KGUARD Standalone DVR KG-SHA116 User Manual
www.kguardsecurity.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KG-SHA116 and is the answer not in the manual?

Questions and answers

Related Manuals for Kguard KG-SHA116

Summary of Contents for Kguard KG-SHA116

  • Page 1 KGUARD Standalone DVR KG-SHA116 User Manual www.kguardsecurity.com...

  • Page 2: Table Of Contents

    KGUARD Standalone DVR KG-SHA116 User Manual CONTENTS SAFETY INSTRUCTIONS......................... 1 CHAPTER 1. DVR FEATURES ......................2 CHAPTER 2. LAYOUT ........................3 2.1. F ..........................3 RONT ANEL 2.2. R ..........................4 ANEL 2.3 R ........................5 EMOTE ONTROL 2.4 M ........................
  • Page 3 KGUARD Standalone DVR KG-SHA116 User Manual 5.2.5.6. System Maintenance ......................22 5.2.6. Network Setup........................22 5.2.6.1. Intranet/LAN Access Setup ....................22 5.2.6.2. Internet Access Setup .....................23 5.2.6.3. Ports..........................24 CHAPTER 6. NETWORK ACCESS ....................25 6.1. IE & N ......................25 ETVIEWER CCESS 6.1.1. IE Setup ..........................25 6.1.2.

  • Page 4: Safety Instructions

    KGUARD Standalone DVR KG-SHA116 User Manual Safety Instructions Use proper power source. Do not use this product with a power source that applies more than specified voltage (100-240V AC). Never insert anything metallic into the DVR case. Putting something into the DVR case can be a source of dangerous electric shock.

  • Page 5: Chapter 1. Dvr Features

    KGUARD Standalone DVR KG-SHA116 User Manual Chapter 1. DVR Features Real time monitoring Supports real time surveillance via Monitor Save Recordings DVR saves real-time recording image to HDD Backup Recordings Supports DVR backup via USB flash drive and hard drive.

  • Page 6: Chapter 2. Layout

    KGUARD Standalone DVR KG-SHA116 User Manual Chapter 2. Layout 2.1. Front Panel 11 13 15 17 18 19 23 24 12 14 20 21 22 25 title Item Type Marks Function /Indicator CH-1 / Numeric key 1 CH-2 / Numeric key 2...

  • Page 7: Rear Panel

    KGUARD Standalone DVR KG-SHA116 User Manual 2.2. Rear Panel RS485/Sensor/Alarm port functions: Alarm input: Connect [-] port of your sensor to G (GND) pin, and [+] port to channel input you want to set. Alarm output: indicate the two ports marked “out”.

  • Page 8: Remote Control

    KGUARD Standalone DVR KG-SHA116 User Manual 2.3 Remote Control Key Title Key Function Manual recording Enter into recording search menu SEARCH Quad display 2×2 9-CH display 3×3 16-CH display 4×4 AUTO Dwell time display Channel select; numeric key Multiple CH display (Quad, 9-CH, 16-CH and single DISPLAY MODE channel display）...

  • Page 9: Mouse Operation

    KGUARD Standalone DVR KG-SHA116 User Manual 2.4 Mouse Operation You can use a mouse instead of front panel keys or remote control to navigate the operation of your DVR Left button of Mouse In OSD menu, click left button to select & edit...

  • Page 10: Chapter 3. Dvr Installation

    KGUARD Standalone DVR KG-SHA116 User Manual Chapter 3. DVR Installation 3.1. Hard Drive Installation Caution: Please do not Install or take out hard drive when DVR is running! The model has a HDD drawer. Please use provided key to take out the HDD drawer and put HDD into the drawer correctly.

  • Page 11: Chapter 4. Dvr Boot Up

    KGUARD Standalone DVR KG-SHA116 User Manual Chapter 4. DVR Boot Up 4.1. System Initialization After connecting the power adapter the system will boot-up and start initializing. 4.2. Main Interface After initialization, the system will display main interface. When there are video inputs, live images from the cameras will be displayed on screen.

  • Page 12: Chapter 5. Dvr Menu

    KGUARD Standalone DVR KG-SHA116 User Manual Chapter 5. DVR Menu 5.1. Main Menu Preview Camera Title Camera Color setup Record Quality Record Solution Audio Record Record Record Mode Record Schedule Record File Size Network DDNS Setup Video Search Main Menu...

