14,000 btu 4-in-1 portable evaporative air conditioner and heat pump

Advertisement

Before using this air conditioner, please read the following instructions carefully and keep
this manual along with your proof of purchase in a safe place for future reference.
OWNER'S MANUAL
4-IN-1 PORTABLE EVAPORATIVE
AIR CONDITIONER AND HEAT PUMP
MODEL : 13-04543 (KY-36)
© Copyright, Sunrise Tradex Corp., 2005
001186-30/11/05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 13-04543 and is the answer not in the manual?

Questions and answers

Summary of Contents for ForestAir 13-04543

  • Page 1 Before using this air conditioner, please read the following instructions carefully and keep this manual along with your proof of purchase in a safe place for future reference. OWNER’S MANUAL 4-IN-1 PORTABLE EVAPORATIVE AIR CONDITIONER AND HEAT PUMP MODEL : 13-04543 (KY-36) © Copyright, Sunrise Tradex Corp., 2005 001186-30/11/05...
  • Page 2: Table Of Contents

    TABLE OF CONTENTS USE ................3 SAFETY NOTES ............3 LCDI POWER CORD AND PLUG ......4 UNIT DIAGRAM Front ................5 Back ................5 Accessories ..............5 INSTALLATION Choosing the location ..........6 Mounting the exhaust hose ........6 Window kit installation ..........7 CONTROL PANEL AND LCD DISPLAY Control panel ............
  • Page 3: Use

    16. Always check the power cord for signs of damage before use. If the power cord is damaged, contact SUNRISE TRADEX Customer Service (see page 15). 17. Do not place a plant or allow a pet to be exposed directly to the unit cool air flow.
  • Page 4: Lcdi Power Cord And Plug

    If a TEST is performed and the pilot light remains ON, a current leakage has been detected. Do not use the air conditioner and/or attempt to reset the LCDI plug. Immediately contact SUNRISE TRADEX Customer Service for technical support (see page 15). TEST BUTTON...
  • Page 5: Unit Diagram

    UNIT DIAGRAM Air outlet Control panel FRONT Vertical air louvers Horizontal air louvers Power cord and Casters plug BACK Lower air inlet grill Hot air outlet grill ACCESSORIES Drain tube Drain pan 3/8” screw 1pc Exhaust Hose Round Adaptor Window Kit Adaptor Adjustable Window Square Adaptor...
  • Page 6: Installation

    INSTALLATION CHOOSING THE LOCATION Place the unit on a level surface in a cleared out area where the air outlets cannot be obstructed. For a maximum efficiency, keep a clearance of at least 50 cm (20”) front and rear of the unit. MOUNTING THE EXHAUST HOSE Slide the square end of the exhaust hose over the hot air outlet on the back of the unit.
  • Page 7: Window Kit Installation

    INSTALLATION WINDOW KIT INSTALLATION Casement window : It is recommended to replace the screen with a clear plexiglass panel (1/4'') fitted to the size of your window screen. Cut a hole to the same size as the end of the exhaust HUNG SLIDING CASEMENT...
  • Page 8: Control Panel And Lcd Display

    CONTROL PANEL AND LCD DISPLAY Press this button to turn the unit on or off. Press this button to select one of the following modes : auto, cooling, MODE dehumidifying, fan or heating. Turns the timer on or off. TIMER Increases room temperature or the hours when the timer is on.
  • Page 9: Unit Operation

    UNIT OPERATION Plug the power cord into a properly rated grounded outlet. Do not connect the unit to an outlet that is being used for other electrical appliances. The unit will beep after two seconds, then press the Power button to begin operation. COOLING 1.
  • Page 10: Setting The Timer

    UNIT OPERATION SETTING THE TIMER When the unit is operating, the timer can be used to set an automatic shut off time. If the unit is off but still plugged, the timer can be used to set an automatic start time. If the timer button is not pressed, the unit will run continuously.
  • Page 11: Remote Control

    REMOTE CONTROL SWING : turns the oscillation on or off. MODE : to select Cooling, Dehumidifying, Heating FAN : to set fan or Auto. speed. TEMPERATURE/TIME °C/°F auto-conversion settings when using the timer. SLEEP mode (can be only programmed with remote. TIMER : turns the timer on or off.
  • Page 12: Water Drainage

    WATER DRAINAGE When the unit is in cooling mode, the air humidity is converted in water used to cool down the unit. When the unit is used in extremely humid environment, exceeding water will be drained into a pan located at the bottom of the unit. When the water pan is full, the compressor will stop but the fan will continue to run.
  • Page 13: Maintenance

    MAINTENANCE Always turn off and unplug the unit before cleaning to avoid electrical shock. CLEANING THE HOUSING • Wipe the surface of the unit with a soft damp cloth. Cleaning the unit with gasoline, paint thinner, chemical products or abrasive detergent could damage it.
  • Page 14: Troubleshooting

    Room temperature is not within the working Place unit in proper operating conditions. range of the unit. FAULT E2 Faulty coils. Contact SUNRISE TRADEX Customer Service. FAULT E3 Frost inside the unit. Wait for unit to defrost. FAULT E4 Unit malfunctions.
  • Page 15: Technical Specifications

    Power Source 115V / 60Hz Rated Cooling 12.0A Current Heating 9.8A Sound Pressure Level <49 db(A) Weight 36.3 Kg (80 lbs) Dimensions 36.5(W)x56.8(D)x77.4(H)cm 14.4”(W)x22.4”(D)x30.5”(H) Refrigerant CONTACT INFORMATION Contact SUNRISE TRADEX Customer Service for: Replacement parts Technical support Warranty claims Customer service...
  • Page 16: Warranty

    ALL IMPLIED WARRANTIES, INCLUDING ANY IMPLIED WARRANTY OF MERCHANTABILITY, ARE LIMITED TO A TWO YEAR (2) PERIOD COVERED BY THIS EXPRESS LIMITED WARRAN- TY. SUNRISE TRADEX CORP. DISCLAIMS ANY LIABILITY FOR CONSEQUENTIAL OR INCI- DENTAL DAMAGES AND, IN NO EVENT, SHALL SUNRISE TRADEX CORP. LIABILITY EXCEEED THE RETAIL VALUE OF THE PORTABLE AIR CONDITIONER FOR BREACH OF ANY WRITTEN OR IMPLIED WARRANTY WITH RESPECT TO THIS PORTABLE AIR CONDITIONER.

This manual is also suitable for:

Ky-36
