- Page 1 ® 19-Module Power Chassis User Manual 140 Technology Drive, #500, Irvine, CA 92618 Phone: (949) 250-6510; Fax: (949) 250-6514...
- Page 2 Warning The operating description in this Instruction Manual is for use by qualified personnel only. To avoid electrical shock, do not perform any servicing of this unit other than that contained in the operating instructions, unless you are qualified and certified to do so by Omnitron Systems Technol- ogy, Inc.
-
Page 3: General Description
19-Module Power Chassis User Manual 1. 0 GENERAL DESCRIPTION iConverter 2U (3.5 inch) 19-Module Power Chassis is powered by up to three (3) hot-swappable and redundant universal iConverter AC or DC power supplies and can accommodate up to nineteen media converters. -
Page 4: Application Example
Fig. 2 19-Module Backplane Architecture Fig. 2 depicts the chassis’ backplane architecture including the A and B Links. The A Links connect between odd numbered slots on the left to even numbered slots on the right (i.e. 1-2, 3-4, 5-6, 7-8, 9-10, 11-12, 13-14, 15-16, 17-18). -
Page 5: Site Preparation And Installation
This configuration provides the network administrator with the ability to provide multi-customer service using a single chassis which is securely managed. UNPACKING, VISUAL INSPECTION AND INVENTORY Review the contents. The following items should be included: iConverter 19-Module Power Chassis † 2 Rack mounting “L” brackets and 12 screws †... - Page 6 Attach the AC power cords (provided for each Power Supply) to the back of each Power Supply and plug into the AC outlets. † iConverter The fans should immediately begin to run and any installed modules will illuminate the power LED.
- Page 7 † the length required. Strip approximately 3/8 of an inch of insulation from the power cable wires. † iConverter Connect the power cables to the Chassis by fastening the stripped ends to the DC power connector. † WARNING: Note the wire colors used in making the positive, negative and ground connections. Use the same color assignment for the connection at the circuit breaker.
-
Page 8: Power Supply Replacement
Removal of power supplies or cards will result in access to hazardous electricity. Hot Removal of AC Power Supply iConverter Determine which power supply is faulty by observing the status LEDs on the NMM2 or viewing the status from the †... - Page 9 Locate the DC circuit breaker and make sure that the switch is in the OFF position. † iConverter Reconnect the DC power source to the power supply.
-
Page 10: Specifications
CUSTOMER SUPPORT INFORMATION If you encounter problems in installing this product, contact Omnitron Technical Support: Phone: (949) 250-6510 Fax: (949) 250-6514 Address: Omnitron Systems Technology, Inc. 140 Technology Drive, #500 Irvine, CA 92618, USA Email: support@omnitron-systems.com URL: http://www.omnitron-systems.com Form 040-08200-001I 7/11...