  • Page 13: Main Menu

    KGUARD Standalone DVR KG-SHA116 User Manual 5.2. Main Menu Press Selection button on the front panel or click the right button of mouse to display pop-up menu. Select MAIN MENU to enter main OSD menu. Press ▲, ▼, ◄, keys on front panel to move the cursor, then press Selection key to enter selected item.

  • Page 14: Record Setup

    KGUARD Standalone DVR KG-SHA116 User Manual 5.2.2. Record Setup Functions： RECORD: ON/OFF option decides to record the channel or not. QUALITY: select recording video quality, higher quality will need more HDD space to save the video. RESOLUTION: decides the recording video resolution.

  • Page 15: Manual Recording

    KGUARD Standalone DVR KG-SHA116 User Manual 4. If you want to change another recording status, repeat step 2 & step 3. 5. You can use copy function to fast complete your settings. 6. Press APPLY button to save your settings.

  • Page 16: Playback Interface

    KGUARD Standalone DVR KG-SHA116 User Manual Search All Recorded File: Press SEARCH button, system will search and show you the recorded status. RED color indicates ALARM recoding, GREEN color indicates continuous recording. You can click the time point to play back.

  • Page 17: Video Backup

    KGUARD Standalone DVR KG-SHA116 User Manual 5.2.3.3. Video Backup 1. Insert your USB device (USB hard disk, USB thumb drive) into the bottom USB port on the rear panel. 2. Select one or more files 3. Press BACKUP button on the menu.

  • Page 18: Hdd Format

    KGUARD Standalone DVR KG-SHA116 User Manual 5.2.4.1.1. HDD Format When a new HDD is installed into the DVR, the HDD status will show “NOT FORMATED”. You need to format the HDD otherwise the system cannot record. Select the HDD(s) you want to format and then press the FORMAT HDD icon to format the HDD(s).
  • Page 19 KGUARD Standalone DVR KG-SHA116 User Manual Take GMAIL for example to demonstrate the email setting: 1. Set SSL to “On” via Gmail.com server, and set to “Off” via other mail server. 2. SMTP Port: indicates sender port of SMTP server. Generally the SMTP port value is 25, SMTP port of G-mail server is 465.

  • Page 20: Motion Detection Setup

    KGUARD Standalone DVR KG-SHA116 User Manual 5.2.4.3. Motion Detection Setup STATUS: This option allows you enable motion detection on the channels. SENSITIVITY: This option allows you to set sensitivity level of motion detection from 1 to 4 with 4 being the most sensitive.

  • Page 21: System Setup

    KGUARD Standalone DVR KG-SHA116 User Manual Open auto cruise function on PTZ setting menu if you want to setup cruise function, and set up cruise channel, cruise point, total quantity and stop time (by second) etc. Channel: select the channel with the PTZ camera TOTAL: set up presetting bit (angle) quantity.

  • Page 22: Password

    KGUARD Standalone DVR KG-SHA116 User Manual 5.2.5.2. Password This option allows you set the device ID for the DVR and set the system password if you want to use one. Click APPLY button to save the settings. When you have enabled Password by setting the option to “ON”, you can setup a user password...

  • Page 23: Video Setup

    KGUARD Standalone DVR KG-SHA116 User Manual 5.2.5.3. Video Setup VIDEO SYSTEM: Select the TV system from PAL and NTSC. VIDEO PORT: keep default VGA RESOLUTION: select the VGA video output solution to match your VGA monitor from 800x600, 1024x768, 1280x1024, and 1440x900.

  • Page 24: Language

    KGUARD Standalone DVR KG-SHA116 User Manual (CH10~CH16) and Sixteen CHs Display (CH1~16) This mode will be disabled when the SEQUENCE display mode is ON. DWELL TIME: Allow system to display single channel in full screen or channel group by certain dwell time, and auto-switch in sequence.

  • Page 25: Info

    KGUARD Standalone DVR KG-SHA116 User Manual 5.2.5.5. Info You can check the system information, including Device Type (model No.), Software (firmware) version and MAC address. 5.2.5.6. System Maintenance This option allows you reset the DVR to default settings, update system software (firmware), and config system auto-maintenance.

  • Page 26: Internet Access Setup

    KGUARD Standalone DVR KG-SHA116 User Manual 1. Access the configuration page of your router. 2. Reserve an IP Address in your router that is not used by other computers or devices connected to your internal network. 3. Write down the assigned IP Address of your DVR, Subnet Mask, IP Address of the router (Gateway) your DVR connect to for future reference.

