Teton Grill 720-0539 Use And Care Manual

Stainless steel gas grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Stainless Steel Gas Grill
USE AND CARE GUIDE
MODEL NO.: 720-0539
Consumer: Retain this manual for future reference.
Installer: Leave this manuals with consumer
PLEASE CONTACT 1-800-913-8999 FOR ASSISTANCE
ABOUT ASSEMBLY OR GRILL OPERATION
DO NOT RETURN TO THE PLACE OF PURCHASE
FOR OUTDOOR USE ONLY
400
500
600
300
700
800
200
100
D24Y07P_1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 720-0539 and is the answer not in the manual?

Questions and answers

Related Manuals for Teton Grill 720-0539

Summary of Contents for Teton Grill 720-0539

  • Page 1 FOR OUTDOOR USE ONLY Stainless Steel Gas Grill USE AND CARE GUIDE MODEL NO.: 720-0539 Consumer: Retain this manual for future reference. Installer: Leave this manuals with consumer D24Y07P_1 PLEASE CONTACT 1-800-913-8999 FOR ASSISTANCE ABOUT ASSEMBLY OR GRILL OPERATION DO NOT RETURN TO THE PLACE OF PURCHASE...

  • Page 2: Table Of Contents

    Section One TABLE OF CONTENTS SECTION FOUR SECTION ONE Table of Contents & Importance………………2 Grill lighting instruction…………………17-20 Precautions……………………………………3-6 Lighting Illustration………………………….21 Care and Maintenance…………………22-23 SECTION TWO Trouble Shooting………………………..24-25 Side burner control panel & Exploded View……………………………...26 Side shelf assembly………………....7 Parts list…………………………………27-28 Side shelf wooden mount panel assembly…..8 Left side shelf push bar &...

  • Page 3: Precautions

    PRECAUTIONS WARNING CAUTION: Beware of Flashback Do not try lighting this appliance without reading the “LIGHTING INSTRUCTIONS” section of this manual. CAUTION: Spiders and small insects occasionally spin webs or make nests in the grill burner tubes during transit and warehousing. These webs can lead TESTED IN ACCORDANCE WITH ANSI to gas flow obstruction, which could result in a fire in Z21..58 CSA 1.6-2007 STANDARD FOR...
  • Page 4 Section One PRECAUTION LP-Gas Supply System PROPER PLACEMENT AND CLEARANCE OF GRILL A 20lbs tank of approximately 1/4 inches in diameter by 18-1/4 •Never use your gas grill in a garage, porch, shed, inches high is the maximum size LP gas tank to use. breezeway or any other enclosed area.
  • Page 5 PRECAUTIONS SAFETY PRACTICES TO AVOID PERSONAL WARNING INJURY Your grill will get very hot. Never lean over the cooking area while using your grill. Do not touch When properly cared for, your grill will provide cooking surfaces, grill housing, lid or any other safe, reliable service for many years.

  • Page 6: Precautions

    PRECAUTIONS Do not heat unopened food containers. A build-up Do not use the grill to cook excessively fatty meats of pressure may cause the containers to burst. or other products which promote flare – ups. Use a covered hand when opening the grill lid. Do not operate the grill under unprotected combustible constructions.

  • Page 7: Section Two

    Section Two SIDE BURNER CONTROL PANEL ASSEMBLY Loosen 3pcs ¼’’ x 12 screws and washers from side burner control panel , then attach side burner to control panel and tighten these screws as in the figure shown below. SIDE SHELF ASSEMBLY The screws used to attach the side shelf are already screwed into the left side shelf, cart-legs and side burner (see the figure below).

  • Page 8: Side Shelf Wooden Mount Panel Assembly

    SIDE SHELF WOODEN MOUNT PANEL ASSEMBLY First remove 8pcs flat head screws from hinge, then use them to attach side shelf hinge to side shelf. (No washers included). 400 500 Left side shelf control panel assembly: 1.Use two fingers to press the hinge which is under the wooden control panel (see below pix 1). 2.

  • Page 9: Side Burner Assembly

    LEFT PUSH BAR ASSEMBLY Required tools: Philips Screwdriver (not included) 1. Remove 2pcs push bar bracket and ensure 2pcs ¼’’x12 screws have been released from left side cart- legs. 2. Align the holes in the side shelf push bar with the holes in the shelf. 3.

  • Page 10: Rear Burner Igniter Wire Assembly

    2. Connect ignite wire with side valve. 400 500 REAR BURNER IGNITER WIRE ASSEMBLY Connect the rear burner igniter wire into the electric igniter.

