do not disable the power cord grounding plug. The grounding plug is an important safety feature. ?# Plug the power cord into a grounded (earthed) electrical outlet that is easily accessible at all times.

  • Page 7: Using Usb Connectors

    Using USB Connectors The base of the monitor has five Universal Serial Bus (USB) connectors. Four of these connectors, 1,2,3,and 4, are for connecting USB compatible devices such as a keyboard, mouse, or joystick to the hub. USB connector 5 is used to connect the USB signal cable to the computer.

  • Page 8: Operating The Monitor

    Operating the Monitor Front Panel Controls No./Icon Control Function Reset Button Pressing this button resets the following items: Contrast, brightness, size/center, geometry, screen, zoom, and color. OSD Position, Color Mode, Control Lock, and Language can not be reset. Auto Adjust Provides automatic horizontal and vertical centering and sizing.
  • Page 9 Continued Contrast Button Right arrow increases contrast or is used to adjust selected OSD adjustment item Power Button Turns the monitor on and off. Indicates monitor mode. 1. Green LED indicates monitor is turned on. 2. Alternating Amber/Green LED indicates Standby/Suspend.

  • Page 10: On-Screen Display Settings

    On-Screen Display Settings To adjust screen settings, press the Menu button 6 to launch the on- screen display (OSD). The OSD can be viewed in nine available languages. The following menu shows the functions at each level: Menu Level 1 Menu Level 2 Size/Center Horizontal Centering...
  • Page 11 How to Adjust Screen Settings To launch the on-screen display Main Menu: Press the Menu button 3 on the monitor front panel. The Main Menu will display on the monitor screen. To select an item from the Main Menu, scroll down by pressing the down arrow button 1 located on the monitor front panel.

  • Page 12: Troubleshooting

    A second-level menu displays and adjustment scale. Use the arrow keys 4 or 5 to select a value on the adjustment scale. Press the Menu button 3 to exit from that adjustment. To exit from the on-screen menu, press the Menu button again. Press Reset to return the adjustments to their original settings.

  • Page 13: Adjusting Screen Quality

    Adjusting Screen Quality The optimum screen settings are factory preset. However, to change the settings to your personal preference, allow the monitor to warm up for 30 minutes before performing the following procedures. The screen image stabilizes after a warm-up period. Optimizing Contrast For best results, set your screen to a light background (such as the Windows Desktop) before adjusting the following settings:...

  • Page 14: Display Resolutions

    Display Resolutions The display resolutions listed below are the most commonly used modes and are set as factory defaults. This monitor automatically recognizes these preset modes and they will appear properly sized and centered on the screen. Display Resolutions Preset Modes Resolutions 1.
  • Page 15 The video controller signal may occasionally call for a mode that is not preset if: ?# You are not using a Compaq standard graphics adapter. ?# You are not using a preset mode. If this occurs, you may need to readjust the parameters of the monitor screen by using the on-screen display.

  • Page 16: Energy Saver Feature

    Energy Saver Feature The energy saver feature has three different modes of operation: Full Power Standby/Suspend Sleep By selecting settings in the computer's Energy Saver utility, you are able to determine the length of the inactivity period before the monitor goes into sleep mode.

  • Page 17: Care And Maintenance

    Care and Maintenance This section explains how to care for and maintain your Compaq monitor during normal everyday use. Protecting the Monitor To protect your monitor from overheating and other types of damage, follow these suggestions: „#Use only a power source and connection appropriate for this monitor, as indicated on the marking label/back plate.
  • Page 18 ?# Do not open the monitor cabinet or attempt to service this product yourself. Adjust only those controls that are covered by the operating instructions. If the monitor is not operating properly or has been dropped or damaged, contact your Compaq authorized dealer, reseller, or service provider. Cleaning the Monitor To clean the monitor, follow these steps: Turn off the monitor and the computer.

  • Page 19: Agency Regulatory Notices

    Modifications The FCC requires the user to be notified that if any changes or modifica- tions are made to this device, not expressly approved by Compaq Computer Corporation, this may void the user's authority to operate the equipment.
  • Page 20 For questions regarding your product, contact: Compaq Computer Corporation P.O. Box 692000, Mail Stop 530113 Houston, Texas 77269-2000 Or, call 1-800-652-6672 (1-800-OK COMPAQ) For questions regarding this FCC declaration, contact: Compaq Computer Corporation P.O. Box 692000, Mail Stop 510101 Houston, Texas 77269-2000...
  • Page 21 EPA E program. As an E NERGY NERGY Partner, Compaq Computer Corporation has determined that this product meets the E guidelines for energy efficiency. Specific NERGY details on using the Energy Saving features can be found in the energy saver or power management section of the computer manual.

  • Page 22: Specifications

    Specifications Compaq P1100 Color Monitor Display 21-in 53.3-cm Type Color, FD Trinitron Viewable Image Size 19.8-in 50.2-cm (diagonal) Face Treatment Antireflective and antistatic coating compliant with TCO 1999 requirements Maximum Weight (Unpacked) 70.4-lb 32.0-kg Maximum Dimensions Height 19.9-in 50.6-cm Depth 19.4-in...

  • Page 23: Power Cord

    ).75 mm² or 18AWG. And the length of the cord must be between 6 feet (1.8 m) and 12 feet (3.6 m). If you have questions about the type of power cord to use, contact your Compaq authorized service provider.
