- Page 1 Slimline High Definition Digital Advertising Display User’s Manual Manual Version PFHD2.0...
- Page 2 Slimline High Definition Digital Advertising Display User’s Manual Our Full Product Range Page 1...
-
Page 3: Safety Instructions
Slimline High Definition Digital Advertising Display User’s Manual Safety Instructions Please keep the display away from any heat sources. Place the display in a stable and well-ventilated place. Please handle with care as product contains glass. The holes or openings on the display are designed for ventilation. Do not cover or block the ventilation holes or openings with any objects. -
Page 4: Figure 1 Position Of Screen Inputs
Slimline High Definition Digital Advertising Display User’s Manual Quick Start Guide This section of the guide is to allow swift set up and use of the unit. Please refer to the main part of the User Guide for full information on use of the unit. -
Page 5: Table Of Contents
Slimline High Definition Digital Advertising Display User’s Manual Contents: Introduction ..........................6 Box Contents ........................6 Product Overview ......................6 Remote Control ....................... 7 Replacing the Remote Control Battery ................8 System Menu Operation ....................9 1.5.1 System Settings ...................... 10 1.5.2... - Page 6 Slimline High Definition Digital Advertising Display User’s Manual F.A.Qs and Troubleshooting Guide ................... 36 My scrolling text message does not appear on my screen ........... 36 How do I play PowerPoint presentations on my display? ..........37 5.2.1 Option 1 (for plain slides with no animation): ............37 5.2.2...
-
Page 7: Introduction
Slimline High Definition Digital Advertising Display User’s Manual 1. Introduction Congratulations on your purchase of our product. Please read carefully and follow all instructions in the manual before first use. The product should not be exposed to liquids dripping or splashing and no objects filled with liquids, such as vases, should be placed on the product. -
Page 8: Remote Control
Slimline High Definition Digital Advertising Display User’s Manual 1.3 Remote Control Page 7... -
Page 9: Replacing The Remote Control Battery
Slimline High Definition Digital Advertising Display User’s Manual 1.4 Replacing the Remote Control Battery 1. Slide the battery cover off, as shown below. 2. Remove the used batteries. 4. Insert the two new AAA batteries with their terminals corresponding to the indicators. -
Page 10: System Menu Operation
Slimline High Definition Digital Advertising Display User’s Manual 1.5 System Menu Operation In order to access the Setup Menu you must first press “STOP” button to go back to the home screen (pictured below). You can then bring up the Main Menu by pressing “SETUP”. -
Page 11: System Settings
Slimline High Definition Digital Advertising Display User’s Manual 1.5.1 System Settings The sub-menus within this section are OSD Language, Clock Display, Scrolling Text, USB Port as well as Restore to Factory Settings and Return to Main Menu options. OSD Language The On Screen Display supports four languages –... - Page 12 Slimline High Definition Digital Advertising Display User’s Manual Scrolling Text There are 2 options as pictured below: Off: The screen doesn’t display scrolling text. On: The screen will display scrolling text from the txt file in the playlist, if there is no playlist or .txt file, the screen doesn’t display scrolling text.
- Page 13 Slimline High Definition Digital Advertising Display User’s Manual USB Port There are 2 options as pictured below: On: The screen restarts automatically once media is loaded (recommended). Off: The screen must be turned off and back on by the mains (or reset button pressed) once media has loaded and media cannot be loaded on home screen.
-
Page 14: Playback Control
Slimline High Definition Digital Advertising Display User’s Manual 1.5.2 Playback Control Storage Priority This section is used to set where the screen will read the media files from - Internal Storage or USB Disk. There are two options as pictured below: ... - Page 15 Slimline High Definition Digital Advertising Display User’s Manual Play Time This is used to set the display time for image files under the Free Playback Mode without using a playlist file. Page 14...
