  • Page 1 UPER ® UPER ERVER 1018D-73MTF USER’S MANUAL...
  • Page 2 The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes no commitment to update or to keep current the information in this manual, or to notify any person or organization of the updates.

  • Page 3: About This Manual

    About This Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 1018D-73MTF. Installation and maintenance should be performed by experienced technicians only. The SuperServer 1018D-73MTF is a high-end server based on the SC113MTQ- 330CB 1U rackmount chassis and the Super X10SL7-F processor motherboard.
  • Page 4 UPER ERVER 1018D-73MTF User's Manual Chapter 5: Advanced Motherboard Setup Chapter 5 provides detailed information on the X10SL7-F motherboard, including the locations and functions of connections, headers and jumpers. Refer to this chapter when adding or removing processors or main memory and when reconfi guring the motherboard.
  • Page 5 Preface Notes...

  • Page 6: Table Of Contents

    UPER ERVER 1018D-73MTF User's Manual Table of Contents Chapter 1 Introduction Overview ......................1-1 Motherboard Features ..................1-2 Processors ...................... 1-2 Memory ......................1-2 SAS ......................... 1-2 SATA ........................ 1-2 I/O Ports ......................1-2 Server Chassis Features ................1-3 System Power ....................1-3 Control Panel ....................
  • Page 7 Table of Contents Control Panel Buttons ..................3-1 Reset ....................... 3-1 Power ......................3-1 UID ........................3-1 Control Panel LEDs ..................3-2 NIC2 ........................ 3-2 NIC1 ........................ 3-2 HDD ......................... 3-2 Power ......................3-2 Overheat/Fan Fail/UID LED ................3-3 Hard Drive Carrier LEDs ................. 3-3 Chapter 4 Standardized Warning Statements for AC Systems About Standardized Warning Statements ............
  • Page 8 UPER ERVER 1018D-73MTF User's Manual Installing Memory .................... 5-7 Memory Population Guidelines ............... 5-8 Adding PCI Cards ................... 5-9 Motherboard Details ..................5-10 X10SL7-F Quick Reference ................5-10 Connector Defi nitions ................... 5-12 Jumper Settings .................... 5-19 5-10 Onboard Indicators ..................5-22 5-11 SAS/SATA Ports ....................

  • Page 9: Chapter 1 Introduction

    Chapter 1 Introduction Overview The SuperServer 1018D-73MTF is a high-end server comprised of two main subsystems: the SC113MTQ-330CB 1U server chassis and the X10SL7-F single processor motherboard. Please refer to our web site for information on operating systems that have been certifi ed for use with the system (www.supermicro.com).

  • Page 10: Motherboard Features

    ERVER 1018D-73MTF User's Manual Motherboard Features At the heart of the SuperServer 1018D-73MTF lies the X10SL7-F, a single proces- sor motherboard based on Intel's C222 chipset. Below are the main features of the X10SL7-F (see Figure 1-1 for a block diagram of the chipset).

  • Page 11: Server Chassis Features

    The following is a general outline of the main features of the SC113MTQ-330CB chassis. System Power When confi gured as the SuperServer 1018D-73MTF, the SC113MTQ-330CB chas- sis includes a single 330W high-effi ciency power supply. Control Panel The control panel on the SC113MTQ-330CB provides important system monitoring and control information.

  • Page 12: System Block Diagram

    UPER ERVER 1018D-73MTF User's Manual Figure 1-1. Intel C222 Chipset: System Block Diagram Note: This is a general block diagram. Please see Chapter 5 for details. PCIe3.0_x8 DDR3 (CHA) DIMM1 PCIe x16 SLOT Intel 8.0Gb DIMM2(Far) 1600/1333MHz i3/i5/i7 Processor 4 UDIMM...

  • Page 13: Contacting Supermicro

    Chapter 1: Introduction Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Web Site: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML 's-Hertogenbosch, The Netherlands Tel:...
  • Page 14 UPER ERVER 1018D-73MTF User's Manual Notes...

  • Page 15: Chapter 2 Server Installation

    Precautions in the next section. Preparing for Setup The box the SuperServer 1018D-73MTF was shipped in should include two sets of rail assemblies, two rail mounting brackets and the mounting screws you will need to install the system into the rack. Follow the steps in the order given to complete the installation process in a minimum amount of time.

  • Page 16: Warnings And Precautions

    UPER ERVER 1018D-73MTF Manual • This product is not suitable for use with visual display work place devices acccording to §2 of the the German Ordinance for Work with Visual Display Units. Warnings and Precautions Rack Precautions • Ensure that the leveling jacks on the bottom of the rack are fully extended to the fl...

  • Page 17: Rack Mounting Considerations

    Chapter 2: Server Installation Rack Mounting Considerations Ambient Operating Temperature If installed in a closed or multi-unit rack assembly, the ambient operating tempera- ture of the rack environment may be greater than the ambient temperature of the room. Therefore, consideration should be given to installing the equipment in an environment compatible with the manufacturer’s maximum rated ambient tempera- ture (Tmra).

  • Page 18: Installing The System Into A Rack

    This section provides information on installing the SuperServer 1018D-73MTF into a rack. If the 1018D-73MTF has already been mounted into a rack, you can skip ahead to Sections 2-5 and 2-6. Note: The rails will fi t a rack between 26" and 33.5" deep.