  • Page 27: Ports

    KGUARD Standalone DVR KG-SHA116 User Manual We recommend applying a free DDNS account at www.dyndns.org If your ISP uses STATIC IP network, select STATCI network TYPE. 1. Input the PORT (media port) 2. Input the WEB PORT (Must be different from media PORT) 3.

  • Page 28: Chapter 6. Network Access

    KGUARD Standalone DVR KG-SHA116 User Manual Chapter 6. Network Access There are 3 methods to remote access the DVR via network: Internet Explorer Browser (IE), Netviewer client software & Mobile phones. 6.1. IE & Netviewer Access You can use Netviewer client software & Internet Explorer (IE) 6.0 or newer version to remote access the DVR.

  • Page 29: Connect To Dvr

    KGUARD Standalone DVR KG-SHA116 User Manual after the ActiveX Control has been installed. Enabling all ActiveX controls put your computer at risk of being attacked by computer virus. 6.1.2. Connect to DVR To connect to the DVR from a remote computer, you would then open an Internet Explorer browser window and enter the Internet IP of your router that you received by going to www.myipaddress.com.

  • Page 30: Live

    KGUARD Standalone DVR KG-SHA116 User Manual 6.1.3.1 Live 1. On / Off Live display [ ]: When the live display status is “On”, clicking the button to close live display. When the live display status is “Off”, clicking the button to open live display.

  • Page 31: Remote Backup

    KGUARD Standalone DVR KG-SHA116 User Manual 6.1.3.5. Remote Backup You can backup recorded video files from DVR to your PC using the Replay menu in the remote surveillance software. To backup files remotely: 1. Click REPLAY at the top of the main screen.

  • Page 32: Playback Local File With Netviewer

    KGUARD Standalone DVR KG-SHA116 User Manual 6.1.3.8. Playback Local File with Netviewer Run the Netviewer software, you will see the OFFLINE button displayed on the Login interface. Press this button to enter local file playback mode. Press the ADD button to add backup H.264 files or folder saved in your computer, you will see the files will be listed in the queue window, select a file then press PLAYFILE button to play.

  • Page 33: Mobile Phones Access

    KGUARD Standalone DVR KG-SHA116 User Manual 6.2. Mobile Phones Access This function allows you to view 1 channel live image at the same time with your mobile phone. ® ® The DVR is currently compatible with mobile phones running Windows Mobile, Symbian ®...
  • Page 34 KGUARD Standalone DVR KG-SHA116 User Manual 3. Choose storage location and click “Install” to start the installation. 4. After installation finishes, click the icon named window mobile to run the program. This will display the program screen. 5. Click the “Setting” button to enter the Setting menu.

  • Page 35: Install & Operate Mobile Client In Symbian Phones

    KGUARD Standalone DVR KG-SHA116 User Manual ® 6.2.1.2. Install & Operate Mobile Client in Symbian Phones 1. Install the webcam program that is included on the supplied CD by copying the “Symban_3.0.sisx” (Symbian 3.0 version) or “Symbian_5.0.sis” (Symbian 5.0 version) file to the mobile phone. You can do this by attaching the mobile phone to a computer and copying the file from the CD to the phone.
  • Page 36 KGUARD Standalone DVR KG-SHA116 User Manual 6. Click “Continue” and wait for the program to install. 5. Once the installation is complete, go to the Applications folder and select the “Symbian_5.0” program, and click “Open” to display the settings menu.

  • Page 37: Install & Operate Mobile Client In Iphone

    KGUARD Standalone DVR KG-SHA116 User Manual ® 6.2.1.3. Install & Operate Mobile Client in iPhone Step 1: Download iTunes Visit Apple website http://www.apple.com/itunes/ to download & install the iTunes. Step 2: Download & install surveillance software “Aplayer” 2.1 Register iTunes Store 2.1.1 Run the installed iTunes, you might need to create an account to visit iTunes store firstly.
  • Page 38 KGUARD Standalone DVR KG-SHA116 User Manual 2.1.3 Select & continue 2.1.4 Fill in your personal info & continue. Please note that the options of Payment Method are different from different regions, please select another payment method. Don’t worry, “Aplayer” is free software & you don’t need to pay for it.
  • Page 39 KGUARD Standalone DVR KG-SHA116 User Manual Click the link included in the email message. It will connect to the iTunes store and turn to iTunes interface. Sign in your account. The register of your iTunes store account has been done.
  • Page 40 KGUARD Standalone DVR KG-SHA116 User Manual 2.2 Authorize Computer You need to authorize your computer with the registered ID. Move to the menu “Store”, and click the option “Authorize Computer”. Input your registered ID & password, then click Authorize button.
  • Page 41 KGUARD Standalone DVR KG-SHA116 User Manual 2.3.2 Click the icon and it will turn to the download page. Click the “GET APP” button to download the file. You will find the downloaded file on the directory of Application 2.3.3 Connect your iPhone to the computer, you will find your Device displayed on the left sidebar.
  • Page 42 KGUARD Standalone DVR KG-SHA116 User Manual The devices ID is different from different iPhones. After finishing the sync, you will find the Aplayer Icon on your iPhone Step 3: Setup & run “Aplayer” Main interface of Aplayer & function keys: Ⅰ...

