Hot Attachment of Power Supplies:
1. Unpack the power supply carefully. Inspect for any damages. If any damage
is observed, do not use the power supply and call (949) 250-6510 to report
the damage immediately and request a replacement unit.
2. Attach the power supply to the chassis and reconnect the 48VDC power source
to the FlexPoint power supply.
3. Locate the 48VDC circuit breaker and switch the circuit breaker to the ON
position.
4. Turn the FlexPoint Chassis power supply ON.
5. Observe the LED in the front of the chassis indicating that the power has been
restored.
SPECIFICATIONS
Indicators:
Power ON:
LED (2), Yellow, power applied
Dimensions / Weight: W:19.0"xD:7.0"xH:3.5" / 9 lb.
Power:
48VDC / 3.0 Amps (for model 4386)
2ea. 48VDC / 3.0 Amps (for model 4385)
Environmental:
Temperature:
0 to 50 degrees C
Humidity:
5-95% (non-condensing)
TECHNICAL SUPPORT
If you encounter problems in installing this product, contact Omnitron Tech Support:
Phone:
(949) 250-6510
Fax:
(949) 250-6514
Address:
Omnitron Systems Technology, Inc.
140 Technology Drive, #500
Irvine, CA 92618, USA
E-mail:
support@omnitron-systems.com
URL:
http://www.omnitron-systems.com
Omnitron Systems Technology, Inc.
040-04385-001B 11/07
Omnitron Systems Technology, Inc.
TM
FlexPoint
Powered Chassis
48VDC Power-Redundant
14-Module Chassis
User's Manual
140 Technology Drive #500 Irvine, CA 92618
(949) 250-6510; Fax: (949) 250-6514