-
Page 16: Date & Time
Slimline High Definition Digital Advertising Display User’s Manual 1.5.3 Date & Time To set accurate date and time first select this menu to open the options pictured below. Next, use ← & → to select which value you wish to modify. Now you can change the setting by pressing ↑ &... - Page 17 Slimline High Definition Digital Advertising Display User’s Manual Weekly You can set the on/off timer for each individual day of the week. For example, on Sunday, 6:00am on, 11:00am off: 1. Choose Weekly in the On/Off Timer menu, press “PLAY” to confirm: 2.
-
Page 18: Local Id
Slimline High Definition Digital Advertising Display User’s Manual There are 3 options available: Timer: user can set 3 timer groups; each group can set “On” or “Off”. Always On: after connecting the power cable, the product will powered on. -
Page 19: File Management
Slimline High Definition Digital Advertising Display User’s Manual If your screen is mounted in landscape orientation please select Horizontal then highlight and select Save and Reboot. Your screen will now restart and when it reboots back to the Home Screen your OSD should be in the correct orientation. -
Page 20: Exit
Slimline High Definition Digital Advertising Display User’s Manual 1.5.8 Exit Highlighting and selecting this section will exit the main menu. Page 19... -
Page 21: Display Settings
Slimline High Definition Digital Advertising Display User’s Manual 1.6 Display Settings As well as having a main system menu that can be accessed through your home screen, the unit also has a display setting menu for changing which input source is being displays as well as altering values such as brightness, contrast and saturation. - Page 22 Slimline High Definition Digital Advertising Display User’s Manual Picture Here you can alter the overall image settings of your screen. The default value for all the image settings is 50. To adjust the Brightness, Contrast and Saturation of your display navigate to the setting, press “PLAY”...
- Page 23 Slimline High Definition Digital Advertising Display User’s Manual Exit To exit from this Display Settings menu, navigate to Exit and press “PLAY”. If inactive for more than 10 seconds, you will automatically exit this menu. Page 22...
-
Page 24: System Operation
Slimline High Definition Digital Advertising Display User’s Manual 2. System Operation 2.1 Supported Media Files Media Type Supported File Type Image JPG, BMP, PNG, GIF Video MPG, AVI, MOV, MP4, TS Audio MP3, WMA 1. This unit does NOT support WMV or FLV video file types. -
Page 25: Steps To Load Media Files
Slimline High Definition Digital Advertising Display User’s Manual 2.2 Steps to Load Media Files 1. Copy the files you want to play on to USB drive in the root directory (without putting them into a folder). 2. Insert USB drive into the USB slot (see Figure 1). -
Page 26: Installation
Slimline High Definition Digital Advertising Display User’s Manual 3. Installation 3.1 Wall Mounting Before you start you will need: Included: 1 x Mounting Plate 1 x Security Screw 1 x Screen Not Included: 9 x 8x40mm Wood Screws 9 x 8x40mm Wall Plugs... - Page 27 Slimline High Definition Digital Advertising Display User’s Manual 1. Clean the wall space where you wish to mount your screen. Using a spirit level position the Mounting Plate on the wall and mark out the position of the 9 holes.
- Page 28 Slimline High Definition Digital Advertising Display User’s Manual 3. Insert your wall pugs into the holes ensuring that none of them are protruding (flush with the wall). 4. Fix the Mounting Plate to the wall using the screws. Page 27...
- Page 29 Slimline High Definition Digital Advertising Display User’s Manual 5. Ensure that the Mounting Plate is securely fixed to the wall carefully match up the screen’s mounting holes with the plate’s hanging pegs. 6. Take the security screw from your accessories bag and insert it into the screen to lock it in position.
