Haier HDB24VA User Manual

Built-in dishwasher
Hide thumbs

Advertisement

Quick Links

Built-In Dishwasher
Lave-Vaisselle Encastrable
Lavaplatos Empotrable
User Manual
Model # HDB24EA, HDB24VA
Guide de l'Utilisateur
Modéle # HDB24EA, HDB24VA
Manual del Usuario
Para Modelo de # HDB24EA, HDB24VA
I
Quality
Innovation
(HDB24EA)
I
Style

Advertisement

loading

  Also See for Haier HDB24VA

  Related Manuals for Haier HDB24VA

  Summary of Contents for Haier HDB24VA

  • Page 1 Built-In Dishwasher Lave-Vaisselle Encastrable Lavaplatos Empotrable Quality (HDB24EA) User Manual Model # HDB24EA, HDB24VA Guide de l’Utilisateur Modéle # HDB24EA, HDB24VA Manual del Usuario Para Modelo de # HDB24EA, HDB24VA Innovation Style...
  • Page 2: Safety Instructions

    6. Replace immediately worn power cords, loose plugs/power outlets. 7. Unplug your appliance before cleaning or before making any repairs. 8. Do not open the dishwasher door immediately after completion of wash process or during the operation as hot air/steam may cause personal injury. Press the door latch, wait few seconds by allowing cold air to go in and then open the door.
  • Page 3: Save These Instructions

    Close supervision and observation needed when children are around the dishwasher. 25. Do not abuse, sit on or stand on the door or dish rack of the dishwasher. 26. Do not touch the heating element during or immediately after use, it may be very hot.
  • Page 4: Table Of Contents

    Dishwasher Safe or Hand Wash Care & Cleaning Of Your Dishwasher Troubleshooting Warranty Thank you for using our Haier product. This easy-to-use manual will guide you in getting the best use of your dishwasher. Remember to record the model and serial number.
  • Page 5: Knowing Your Dishwasher

    6. Model and serial number label 7. Detergent dispenser 8. Rinse aid dispenser 9. Vent 10. Upper Wash Sprayer (only in HDB24VA) 11. Spray tower 12. Lower spray arm 13. Overfill protection float 14. Heating element 15. 4 Adjustable leveling legs...
  • Page 6 English H D B 2 4 E A 1. Heat dry [on/off] 2. Door handle (Front view with door closed) H E A T E D D R Y O F F (HDB24EA) (HDB24EA) 3. Cycle selector knob 4. Air Vent...
  • Page 7 (Front view with door closed) (HDB24VA) 1. Hi-Temp Wash 2. Heated Dry 3. Hi-Temp Rinse (HDB24VA) 4. Door Handle 5. Cycle Selector Knob 6. Air Vent English...
  • Page 8: Using Your Dishwasher

    Selecting wash cycles • Select the appropriate cycle based on the load and soil level. For your convenience, the dishwasher has Prewash, Pots & Pans, Heavy Normal, and Rinse & Hold wash cycles that you can select from. Prewash •...
  • Page 9 Heated dry option • Activating this option will turn on the heating element to hasten the drying process. HDB24VA Heated Dry button: • Activating this will turn on the heating element to hasten the drying process. This needs to be “on” when using plate warmer feature.
  • Page 10 Pausing a wash cycle If you need to pause the dishwasher in the middle of the cycle to add or remove any items: 1. Open the door by squeezing the door latch slowly.
  • Page 11 Failure to do so may cause discoloration to plates, food containers and internal cabinet. • It is not necessary to rinse the dishes before loading the dishwasher. Food particals in the dishwasher will be disposed of by the built-in food disposal.
  • Page 12 • Do not load dishware or food containers that are made of wood or iron. These items are not considered dishwasher safe. • Place delicate items on the upper rack. • All dishware and glassware items should be securely in place when loading to avoid falling over or striking against each other.
  • Page 13 HDB24VA • This unit has a 3 level wash. The lower spray arm, the middle tower and the upper sprayer. • Three wash levels wash and clean both the upper and the lower wash loads from the top and bottom.
  • Page 14 Note: Use only "Automatic Dishwasher Detergent" for your dishwasher. Other types of detergents that are not for dishwasher use may cause over suds and foaming. Do not use detergents that are dried, caked or moist.
  • Page 15 Filling Dishwasher Detergent Use the recommended amount of detergent for your wash loads. Measure and pour the detergent into the large compartment for the main wash. The detergent for the pre-wash goes into the small compartment next to the main wash compartment.
  • Page 16 * Small amounts of water run through the pump to remove soil particles. • Shows what steps are there in each cycle. Cycle time includes dry time. Cycle time may be longer depending on the temperature of the water entering the dishwasher. Note: Cooler the water, longer the cycle time. •...
  • Page 17 Drying During the drying cycle you will see steam escaping through the vent located on the upper left side of the dishwasher door. This is normal as heat dries the wash load. CAUTION: The vapor is hot. DO NOT touch the vapor or the vent during the drying process.
  • Page 18: Dishwasher Safe Or Hand Wash