  • Page 11: Side Burner Lid Bracket Assembly

    SIDE BURNER LID BRACKET ASSEMBLY First remove the screws from side burner lid. Then attach side burner bracket with side burner frame as shown below from top to bottom with three washers and screws.

  • Page 12: Battery Assembly

    BATTERY ASSEMBLY In order to install the battery, remove the ignition button housing. Please keep the positive pole of the battery facing toward you. Insert the battery into the housing. Replace the ignition button housing after battery is installed. 400 500 ROTISSERIE KIT ASSEMBLY Screw the rotisserie motor mount on the left side shelf first, put the rotisserie motor on the mount as shown in the figure below.

  • Page 13: Propane Tank Assembly

    PROPANE TANK ASSEMBLY Attach regulator to the propane tank by turning the regulator handle clockwise (FIGURE A). Turn off LP supply at cylinder when appliance is not in use. (FIGURE A) Put the gas tank into bottom panel. Then tighten up the gas tank retention kit for fixing the gas tank as shown in below.

  • Page 14: Section Three

    Section Three GAS HOOK UP NEVER CONNECT AN UNREGULATED QCC1 in the standard for compressed gas GAS SUPPLY LINE TO THE APPLIANCE. cylinder valve outlet and inlet connection USE THE REGULATOR/HOSE ANSI/CGA-V-1. ASSEMBLY SUPPLIED. Manifold pressure: 10”(25.4cm) water This is a liquid propane configured grill. column (W.C.).

  • Page 15: Gas Hook

    GAS HOOK-UP 5. When connecting regulator assembly to To disconnect L.P. gas cylinder: the valve, hand tighten the quick 1. Turn the burner valves off. coupling nut clockwise to a complete stop. Do not use a wrench to tighten. 2. Turn the tank valve off fully (turn Use of a wrench may damage the quick clockwise to stop).

  • Page 16: Leak Testing

    LEAK TESTING GENERAL Only those parts recommended by the manufacturer should be used on the grill. Although all gas connections on the grill are leak tested at the factory prior to shipment, a Substitution will void the warranty. Do not use complete gas tightness check must be the grill until all connections have been performed at the installation site due to...

  • Page 17: Operating Instructions

    Section Four OPERATING INSTRUCTIONS CAUTION: PLEASE TAKE OFF THE WARMING RACK WHEN USING THE ROTIS BURNER. THE HIGH HEAT COMING FROM THE ROTIS BURNER MAY CAUSE THE WARMING RACK TO BEND. GRILL LIGHTING INSTRUCTIONS Never substitute regulators and hose assembly for those supplied with the grill. WARNING: IMPORTANT! If a replacement is necessary, contact the BEFORE LIGHTING…...
  • Page 18 GRILL LIGHTING INSTRUCTIONS If you’ve just attempted to light the burner with the TO LIGHT THE GRILL BURNER: igniter, allow 5 minutes for any accumulated gas to Make sure all knobs are “OFF” then turn on the gas dissipate. Keep your face and hands as far away supply from the LP tank.
  • Page 19 TO MATCH LIGHT THE GRILL 1. If the burner will not light after several attempts then the burner can be match lit. 2. If you’ve just attempted to light the burner with the igniter, allow 5 minutes for any accumulated gas to dissipate.

  • Page 20: Grill Lighting Instruction

    GRILL LIGHTING INSTRUCTIONS flame is noisy and tends to lift away from FLAME CHARACTERISTICS the burner, it indicates too much air. Check for proper burner flame characteristics. Burner flames should be blue and stable Each burner is adjusted prior to with no yellow tips, excessive noise, or shipment;...

  • Page 21: Lighting Illustration

    LIGHTING ILLUSTRATIONS Main & side burner lighting illustration Make sure the lid is open. 2. Push and turn one of Main or Side Burner knob slowly to IGNITE/HI position. You may try 3 or 4 times to light the burner. After the burner is lit, adjust the knob as desired Rear burner lighting illustration 1.

  • Page 22: Care And Maintenance

    Section Five CARE AND MAINTENANCE STAINLESS STEEL MAIN GRILL BURNER CLEANING The grill is made from non-rusting and Ensure the gas supply is off and the knobs non-magnetic stainless steel. There are are in the “OFF” position. Make sure the grill many different stainless steel cleaners is cool.

  • Page 23: Care And Maintenance

    CARE AND MAINTENANCE HOW TO REPLACE MAIN BURNER STAINLESS STEEL : Step 1. Place the burner onto the orifice. There are many different stainless steel cleaners available. Always use the mildest cleaning procedure first, scrubbing in the direction of the grain. Do not use steel wool as it will scratch the surface.

