- Page 1 JC-201ASU/401ASU 2/4 Port USB 2.0 AUTO SWITCH Share a USB 2.0 Device with up to Two or Four Computers USER MANUAL...
-
Page 2: Table Of Contents
ABLE OF CONTENTS INTRODUCTION............. 1 PRODUCT FEATURES........1 SPECIFICATIONS........... 2 PACKAGE CONTENTS........2 EQUIPMENT............. 3 OPERATING SYSTEMS........3 DISPLAY DIAGRAMS........4 SOFTWARE INSTALLATION.......6 HARDWARE INSTALLATION......... 7 OPERATION............. 8 MANUAL SWITCHING........... 9 AUTO SWITCH SETTING........ 9 AUTOMATIC PRINT SHARING......10 TROUBLESHOOTING........... 11... -
Page 3: Introduction
JC-201ASU/401ASU Introduction Thank you for purchasing JustCom's two / four port (JC- 201ASU/401ASU) USB 2.0 Auto Switch. Incorporating fast USB 2.0 technology (up to 480 Mbps), the Auto Switch allows up to four computers (PCs & Macs) direct access to a single USB (1.1/2.0) compliant device - such as a scanner, printer,... -
Page 4: Specifications
JC-201ASU/401ASU Supports idle Time-out switching & Automatic printer sharing Supports Windows 98, SE, ME, 2000, XP, and Mac OS Light-Emitting Diode (LEDs) for status monitoring Non-powered Comes with JustCom's 3 year warranty Specifications Package Contents... -
Page 5: Equipment
JC-201ASU/401ASU Equipment Cables To connect to the Auto Switch, each computer requires a USB device cable (A to B).The following Hi-Speed USB Device Cables are recommended for use with JustCom's (JC-201ASU/401ASU) Auto Switch. * JustCom Hi-Speed USB (2.0) device cable (6') -
Page 6: Display Diagrams
JC-201ASU/401ASU Display Diagrams 1. LED Display LED Display 2. USB Device Port USB Device Port... - Page 7 JC-201ASU/401ASU Display Diagrams 3. Computer Ports Computer Ports 4. Manual Port Selector Manual Port Selector...
-
Page 8: Software Installation
JC-201ASU/401ASU Software Installation Before you begin, make sure that : 1. The Auto Switch is not connected to your computers 2. The Auto Switch and your peripheral USB devices are supported by your operating system. Software Installation for Windows Users To install the software 1. -
Page 9: Hardware Installation
JC-201ASU/401ASU Hardware Installation Connecting the Auto Switch 1.Connect the A-type connector cable of your USB device to the A-type USB port on the Auto Switch. 2.Install the drivers for your USB (1.1/2.0) device. Refer to the device's user manual for additional information on installing the driver. -
Page 10: Operation
JC-201ASU/401ASU Operation - Software Switching for Windows Users JustCom's Auto Switch provides Windows users with AOD (Access-On- Demand) switching software. All computers stay connected with instant access to your USB device at the click of a mouse. AOD Legend Green -the USB device is free for use (Ready status) -
Page 11: Manual Switching
3.You are now able to use the connected USB device from your computer. Auto Switch Settings: Users of JustCom's Auto Switch are able to customize settings. Auto Switch Settings Users of JustCom's Auto Switch are able to customize settings for the following : 1. Idle Time-Out switching 2. Automatic Print Sharing... -
Page 12: Automatic Print Sharing
JC-201ASU/401ASU To setup, do the following : 1.Right click your taskbar's USB Share icon and select "Settings" 2.Enter a time out value in seconds 3.Click "OK" to exit Automatic Print Sharing To assign a printer : 1.Right click your taskbar's USB icon and select "Settings"... -
Page 13: Troubleshooting
JC-201ASU/401ASU Troubleshooting The Auto Switch does not detect my computer 1.Check that the USB cable between the Auto Switch and the computer is properly connected. 2.Make sure the connected device is not further than 15 feet away. 3.Check that the USB cable between the Auto Switch and the computer is no longer than 15 feet. -
Page 14: Fcc Certifications
JC-201ASU/401ASU FCC Certifications This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This... - Page 15 JC-201ASU/401ASU This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions : (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
-
Page 16: Limited Warranty
JC-201ASU/401ASU Limited Warranty JUSTCOM offers limited warranty for its product only to the person or entity who originally purchased the product from JUSTCOM or its authorized reseller or distributor Limited Hardware Warranty: JUSTCOM warrants that the hardware portion of the JUSTCOM... - Page 17 Hardware will be refunded by JUSTCOM upon return to JUSTCOM of the defective Hardware. All Hardware (or part thereof) that is replaced by JUSTCOM, or for which the purchase price is refunded, shall become the property of JUSTCOM upon replacement or refund.
-
Page 18: Governing Law
JC-201ASU/401ASU Governing Law This Limited Warranty shall be governed by the United States. Some states do not allow exclusion or limitation of incidental or consequential damages, or limitations on how long an implied warranty lasts, so the foregoing limitation and exclusion may not apply. This limited warranty provides specific legal rights and the product owner may also have other rights which vary from state to state. - Page 19 3. What network protocol(s) does your organization use ? XNS/IPX TCP/IP DECnet Others___________________________________________________ 4. What network operating system(s) does your organization use ? Justcom LANsmart Novell NetWare NetWare Lite SCO Unix/Xenix PC NFS 3Com 3+Open Banyan Vines DECnet Pathwork Windows NT Windows NTAS Windows '95 Oothers______________________________________________________________________ 5.