  • Page 19: Inner Rails

    Chapter 2: Server Installation Inner Rails The SC113MTQ chassis includes a set of inner rails in two sections: inner rails and inner rail extensions. The inner rails are pre-attached and do not interfere with normal use of the chassis if you decide not to use a server rack. Attach the inner rail extension to stabilize the chassis within the rack.

  • Page 20: Outer Rails

    UPER ERVER 1018D-73MTF Manual Outer Rails Installing the Outer Rails to the Rack (Figures 2-3 and 2-4) 1. Attach the short bracket to the outside of the long bracket. You must align the pins with the slides. Also, both bracket ends must face the same direction.
  • Page 21 Chapter 2: Server Installation SCALE 0.380 Figure 2-4. Installing the Outer Rails to the Rack...
  • Page 22 UPER ERVER 1018D-73MTF Manual Installing the Chassis into a Rack (Figure 2-5) 1. Confi rm that chassis includes the inner rails and rail extensions . Also, confi rm that the outer rails are installed on the rack. 2. Line chassis rails with the front of the rack rails.

  • Page 23: Installing The Server Into A Telco Rack

    Chapter 2: Server Installation Installing the Server into a Telco Rack To install the SuperServer 1018D-73MTF into a Telco type rack, use two L-shaped brackets on either side of the chassis (four total). First, determine how far follow the server will extend out the front of the rack. Larger chassis should be positioned to balance the weight between front and back.
  • Page 24 UPER ERVER 1018D-73MTF Manual Notes 2-10...

  • Page 25: Chapter 3 System Interface

    Chapter 3: System Interface Chapter 3 System Interface Overview There are several LEDs on the control panel to keep you constantly informed of the overall status of the system as well as the three buttons described below. Control Panel Buttons There are three buttons located on the front of the chassis: a UIB button, a reset button and a power on/off button.

  • Page 26: Control Panel Leds

    UPER ERVER 1018D-73MTF Manual Control Panel LEDs The control panel located on the front of the SC113MTQ chassis has fi ve LEDs. These LEDs provide you with critical information related to different parts of the system. This section explains what each LED indicates when illuminated and any corrective action you may need to take.

  • Page 27: Overheat/Fan Fail/Uid Led

    Chapter 3: System Interface Overheat/Fan Fail/UID LED When this LED fl ashes it indicates a fan failure. When continuously on (not fl ashing) it indicates an overheat condition, which may be caused by cables obstructing the airfl ow in the system or the ambient room temperature being too warm. Check the routing of the cables and make sure that all fans are present and op- erating normally.
  • Page 28 UPER ERVER 1018D-73MTF Manual Notes...

  • Page 29: Chapter 4 Standardized Warning Statements For Ac Systems

    Chapter 4: Warning Statements for AC Systems Chapter 4 Standardized Warning Statements for AC Systems About Standardized Warning Statements The following statements are industry standard warnings, provided to warn the user of situations which have the potential for bodily injury. Should you have questions or experience difficulty, contact Supermicro's Technical Support department for assistance.
  • Page 30 UPER ERVER 1018D-73MTF User's Manual Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befi nden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut.
  • Page 31 Warning Statements for AC Systems ‫ﺟﺴﺪﻳﺔ‬ ‫ﺍﺻﺎﺑﺔ‬ ‫ﺗﺘﺴﺒﺐ ﻓﻲ‬ ‫ﺣﺎﻟﺔ ﻳﻤﻜﻦ ﺃﻥ‬ ‫ﺍﻧﻚ ﻓﻲ‬ ‫ﺧﻄﺮ‬ ‫ﻳﻌﻨﻲ‬ ‫ﻫﺬﺍ ﺍﻟﺮﻣﺰ‬ !‫ﺗﺤﺬﻳﺮ‬ ‫ﺍﻟﺪﻭﺍﺋﺮ‬ ‫ﺑﺎﻟﻤﺨﺎﻁﺮ ﺍﻟﻨﺎﺟﻤﺔ ﻋﻦ‬ ‫ﻦ ﻋﻠﻰ ﻋﻠﻢ‬ ، ‫ﻛ‬ ‫ﻣﻌﺪﺍﺕ‬ ‫ﺗﻌﻤﻞ ﻋﻠﻰ ﺃﻱ‬ ‫ﻗﺒﻞ ﺃﻥ‬ ‫ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬ ‫ﺣﻮﺍﺩﺙ‬ ‫ﺃﻱ‬ ‫ﻭﻗﻮﻉ‬ ‫ﻤﻨﻊ‬ ‫ﻟ‬ ‫ﺍﻟﻮﻗﺎﺋﻴﺔ‬...

  • Page 32: Installation Instructions

    UPER ERVER 1018D-73MTF User's Manual Installation Instructions Warning! Read the installation instructions before connecting the system to the power source. 警告 将此系统连接电源前,请先阅读安装说明。 警告 將系統與電源連接前，請先閱讀安裝說明。 Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación.

  • Page 33: Circuit Breaker

    Chapter 4: Warning Statements for AC Systems Circuit Breaker Warning! This product relies on the building's installation for short-circuit (overcurrent) protection. Ensure that the protective device is rated not greater than: 250 V, 20 A. 警告 此产品的短路(过载电流)保护由建筑物的供电系统提供,确保短路保护设备的额定电 流不大于250V,20A。 警告 此產品的短路(過載電流)保護由建築物的供電系統提供,確保短路保護設備的額定電 流不大於250V,20A。...

