This document describes the installation procedure for the 4190-9007 Remote
Printer. Consult the User's Guide supplied with your printer for a detailed
description of mechanical setup, features and operating principles.
The 4190-9007 Remote Printer interfaces with Simplex Fire Alarm and Nurse
Call systems. The printer provides hard copy of status reports for these systems:
Fire Alarm
-
2120 Multiplex
-
4010
-
4020
-
4100+
5001 Nurse Call
The following topics are covered in this publication.
Control Panel DIP Switches
Serial Interface DIP Switches
Printer Connections
Connecting to Fire Alarm Systems
4010 Front Panel Programming for an RS-232 Port
Connecting to 5001 Nurse Call
Control Panel
4190-9007 Remote Printer
Installation Instructions
-
4120 Network
-
4120 GCC
-
4120 NPU
Topic
Page Number
2
3
6
7
9
12
13
574-124
Rev. B