  • Page 43: Blackberry Handheld Application Installation Guide

    KGUARD Standalone DVR KG-SHA116 User Manual 6.2.1.4. Blackberry Handheld Application Installation Guide 1. Install the Blackberry desktop manager on the computer; 2. Connect the handheld to computer using the USB port; 3. Open the Blackberry desktop manager; 4. Select the [Application Loader] item in the main menu;...
  • Page 44 KGUARD Standalone DVR KG-SHA116 User Manual 6. Browse and open the [*.alx] file then click [Next]; 7. Just click the [Finish] button to complete the installation. www.kguardsecurity.com...
  • Page 45 KGUARD Standalone DVR KG-SHA116 User Manual The startup shortcuts are usually located in the Downloads directory. Main screen of the application. www.kguardsecurity.com...

  • Page 46: Chapter 7. Specifications

    KGUARD Standalone DVR KG-SHA116 User Manual Chapter 7. Specifications Model KG-SHA116 H.264 Video Compression Video System NTSC / PAL Operation System Linux Video Input / BNC 16-channel / VGA 1-channel & BNC 2-channel Output Audio Input / Output BNC 4-channel / 1-channel, 1channel spot out...

  • Page 47: Chapter 8. System Connection Configuration

    KGUARD Standalone DVR KG-SHA116 User Manual Chapter 8. System Connection Configuration www.kguardsecurity.com...

  • Page 48: Chapter 9. Appendix

    KGUARD Standalone DVR KG-SHA116 User Manual Chapter 9. Appendix 9.1 Operation Function Table Type Title Description Page Time setting Setting system date, time and format and day-light saving time setting Language Select Setting system language Setting CH title and position; adjusting image color parameter value; setting CH CH Setting display to ON / Off and time display/recording time overlaying to On/Off.

  • Page 49: Recording Alarm Setting

    KGUARD Standalone DVR KG-SHA116 User Manual 9.2 Recording Alarm setting ⊥ Please refer the below matrix: “ ” stand for “only alarm but no recording”; “AMR” stand for “alarm recording”; “NLR” stand for “normal recording”; and “NOR” stand for “ no recording”. Once alarm is triggered, alarm icon will occur, and when many alarms are triggered, alarm remarks will occur on the screen.

  • Page 50: Mail Server Check List

    KGUARD Standalone DVR KG-SHA116 User Manual 9.4. Email server check list （The below info only for your ref.） （Web site） Email address Sender server（25） Receiver server（110） @yahoo.com.tw smtp.mail.yahoo.com.tw pop.mail.yahoo.com.tw www.yahoo.com @yahoo.com smtp.mail.yahoo.com pop.mail.yahoo.com www.google.com @gmail.com smtp.gmail.com(465/587) pop.gmail.com(995) 9.5. Usage Maintenance 1.

  • Page 51: Hdd Device Support List

    KGUARD Standalone DVR KG-SHA116 User Manual 9.7 HDD Device Support List SHA Series – SATA HDD Support Suggestion Brand Model No. Note Capacity ST380815AS 160G ST3160815SV ST3250310SV ST3250410AS 250G ST3250312CS ST3250310SV 320G ST3320410SV ST3500312CS Seagate ST3500320AS 500G ST3500320SV Special design for Standalone DVR.

  • Page 52: Cell Phone Support List

    KGUARD Standalone DVR KG-SHA116 User Manual 160G HD161HJ 500G HD501IJ/CNG 9.8 3G Cell Phone Support List 3G Cell phone Support Suggestion Brand Model No. Note Nokia Motorola E770 SE K600i SE k700i Sony Ericsson SE 700i SE 800i Z610i Samsung...
  • Page 53 The material in this document is the intellectual property of our department . No part of this manual may reproduced, copied, translated, transmitted, or published in any form or by any means without our department prior writt en permission. Our products are under continual improvement and we reserve the right t o make changes without noti ce.