  • Page 34: Power Disconnection Warning

    UPER ERVER 1018D-73MTF User's Manual Waarschuwing Dit product is afhankelijk van de kortsluitbeveiliging (overspanning) van uw electrische installatie. Controleer of het beveiligde aparaat niet groter gedimensioneerd is dan 220V, 20A. Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components.
  • Page 35 Chapter 4: Warning Statements for AC Systems ¡Advertencia! El sistema debe ser disconnected de todas las fuentes de energía y del cable eléctrico quitado de los módulos de fuente de alimentación antes de tener acceso el interior del chasis para instalar o para quitar componentes de sistema. Attention Le système doit être débranché...

  • Page 36: Equipment Installation

    UPER ERVER 1018D-73MTF User's Manual Equipment Installation Warning! Only trained and qualifi ed personnel should be allowed to install, replace, or service this equipment. 警告 只有经过培训且具有资格的人员才能进行此设备的安装、更换和维修。 警告 只有經過受訓且具資格人員才可安裝、更換與維修此設備。 Warnung Das Installieren, Ersetzen oder Bedienen dieser Ausrüstung sollte nur geschultem, qualifi ziertem Personal gestattet werden.

  • Page 37: Restricted Area

    Chapter 4: Warning Statements for AC Systems Waarschuwing Deze apparatuur mag alleen worden geïnstalleerd, vervangen of hersteld door geschoold en gekwalifi ceerd personeel. Restricted Area Warning! This unit is intended for installation in restricted access areas. A restricted access area can be accessed only through the use of a special tool, lock and key, or other means of security.

  • Page 38: Battery Handling

    UPER ERVER 1018D-73MTF User's Manual ‫אזור עם גישה מוגבלת‬ !‫אזהרה‬ ‫יש להתקין את היחידה באזורים שיש בהם הגבלת גישה. הגישה ניתנת בעזרת‬ .('‫כלי אבטחה בלבד )מפתח, מנעול וכד‬ ‫ﻣﺤﻈﻮﺭﺓ‬ ‫ﻣﻨﺎﻁﻖ‬ ‫ﻟﺘﺮﻛﻴﺒﻬﺎ ﻓﻲ‬ ‫ﻫﺬﻩ ﺍﻟﻮﺣﺪﺓ‬ ‫ﺗﺨﺼﻴﺺ‬ ‫ﺗﻢ‬ ،‫ﺃﺩﺍﺓ ﺧﺎﺻﺔ‬ ‫ﻣﻦ ﺧﻼﻝ ﺍﺳﺘﺨﺪﺍﻡ‬...
  • Page 39 Chapter 4: Warning Statements for AC Systems Warnung Bei Einsetzen einer falschen Batterie besteht Explosionsgefahr. Ersetzen Sie die Batterie nur durch den gleichen oder vom Hersteller empfohlenen Batterietyp. Entsorgen Sie die benutzten Batterien nach den Anweisungen des Herstellers. Attention Danger d'explosion si la pile n'est pas remplacée correctement. Ne la remplacer que par une pile de type semblable ou équivalent, recommandée par le fabricant.

  • Page 40: Redundant Power Supplies

    UPER ERVER 1018D-73MTF User's Manual Redundant Power Supplies Warning! This unit might have more than one power supply connection. All connections must be removed to de-energize the unit. 警告 此部件连接的电源可能不止一个，必须将所有电源断开才能停止给该部件供电。 警告 此裝置連接的電源可能不只一個，必須切斷所有電源才能停止對該裝置的供電。 Warnung Dieses Gerät kann mehr als eine Stromzufuhr haben. Um sicherzustellen, dass der Einheit kein trom zugeführt wird, müssen alle Verbindungen entfernt werden.

  • Page 41: Backplane Voltage

    Chapter 4: Warning Statements for AC Systems ‫ﺍﻣﺪﺍﺩ ﺍﻟﻄﺎﻗﺔ‬ ‫ﺑﻮﺣﺪﺍﺕ‬ ‫ﻋﺪﺓ ﺍﺗﺼﺎﻻﺕ‬ ‫ﺠﻬﺎﺯ‬ ‫ﺍﻟ‬ ‫ﻳﻜﻮﻥ ﻟﻬﺬﺍ‬ ‫ﻗﺪ‬ ‫ﺍﻟﻜﻬﺮﺑﺎء‬ ‫ﻋﻦ‬ ‫ﻮﺣﺪﺓ‬ ‫ﺍﻟ‬ ‫ﻟﻌﺰﻝ‬ ‫ﻛﺎﻓﺔ ﺍﻻﺗﺼﺎﻻﺕ‬ ‫ﻳﺠﺐ ﺇﺯﺍﻟﺔ‬ Waarschuwing Deze eenheid kan meer dan één stroomtoevoeraansluiting bevatten. Alle aansluitingen dienen verwijderd te worden om het apparaat stroomloos te maken. Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is...