-
Page 30: Figure 4 Security Screw
Slimline High Definition Digital Advertising Display User’s Manual Figure 5 Security Screw Page 29... -
Page 31: Advanced Guide
Slimline High Definition Digital Advertising Display User’s Manual 4. Advanced Guide Although this unit can operate without using any additional software, for more advanced applications please copy the Playlist Editor scheduling software (on the CD provided) to your computers’ hard drive. The software also allows you to edit existing 4.1 Main Menu... -
Page 32: Add Schedule
Slimline High Definition Digital Advertising Display User’s Manual 4.2.1 Add Schedule The schedule functions as a timer for the playlists, so you can have between one and eight playlists scheduled to start and end at different times of the day, with up to 50 files in each playlist. - Page 33 Slimline High Definition Digital Advertising Display User’s Manual > Enter a duration time > Select Image switch mode > Click “OK” > Image appears in Schedule. You can select multiple image files at once to add to a schedule, you can also move each item up or down in the playlist by using the arrow buttons on the right hand side.
- Page 34 Slimline High Definition Digital Advertising Display User’s Manual Adding Video Note: Before adding video files please ensure that it has a file name of 11 characters or less and contain no special characters (!”£$%^&* etc.). Click the “Add Video” button >...
-
Page 35: Saving
Slimline High Definition Digital Advertising Display User’s Manual 4.2.3 Saving Note: Before saving please ensure location drive is empty. Click “Save to Disk” > Click “Browse” and select the top level of the USB drive as the location of the playlist and files >... -
Page 36: Editing Playlists
Slimline High Definition Digital Advertising Display User’s Manual 4.3 Editing Playlists From the main menu click “Load Existing Playlist” > Locate and select playlist to edit > Playlist appears in playlist creator > Select item to edit and click “Edit” button located on the top right hand side of the application. -
Page 37: F.a.qs And Troubleshooting Guide
Slimline High Definition Digital Advertising Display User’s Manual 5. F.A.Qs and Troubleshooting Guide 5.1 My scrolling text message does not appear on my screen If you have set up a playlist that includes a scrolling text message it should appear at the bottom of the screen as your media is playing, if it is not, you have not turned this function on. -
Page 38: How Do I Play Powerpoint Presentations On My Display
Slimline High Definition Digital Advertising Display User’s Manual Navigate to Return to Main Menu and press “PLAY”. You can now press “PLAY” on the home Screen to display your media – your scrolling text message should now appear. 5.2 How do I play PowerPoint presentations on my display? 5.2.1 Option 1 (for plain slides with no animation):... -
Page 39: Wireless Connection
Slimline High Definition Digital Advertising Display User’s Manual • Aspect Ratio: 16:9 (widescreen); • Encode Size: Width 720, Height 480. 5.3 Wireless connection The screen does not have a wireless capability built in. However, with the range of screen inputs available as shown in Figure 44 an external network media player can be easily connected. - Page 40 Slimline High Definition Digital Advertising Display User’s Manual 6. Click the ‘Output Setting’ button and modify it to look like the image shown below. A number of important settings have been highlighted. 7. Select ‘OK’ to save these changes and then Press ‘OK’ button to goto main screen...
-
Page 41: Hd Video Converter Deluxe
Slimline High Definition Digital Advertising Display User’s Manual 8. Press the ‘Start’ button along the top to start the conversion. Once completed, press the ‘Output Folder’ to see the converted video. 5.4.2 HD Video Converter Deluxe This is only really useful for High Definition videos. -
Page 42: Connecting Screen To Pc
Slimline High Definition Digital Advertising Display User’s Manual 5.5 Connecting screen to PC If your PC has a HDMI output then this is ideal. Simply connect one end of a HDMI cable to the screens HDMI input (see Figure 4) and the other to your PCs HDMI output port. Using this method will carry both your PCs visual and audio signals. -
Page 43: My Media File Will Not Display Or Is Missing From The Playlist
Slimline High Definition Digital Advertising Display User’s Manual 5.7 My media file will not display or is missing from the playlist In this situation the first step to take is to start with a blank USB drive. Copy one supported picture file (2.1 Supported Media Files) onto the blank USB drive and insert this into the unit. - Page 44 Slimline High Definition Digital Advertising Display User’s Manual Once you have done this your media should now play in a loop. To stop this from happening in the future first press “STOP” to return to the home screen. Next, press “SETUP” to bring up the Main Menu.