    English Dishwasher Safe or Hand Wash Material Dishwasher Safe type Aluminum Cast Iron Chinaware Copper Crystal Comments Some restrictions apply. Read manufacturer's washing instructions before loading. Not recommended - hand wash only, dry immediately after washing. Some restrictions apply. Read manufacturer's washing instructions before loading.
  • Page 19 Dishwasher Safe or Hand Wash Material Dishwasher Safe type Dirilyte (gold colored flat ware) Disposable Plastic Glassware Knives Lead Crystal Non- Dishware Non-Stick Coatings Pewter (continued) Comments Not recommended - hand wash only, Read manufacturer’s washing instructions before loading. Not recommended - hand wash only, Read manufacturer’s washing...
  • Page 20 English Dishwasher Safe or Hand Wash Material Dishwasher Safe type Plastic Silver & Silver Plated Stainless Steel Metal Wood (continued) Comments Only if stated "Dishwasher Safe". Read manufacturer's washing instructions before loading. Note: Rinse these items immediately. If you are...
  • Page 21: Care & Cleaning Of Your Dishwasher

    • Do not use any sharp objects that can scratch the cabinet surface. Preventing your dishwasher from freezing To protect your dishwasher if it is left in an unheated place during the winter. • Shut off electrical power to the dishwasher.
  • Page 22: Troubleshooting

    English Troubleshooting Dishwasher does not work • Check if the circuit breaker needs to be reset or if the fuse needs to be replaced. • Check if the unit is in "OFF" mode. • Check if the door is open. You may need to close the door properly.
  • Page 23 Over Sudsing This is due to the use of regular hand washing detergent. Detergent used should be for "Automatic Dishwasher Use". You must use the proper detergent for best dishwashing results. Dishware Odor • This is due to an incomplete cycle.
  • Page 24 (20") above the sub floor or floor. • If the drain hose is bent or shrunken, it may affect water draining. • If water can not be drained out smoothly, the dishwasher operation will be affected and it may stop in the middle of the cycle.
  • Page 25 Dishwasher is running for too long • The temperature of incoming water is below 120˚F. Raising your water heater setting will help to shorten the time of operation. • Call the Haier Customer Satisfaction Center if this does not resolve the problem. English...
  • Page 26: Warranty

    Water Distribution System (Parts Only) For 24 months from the date of original retail purchase, Haier will replace any parts in the water distribution system which fail due to manufacturing defect. This includes the pump, motor, lower wash arm, middle wash arm and the wash tower upper sprayer with associated supply tube and filters.
  • Page 27 No regrese este producto a la tienda Si tiene algún problema con este producto, por favor contacte el "Centro de Servicio al Consumidor de Haier" al 1-877-337-3639 (Válido solo en E.U.A). NECESITA UNA PRUEBA DE COMPRA FECHADA PARA EL SERVICIO DE LA GARANTIA Made in China Fabriqué...