  • Page 42: Comply With Local And National Electrical Codes

    UPER ERVER 1018D-73MTF User's Manual ‫מתח בפנל האחורי‬ !‫הרה‬ ‫אז‬ ‫קיימת סכנת מתח בפנל האחורי בזמן תפעול המערכת. יש להיזהר במהלך‬ .‫העבודה‬ ‫ﺍﻟﻠﻮﺣﺔ‬ ‫ﺃﻭﺍﻟﻄﺎﻗﺔ ﺍﻟﻤﻮﺟﻮﺩﺓ ﻋﻠﻰ‬ ‫ﺍﻟﺘﻴﺎﺭ ﺍﻟﻜﻬﺮﺑﺎﺋﻲ‬ ‫ﻣﻦ‬ ‫ﺧﻄﺮ‬ ‫ﻫﻨﺎﻙ‬ ‫ﻫﺬﺍ ﺍﻟﺠﻬﺎﺯ‬ ‫ﺧﺪﻣﺔ‬ ‫ﻛﻦ ﺣﺬﺭﺍ ﻋﻨﺪ‬ ‫ﻳﻌﻤﻞ‬ ‫ﺍﻟﻨﻈﺎﻡ‬ ‫ﻋﻨﺪﻣﺎ ﻳﻜﻮﻥ‬...

  • Page 43: Product Disposal

    Chapter 4: Warning Statements for AC Systems Attention L'équipement doit être installé conformément aux normes électriques nationales et locales. ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ ‫הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫התקנת‬ ‫ﺍﻟﻤﺘﻌﻠﻘﺔ‬ ‫ﺍﻟﻤﺤﻠﻴﺔ ﻭﺍﻟﻮﻁﻨﻴﺔ‬ ‫ﻘﻮﺍﻧﻴﻦ‬ ‫ﻳﺠﺐ ﺃﻥ ﻳﻤﺘﺜﻞ ﻟﻠ‬ ‫ﺍﻟﻜﻬﺮﺑﺎﺋﻴﺔ‬...

  • Page 44: Hot Swap Fan Warning

    UPER ERVER 1018D-73MTF User's Manual ¡Advertencia! Al deshacerse por completo de este producto debe seguir todas las leyes y reglamentos nacionales. Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent.
  • Page 45 Chapter 4: Warning Statements for AC Systems 警告 當您從機架移除風扇裝置，風扇可能仍在轉動。小心不要將手指、螺絲起子和其他 物品太靠近風扇。 Warnung Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt. ¡Advertencia! Los ventiladores podran dar vuelta cuando usted quite ell montaje del ventilador del chasis.

  • Page 46: Power Cable And Ac Adapter

    UPER ERVER 1018D-73MTF User's Manual Power Cable and AC Adapter Warning! When installing the product, use the provided or designated connection cables, power cables and AC adaptors. Using any other cables and adaptors could cause a malfunction or a fi re. Electrical Appliance and Material Safety Law prohibits the use of UL or CSA -certifi...
  • Page 47 Chapter 4: Warning Statements for AC Systems Attention Lors de l'installation du produit, utilisez les bables de connection fournis ou désigné. L'utilisation d'autres cables et adaptateurs peut provoquer un dysfonctionnement ou un incendie. Appareils électroménagers et de loi sur la sécurité Matériel interdit l'utilisation de UL ou CSA câbles certifi...
  • Page 48 UPER ERVER 1018D-73MTF User's Manual Notes 4-20...

  • Page 49: Chapter 5 Advanced Motherboard Setup

    Chapter 5: Advanced Motherboard Setup Chapter 5 Advanced Motherboard Setup This chapter covers the steps required to install processors and heatsinks to the X10SL7-F motherboard, connect the data and power cables and install add-on cards. All motherboard jumpers and connections are described and a layout and quick reference chart are included in this chapter.

  • Page 50: Processor And Heatsink Installation

    UPER ERVER 1018D-73MTF User's Manual Processor and Heatsink Installation Warning: When handling the processor package, avoid placing direct pressure on the label area of the fan. Notes: • Always connect the power cord last and always remove it before adding, re- moving or changing any hardware components.
  • Page 51 Chapter 5: Advanced Motherboard Setup 5. Align the CPU key, which is a semi- circle cutout, against the socket CPU Key key, which is the notch below the gold color dot on the side of the socket. 6. Align pin 1 of the CPU against pin 1 of the CPU socket.

  • Page 52: Installing A Cpu Heatsink

    UPER ERVER 1018D-73MTF User's Manual Installing a CPU Heatsink 1. Remove power from the system and unplug the AC power cord from the power supply. 2. Do not apply any thermal grease to the heatsink or the CPU die; the required amount has already been applied.

  • Page 53: Connecting Cables

    Chapter 5: Advanced Motherboard Setup Connecting Cables Now that the processors are installed, the next step is to connect the cables to the motherboard. These include the data (ribbon) cables for the peripherals and control panel and the power cables. Connecting Data Cables The cables used to transfer data from the peripheral devices have been carefully routed in preconfi...

  • Page 54: I/O Ports

    UPER ERVER 1018D-73MTF User's Manual Figure 5-2. Front Control Panel Header Pins (JF1) Ground Power LED HDD LED NIC1 LED NIC2 LED OH/Fan Fail LED PWR Fail LED Reset Reset Button Ground Power Button Ground I/O Ports The I/O ports are color coded in conformance with the PC 99 specifi cation. See Figure 5-3 below for the colors and locations of the various I/O ports.

  • Page 55: Installing Memory

    Chapter 5: Advanced Motherboard Setup Installing Memory Note: Check the Supermicro web site for recommended memory modules. CAUTION Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Installing DIMMs Insert the desired number of DIMMs into the memory slots, starting with the DIMMA1 slot.