  • Page 24: Trouble Shooting

    TROUBLE SHOOTING SPIDER AND INSECT WARNING!!! WHEN TO LOOK FOR SPIDERS Spiders and small insects occasionally You should inspect the burners at least spin webs or make nests in the grill burner once a year or immediately after any of the tubes during transit and warehousing.

  • Page 25: Trouble Shooting

    TROUBLE SHOOTING CHECK LIST WHAT TO DO PROBLEMS Check to see if LP tank is empty. Grill won’t light when the control knob is rotated. Clean wire(s) and /or electrode by rubbing with alcohol and clean swab. Wipe with dry cloth. Make sure the wire is connected to electrode assembly.

  • Page 26: Exploded View

    720-0539 EXPLODED VIEW 400 500...

  • Page 27: Parts List

    PARTS LIST DESCRIPTION REF# DESCRIPTION Warming Rack Left side panel cart leg , Rear Cooking Grid With Hole Left side panel cart leg, Front Flame Tamer Right side panel cart leg , Rear Main Burner Right side panel cart leg , Front Greasy tray Cart –Caster Insert Grease slide panel, bottom...

  • Page 28: Parts List

    PARTS LIST REF# DESCRIPTION REF# DESCRIPTION Side burner fix bracket Rotisserie gas valve Side burner bracket Main gas valve Side burner pipe Front baffle Side burner bowl assembly Main burner bowl assembly Side burner ring Regulator, LP Side burner ignite wire Spit rod Side burner cooking grid Counter-balance...

  • Page 29: Section Five

    Section Five ORDERING PARTS REPLACEMENT IMPORTANT HOW TO ORDER PARTS Use only factory authorized parts. The use of any part that is not factory authorized can be dangerous. To make sure you obtain the correct replacement This will also void your warranty. part(s) for your gas grill, please refer to the parts list on the previous 2 pages.

  • Page 30: Grill Cooking Charts

    GRILL COOKING CHART WEIGHT OR FLAME APPROXIMATE FOOD THICKNESS SIZE TIME SPECIAL INSTRUCTIONS AND TIPS Vegetables Slice. Dot with butter or margarine Wrap in heavy-duty foil. Grill,turning occasionally. Fresh Beets Carrots Grill,turning once.Brush Medium 12 to 20 minutes Occasionally With melted butter or margarine Turnips Onion 1/2 inch slices...
  • Page 31 GRILL COOKING CHART WEIGHT OR APPROXIMATE SPECIAL INSTRUCTIONS FOOD THICKNESS FLAME SIZE TIME AND TIPS Rare 1 inch High 8 to 14 minutes 1-1/2 inch High 11 to 18 minutes Remove excess fat from edge. Slash Medium 1 inch Medium to 12 to 22 minutes remaining fat at 2-inch intervals.

  • Page 32: Grill Cooking Charts

    GRILL COOKING CHART APPROXIM WEIGHT OR SPECIAL INSTRUCTIONS AND FLAME SIZE FOOD THICKNESS TIME TIPS FISH AND SEAFOOD Grill,turning once. Brush Steaks 3/4 to 1 inch Medium to high 8 to 15 with melted butter, margarine minutes or oil. Halibut High To keep moist.

  • Page 33: Grill Recipe Suggestion

    GRILL RECIPE SUGGESTIONS BBQ SALMON TANGY SEAFOOD KABOBS Peel and grate onion into a mixing bowl, add the rest of the 1 lb. Large shrimp, shelled & 2 large salmon steaks devined ingredients except the pork 2 tbs. Oil chops. Mix well. Pour over chops ¾...
  • Page 34 GRILL RECIPE SUGGESTIONS Preheat grill. Combine cheese, Pound flank steak to ¼ inch In a blender, process 1/3 c. water, condensed soup, milk, BBQ thickness or flatten chicken onion, soy sauce, 2 tsp. oil and sauce, oregano, salt and pepper breasts.
  • Page 35 GRILL RECIPE SUGGESTIONS TURKEY CHICKEN TANDOORI STYLE Marinade ribs for 3 hours. Use 12 lb. turkey marinade for basting by adding 8 large chicken thighs or Beer basting sauce: drumsticks beer to it. Prong meat hook down 1 can beer the length of spit and tighten.

  • Page 36: Limited Warranty

    Product repair as provided under this warranty is your exclusive remedy. Nexgrill Industries or Teton Grill shall not be liable for any incidental or consequential damages for breach of any express or implied warranty on its products, except to the extent prohibited by applicable law, any implied warranty or merchantability or fitness for a particular purpose on this product to the duration of the above warranty.
