10.1 Replacing the lancing device with a blanking plate

Undock the lancing device from the meter as follows.
Push the slide button in the direction indicated by the arrow (1) and
hold it there.
Slide the lancing device out in the direction indicated by the arrow
(2).
152
Blood glucose testing in a multi-patient setting
Instead of the lancing device you can use a blanking plate which is
available from Accu-Chek Customer Care at 1-800-363-7949.
Hold the meter so it is horizontal, with the recess for docking the
lancing device pointing upwards.
Slide the blanking plate over the recess from the left along the
meter in the direction indicated by the arrow.
The guides along the inside of the recess must engage with the
grooves along the blanking plate. The blanking plate is properly
attached when it locks into place with an audible CLICK.