  • Page 56: Memory Population Guidelines

    UPER ERVER 1018D-73MTF User's Manual Memory Population Guidelines Please follow the table below when populating the X10SL7-F. DDR3 Unbuffered ECC (UDIMM) Memory DIMM Slots per DIMMs Populat- Ranks per DIMM (any DIMM Type POR Speeds Channel ed per Channel combination)

  • Page 57: Adding Pci Cards

    Chapter 5: Advanced Motherboard Setup Adding PCI Cards PCI Expansion Slots One riser card is used to support a PCI expansion (add-on) card in the system. The SC113MTQ chassis can accommodate one standard size (full height full length) PCI expansion card. When viewed from the chassis front, the card installs to the left rear of the system.

  • Page 58: Motherboard Details

    UPER ERVER 1018D-73MTF User's Manual Motherboard Details Figure 5-5. SUPER X10SL7-F Layout USB2/3 COM1 USB4/5 COM2 LAN2 LAN1 IPMI _LAN CTRL CTRL IPMI CODE BAR CODE MAC CODE SAS CODE SPKR1 X10SL7-F Rev. 1.01 BIOS CPU1 Battery JBT1 LEDS2 USB1 (3.0)
  • Page 59 Chapter 5: Advanced Motherboard Setup Connector Description COM1/COM2 COM1 (Port)/COM2 (Header) Fan1 - Fan4, System/CPU Fan Headers FanA Front Panel Control Header Chassis Intrusion Header JLED1 Power LED Indicator Header Power SMB (System Management Bus) JPW1 24-pin ATX Main Power Connector (Required) JPW2 +12V 8-pin CPU power Connector (Required) JSD1...

  • Page 60: Connector Defi Nitions

    UPER ERVER 1018D-73MTF User's Manual Connector Defi nitions ATX Power 24-pin Connector Pin Defi nitions (JPW1) Pin# Defi nition Pin # Defi nition Power Connectors +3.3V +3.3V The 24 - pin main power connector -12V +3.3V (JPW1) is used to provide power to the motherboard.
  • Page 61 Chapter 5: Advanced Motherboard Setup NIC1/NIC2 (LAN1/LAN2) GLAN1/2 LED Pin Defi nitions (JF1) The NIC (Network Interface Controller) Pin# Defi nition LED connection for LAN port 1 is located on pins 11 and 12 of JF1, and the LED NIC 2 Link/Acitivty connection for LAN Port 2 is on pins 9 and 10.
  • Page 62 UPER ERVER 1018D-73MTF User's Manual Power Button The Power Button connection is located on pins 1 and 2 of JF1. Momentarily Power Button Pin Defi nitions (JF1) contacting both pins will power on/off the Pin# Defi nition system. This button can also be confi g-...
  • Page 63 Chapter 5: Advanced Motherboard Setup Fan Headers The X10SL7-F has fi ve fan headers (Fan1 - Fan4 and FanA). These are all 4-pin fan Fan Header Pin Defi nitions headers, however pins 1-3 are backward Pin# Defi nition compatible with traditional 3-pin fans. Fan speed is controlled via IPMI based on the Ground (Black) system temperature.
  • Page 64 UPER ERVER 1018D-73MTF User's Manual DOM PWR Connector DOM PWR Pin Defi nitions The Disk-On-Module (DOM) power con- Pin# Defi nition nector (JSD1) provides 5V power to a solid state DOM storage device con- Ground nected to one of the SATA ports. See the Ground table on the right for pin defi...
  • Page 65 Chapter 5: Advanced Motherboard Setup LAN Ports Pin Defi nition Pin# Defi nition Ethernet Ports P2V5SB SGND Two Gigabit Ethernet ports (LAN1/2) TD0+ Act LED are located on the I/O backplane on the TD0- P3V3SB motherboard to provide internet con- TD1+ Link 100 LED (Yel- nections.
  • Page 66 UPER ERVER 1018D-73MTF User's Manual Onboard Power LED (JLED1) Onboard PWR LED Pin Defi nitions An onboard Power LED header is lo- Pin# Defi nition cated at JLED1. This Power LED header connects to JF1 to indicate the status of No Connection system power.

  • Page 67: Jumper Settings

    Chapter 5: Advanced Motherboard Setup Jumper Settings Explanation of Jumpers To modify the operation of the mother- board, jumpers can be used to choose Connector between optional settings. Jumpers cre- Pins ate shorts between two pins to change the function of the connector. Pin 1 is Jumper identifi...
  • Page 68 UPER ERVER 1018D-73MTF User's Manual PCI-E Slot SMB Enable (I C1/I PCI-E Slot_SMB Enable Use Jumpers I C1/I C2 to enable PCI-E Jumper Settings SMB (System Management Bus) support Jumper Setting Defi nition to improve system management for the Pins 1-2 Enabled PCI-E slots.
  • Page 69 Chapter 5: Advanced Motherboard Setup ME Recovery Set Jumper JPME1 to select ME Firm- ware Recovery mode, which will limit ME Recovery Jumper Settings system resource for essential function Jumper Setting Defi nition use only without putting restrictions on Pins 1-2 Normal (Default) power use.

  • Page 70: 5-10 Onboard Indicators

    UPER ERVER 1018D-73MTF User's Manual 5-10 Onboard Indicators LAN1/LAN2 LEDs LAN LED Connection Speed Indication The Ethernet ports (located beside the LED State Defi nition VGA port) have two LEDs. On each Giga- No connection or 10 Mb/s bit LAN port, the yellow LED indicates...

