Sensorsoft ST6105J User Manual page 14

9 pin Serial Port to Sensorsoft Device
9 pin Port
3
TX
2
RX
4
DTR
7
RTS
5
SIGNAL GND
P/N C2000 is for use with PC's and most other devices which have a 9 position serial
port. F indicates female/socket type connector.
DTE Serial Port to Sensorsoft Device
DTE Port
2
TX
3
RX
20
DTR
4
RTS
7
SIGNAL GND
P/N C2002 is for use with Sun SPARCstation or SPARCserver serial ports A or B. The
DTE end of this cable uses a DB-25M connector. P/N C2001 is for use with PC's which
have a DB-25 connector. The DTE end of this cable uses a DB-25F connector. M
indicates male/pin type connector. F indicates female/socket type connector.
Cable P/N C2000
DB-9F to RJ45 modular plug
white-green
white-orange
white-brown
blue
green
Cable P/N C2001 and C2002
DB-25 to RJ45 modular plug
white-green
white-orange
white-brown
blue
green
Sensorsoft Thermometer User Manual
Sensorsoft Device
RX
TX
POWER +V
POWER +V
GND
Sensorsoft Device
RX
TX
POWER +V
POWER +V
GND
1
3
7
4
2
1
3
7
4
2