  • Page 71: 5-11 Sas/Sata Ports

    Chapter 5: Advanced Motherboard Setup Power Status LED (LE6) Power Status LED Color Defi nition A Power Status LED is located at LE6 on Green System Power On (Power Normal) the motherboard. When the LED indica- Yel- Standby Power Active tor turns to color red, power supply has a (System Off) problem.

  • Page 72: 5-12 Installing Software

    UPER ERVER 1018D-73MTF User's Manual 5-12 Installing Software The Supermicro ftp site contains drivers and utilities for your system at ftp://ftp. supermicro.com. Some of these must be installed, such as the chipset driver. After accessing the ftp site, go into the CDR_Images directory and locate the ISO fi...

  • Page 73: Superdoctor Iii

    Chapter 5: Advanced Motherboard Setup SuperDoctor III The SuperDoctor® III program is a web-based management tool that supports remote management capability. It includes Remote and Local Management tools. The local management is called SD III Client. The SuperDoctor III program allows you to monitor the environment and operations of your system.

  • Page 74: 5-13 Onboard Battery

    UPER ERVER 1018D-73MTF User's Manual Figure 5-8. SuperDoctor III Interface Display Screen (Remote Control) Note: The SuperDoctor III program and User’s Manual can be downloaded from the Supermicro web site at http://www.supermicro.com/products/accessories/soft- ware/SuperDoctorIII.cfm. For Linux, we recommend that you use the SuperDoctor II application instead.

  • Page 75: Chapter 6 Advanced Chassis Setup

    Chapter 6: Advanced Chassis Setup Chapter 6 Advanced Chassis Setup This chapter covers the steps required to install components and perform main- tenance on the SC113MTQ-330CB chassis. For component installation, follow the steps in the order given to eliminate the most common problems encountered. If some steps are unnecessary, skip ahead to the next step.

  • Page 76: Control Panel

    UPER ERVER 1018D-73MTF User's Manual Figure 6-1. Chassis: Front and Rear Views Control Panel SATA Drive Bays (8) Power Supply Dedicated IPMI LAN Port VGA Port PCI Slot COM Port USB Ports LAN Ports Control Panel The control panel (located on the front of the chassis) must be connected to the JF1 connector on the motherboard to provide you with system status indications.

  • Page 77: System Fan Failure

    Chapter 6: Advanced Chassis Setup Adding a System Fan 1. Turn off the power to the system and unplug the power cord. 2. Remove the chassis cover then remove the dummy fan from the fan tray. 3. Place the new fan into the vacant space in the housing while making sure the arrows on the top of the fan (indicating air direction) point in the same direc- tion as the arrows on the other fans.

  • Page 78: Drive Bay Installation/Removal

    Proceed to the "DVD-ROM Drive Installation" section later in this chapter for instructions. Note: Only a "slim" DVD-ROM drive will fi t into the 1018D-73MTF. Hard Drive Installation The hard drives are mounted in drive carriers to simplify their installation and removal from the chassis.
  • Page 79 Chapter 6: Advanced Chassis Setup 2. Align the drive in the carrier so that the screw holes of both line up. Note that there are holes in the carrier marked “SATA” to aid in correct installation. 3. Secure the drive to the carrier with four screws as illustrated below. 4.

  • Page 80: Dvd Drive Installation

    UPER ERVER 1018D-73MTF User's Manual Figure 6-4. Removing a Hard Drive DVD Drive Installation The SC113MTQ chassis may have a DVD-ROM installed (optional). Installing or Replacing a DVD-ROM Drive (Figure 6-5) 1. Power down the system and if necessary, remove the server from the rack and the front bezel from the chassis.
  • Page 81 Chapter 6: Advanced Chassis Setup Figure 6-5. Installing a DVD-ROM Drive...

  • Page 82: Power Supply

    UPER ERVER 1018D-73MTF User's Manual Power Supply The SuperServer 1018D-73MTF has a single 330 watt power supply, which is auto- switching capable. This enables it to automatically sense and operate with a 100V to 240V input voltage. Power Supply Failure If the power supply unit fails, the system will shut down and you will need to replace the unit.
  • Page 83 Chapter 6: Advanced Chassis Setup Figure 6-6. Removing/Replacing the Power Supply...
  • Page 84 UPER ERVER 1018D-73MTF User's Manual Notes 6-10...

  • Page 85: Chapter 7 Bios

    Chapter 7: BIOS Chapter 7 BIOS Introduction This chapter describes the AMI BIOS Setup Utility for the X10SL7-F. The ROM BIOS is stored in a Flash EEPROM and can be easily updated. This chapter describes the basic navigation of the AMI BIOS Setup Utility setup screens. Note: For AMI BIOS Recovery, please refer to the UEFI BIOS Recovery Instructions in Appendix C.

  • Page 86: How To Start The Setup Utility

    UPER ERVER 1018D-73MTF User's Manual How to Start the Setup Utility Normally, the only visible Power-On Self-Test (POST) routine is the memory test. As the memory is being tested, press the <Delete> key to enter the main menu of the AMI BIOS Setup Utility. From the main menu, you can access the other setup screens.
  • Page 87 Chapter 7: BIOS The following Main menu items will display: System Time/System Date Use this option to change the system date and time. Highlight System Date or System Time using the arrow keys. Enter new values through the keyboard. Press the <Tab>...

  • Page 88: Advanced Setup Confi Gurations

    UPER ERVER 1018D-73MTF User's Manual Advanced Setup Confi gurations Use the arrow keys to select Boot Setup and press <Enter> to access the submenu items: Warning: Take Caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency, or an incorrect DRAM timing setting may make the system unstable.
  • Page 89 Chapter 7: BIOS Wait For 'F1' If Error This feature forces the system to wait until the 'F1' key is pressed if an error oc- curs. The options are Disabled and Enabled. Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this item is set to Enabled, the ROM BIOS of the host adaptors will "capture"...
  • Page 90 UPER ERVER 1018D-73MTF User's Manual  CPU Confi guration The following CPU information will be displayed: • Type of CPU • CPU Signature • Microcode Patch • Max (Maximum) CPU Speed • Min (Minimum) CPU Speed • CPU Speed •...
  • Page 91 Chapter 7: BIOS Hyper-threading Select Enabled to support Intel Hyper-threading Technology to enhance CPU per- formance. The options are Enabled and Disabled. Active Processor Cores This feature determines how many CPU cores will be activated for each CPU. When all is selected, all cores in the CPU will be activated. (Please refer to Intel's web site for more information.) The options are All, 1, 2, and 3.
  • Page 92 UPER ERVER 1018D-73MTF User's Manual CPU AES Select Enable to enable Intel CPU Advanced Encryption Standard (AES) Instruc- tions for CPU to enhance data integrity. The options are Enabled and Disabled. EIST EIST (Enhanced Intel SpeedStep Technology) allows the system to automatically adjust processor voltage and core frequency in an effort to reduce power consump- tion and heat dissipation.
  • Page 93 Chapter 7: BIOS 1-Core Ratio Limit (Available when "Turbo Mode" is set to Enabled) This increases (multiplies) 1 clock speed in the CPU core in relation to the bus speed when one CPU core is active. Press "+" or "-" on your keyboard to change the value.
  • Page 94 UPER ERVER 1018D-73MTF User's Manual CPU C3 Report (Available when "CPU C-States" is set to Enabled) Select Enabled to allow the BIOS to report the CPU C3 State (ACPI C2) to the operating system. During the CPU C3 State, the CPU clock generator is turned off.
  • Page 95 Chapter 7: BIOS Package C-State limit Select Auto for the AMI BIOS to automatically set the limit on the C-State package register. The options are C0/C1, C2, C3, C6, C7 and Auto.  Chipset Confi guration Warning! Setting the wrong values in the following sections may cause the system to malfunction.
  • Page 96 UPER ERVER 1018D-73MTF User's Manual Primary PCIE (PCI-Express Device) This feature allows the user to specify which graphics card to be used as the primary graphics card. The options are PCIE1, PCIE2, PCIE3, PCIE4, PCIE5 , PCIE6, PCIE7 and Auto.
  • Page 97 Chapter 7: BIOS  Memory Confi guration This item displays the information on the memory modules installed on the motherboard. • Memory RC Version • Memory Frequency • Total Memory • Memory Voltage • DIMMA1 • DIMMA2 • DIMMB1 • DIMMB2 •...
  • Page 98 UPER ERVER 1018D-73MTF User's Manual Memory Scrambler This feature enables or disables memory scrambler support for memory error correction. The settings are Enabled and Disabled.  PCH-IO Confi guration This item displays the information for PCH-IO Chip. • Intel PCH Rev ID •...
  • Page 99 Chapter 7: BIOS EHCI Hand-Off This item is for Operating Systems that do not support Enhanced Host Controller Interface (EHCI) hand-off. When this item is enabled, EHCI ownership change will be claimed by the EHCI driver. The settings are Enabled and Disabled. XHCI Mode This feature handles the operation mode for the XHCI (Extensible Host Control- ler Interface) controller.
  • Page 100 UPER ERVER 1018D-73MTF User's Manual Port 0 ~ Port 1 SATA Device Type This feature confi gures the selected SATA port to support either a solid state drive or hard disk drive. The options are Hard Disk Drive and Solid Sate Drive.
  • Page 101 Chapter 7: BIOS  PCIe/PCI/PnP Confi guration This feature allows the user to set the PCI/PnP confi gurations for the following items: Above 4G Decoding Select Enabled for 64-bit devices to be decoded above the 4GB address space If 64bit PCI decoding is supported by the system. The options are Disabled and Enabled.

  • Page 102: Acpi Settings

    UPER ERVER 1018D-73MTF User's Manual Onboard LAN1/LAN2 Option ROM Select iSCSI to use the iSCSI Option ROM to boot the computer using an iSCSI device installed in a LAN port specifi ed. Select PXE (Preboot Execution Environ- ment) to boot the computer using a PXE device installed in a LAN port specifi ed.
  • Page 103 Chapter 7: BIOS  Intel Server Platform Services Confi guration The following status information for this motherboard are displayed: • ME (Management Engine) BIOS Interface Version • SPS Version • ME FW (Firmware) Status Value • ME FW State • ME FW Operation State •...
  • Page 104 UPER ERVER 1018D-73MTF User's Manual Pending Operation Use this item to schedule a TPM-related operation to be performed by a security device for TPM support. The options are None, Enable Take Ownership, Disable Take Ownership, and TPM Clear. Note: The computer will reboot to carry out a pending TPM operation and change TPM state for a TPM device.

  • Page 105: Serial Port Console Redirection

    Chapter 7: BIOS  Serial Port Console Redirection COM1/COM2 Use this feature to enable console redirection for COM1 and COM2 ports. The op- tions are Enabled and Disabled. The default setting is Disabled. Console Redirection Settings This feature allows the user to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user.
  • Page 106 UPER ERVER 1018D-73MTF User's Manual Flow Control This feature allows the user to set the fl ow control for Console Redirection to prevent data loss caused by buffer overfl ow. Send a "Stop" signal to stop send- ing data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty.
  • Page 107 Chapter 7: BIOS  Console Redirection Settings (for EMS) This feature allows the user to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user. Out-of-Band Management Port The feature selects a serial port used by the Microsoft Windows Emergency Management Services (EMS) to communicate with a remote server.
  • Page 108 UPER ERVER 1018D-73MTF User's Manual  H/W (Hardware) Monitor PC Health Status Fan Speed Control Mode This feature allows the user to decide how the system controls the speeds of the onboard fans. The CPU temperature and the fan speed are correlative. When the CPU on-die temperature increases, the fan speed will also increase for effective system cooling.

  • Page 109: Event Logs

    Chapter 7: BIOS Event Logs  Change SMBIOS Event Log Settings Enabling/Disabling Options SMBIOS Event Log Change this item to enable or disable all features of the SMBIOS Event Logging during system boot. The options are Enabled and Disabled. Erasing Settings Erase Event Log If No is selected, data stored in the event log will not be erased.

  • Page 110: View Smbios Event Log

    UPER ERVER 1018D-73MTF User's Manual MECI The Multiple Event Count Increment (MECI) counter counts the number of oc- curences a duplicate event must happen before the MECI counter is incremented. This is a numeric value. The default value is 1.

  • Page 111: Ipmi

    Chapter 7: BIOS IPMI The following IPMI information will be displayed: • IPMI Firmware Revision • IPMI Status  System Event Log This feature is used to change the System Event Log (SEL) confi guration. SEL Components - Change this item to enable or disable all features of System Event Logging.
  • Page 112 UPER ERVER 1018D-73MTF User's Manual  BMC Network Confi guration LAN Channel 1: This feature allows the user to confi gure the settings for LAN1 Port. Update IPMI LAN Confi guration This feature allows the BIOS to implement any IP/MAC address changes at the next system boot.

  • Page 113: Boot Settings

    Chapter 7: BIOS Boot Settings Use this feature to confi gure Boot Settings: Set Boot Priority This option prioritizes the order of bootable devices that the system to boot from. Press [ENTER] on each entry from top to bottom to select devices. •...
  • Page 114 UPER ERVER 1018D-73MTF User's Manual  Delete Boot Option Use this feature to remove a pre-defi ned boot device from which the system will boot during startup. The settings are [any pre-defi ned boot device]  Delete Driver Option This feature allows the user to delete a previously defi ned boot device from which the systems boots during startup.

  • Page 115: Security Settings

    Chapter 7: BIOS Security Settings This menu allows the user to confi gure the following security settings for the system. • If the Administrator password is defi ned ONLY - this controls access to the BIOS setup ONLY. • If the User's password is defi ned ONLY - this password will need to be entered upon each system boot, and will also have Administrator rights in the setup.

  • Page 116: Save & Exit

    UPER ERVER 1018D-73MTF User's Manual Save & Exit Select the Exit tab from the BIOS Setup Utility screen to enter the Exit BIOS Setup screen. Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system confi...
  • Page 117 Chapter 7: BIOS Restore Optimized Defaults To set this feature, select Restore Defaults from the Exit menu and press <Enter>. These are factory settings designed for maximum system stability, but not for maximum performance. Save As User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <En- ter>.
  • Page 118 UPER ERVER 1018D-73MTF User's Manual Notes 7-34...

  • Page 119: Appendix A Post Error Beep Codes

    Appendix A: POST Error Beep Codes Appendix A POST Error Beep Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue with bootup.
  • Page 120 UPER ERVER 1018D-73MTF User's Manual Notes...

  • Page 121: Appendix B System Specifi Cations

    Appendix B: System Specifi cations Appendix B System Specifi cations Processors ® ® Single Intel Xeon E3-1200 v3 or a 4th Generation Core i3/ i5/ i7 processor in an LGA1150 socket Note: Please refer to our web site for a complete listing of supported processors. Chipset Intel C222 BIOS...
  • Page 122 UPER ERVER 1018D-73MTF User's Manual Chassis SC113MTQ Form Factor: 1U rackmount Dimensions: (WxHxD) 17.2 x 1.7 x 19.85 in. (437 x 43 x 504 mm) Weight Gross Weight: 30 lbs. (13.6 kg.) System Cooling Four 4-cm counter-rotating PWM fans System Input Requirements AC Input Voltage: 100-240V AC auto-range Rated Input Current: 6.3A (115V) to 3.24A (230V)
  • Page 123 Appendix B: System Specifi cations This Perchlorate warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only to products containing CR (Manganese Dioxide) Lithium coin cells.
  • Page 124 UPER ERVER 1018D-73MTF User's Manual Notes...

Table of Contents
